- Page 1 CU900 TV BRACKET INSTALLATION GUIDE...
- Page 2 Spirit Fitness...
- Page 3 Congratulations on your new TV bracket and welcome to the Spirit Fitness family! Thank you for your purchase of this TV bracket from Spirit Fitness. This bracket was manufactured by one of the leading fitness manufacturers in the world and is backed by one of the most comprehensive warranties available.
- Page 4 WARNING: This product may contain a chemical known to the state of California to cause cancer, birth defects, or other reproductive harm. Spirit Fitness...
- Page 5 CU900 TV BRACKET STEP ONE 1. Remove the console cover and console. 2. Remove Handlebar assembly and disconnect HR wires. 3. Using a TV cable, or wire snake (indicated by a thick black line), drop it down the hole of the console mast tube.
- Page 6 CU900 TV BRACKET STEP TWO 1. Route the cables at the top of the machine through the TV bracket and mount the bracket on top of the handle bar mount (installing both at the same time) using the original handle bar hardware.
- Page 7 CU900 TV BRACKET STEP THREE 1. Re-assemble console and console cover to the console mast after removing the dummy panel. www.spiritfitness.com...
- Page 8 CU900 TV BRACKET STEP FOUR HARDWARE FOR STEP 4 PART TYPE DESCRIPTION SCREW M5x12mm SPLIT WASHER 4x1.0 FLAT WASHER SCREW M5x12mm 1. Assemble the TV to the TV bracket with four M4 SCREWS (6), SPLIT WASHERS (7) and FLAT WASHERS (8). Attach the rear TV bracket cover with the M5 SCREW (9).
- Page 9 NOTES www.spiritfitness.com...
- Page 10 NOTES Spirit Fitness...
- Page 11 NOTES www.spiritfitness.com...
- Page 12 800.258.4555 Spirit Fitness spiritservice@spiritfitness.com 3000 Nestle Road www.spiritfitness.com Jonesboro, AR 72401 CU900 TV Bracket Installation Guide © 2018 All Rights Reserved Revision: 02.28.2018...
