Nuvico Xcel TE-100-4M Quick Start Manual

TE-100-4M Encoder
Quick Star t Guide
Thank you for purchasing our product. Please read these instructions
carefully for correct use of the product and keep it for further reference. All
examples and pictures used here are for reference only. There may be several
technically incorrect places or printing errors in this manual. The updated
information will be added into the new version of this manual. The content is
subject to change without notice.
1
Warning and Caution
■ If the product does not work properly, please contact your dealer or
the nearest service center. Never attempt to disassemble the device
yourself. (We shall not be responsible for any problems caused by
unauthorized repair or maintenance.)
■ Keep away from liquid while in use.
■ In the use of the product, you must be in strict compliance with the
electrical safety regulations of the nation and region. When the product is
mounted on wall or ceiling, the device shall be firmly fixed.
■ Do not use the device beyond specified voltage range.
■ Do not drop it or subject it to physical shock.
■ If cleaning is necessary, please use clean cloth to wipe it gently.
■ Do not place it in extremely hot, cold (the operating temperature shall
be -4˚F~131˚F), dusty or damp locations, and do not expose it to high
electromagnetism radiation.
■ To avoid heat accumulation, good ventilation is required for operating
environment.
■ A few parts of the device shall be replaced regularly according to their
average enduring time. Regular checking is recommended for all users.
2
Package
Device Quick Start Guide
Plastic plug ×4
4 tapping screws PA 4×25
3
Overview
• Front Panel
1 2 3 4 5 6
5
1 Micro SD card slot
6
2
Reset
HD-TVI/AHD video input
3 7
4 Grounding 8
• Rear Panel
CD
1 DC12V power input
2
PoE network interface
3
LAN/
WAN
DC12V
7 8
Monitor
Audio input
Audio output
Sensor
Power indicator
DC12V power output
1 2 3 4 5
Alarm output
4
Alarm input
5
Analog video output 6 RS 485 interface
Loudspeaker
PTZ
Alarm out
6
HD-TVI / AHD
Security Camera
Sound pickup
