Continental Underfloor HeatMax 34005 Installation And User Manual

HeatMax™ UFH wiring centre
4 zone
34005
Installation and user guide
The HeatMax™ UFH wiring centre is a 4-zone wiring module that has all of the electrical
connections for warm water underfloor heating systems.
Key features:
- It connects HeatMax™ room thermostats to the corresponding HeatMax™ zone
actuators
- The zone actuator state (open / closed) is indicated by green LEDs
- The boiler and pump state (on / off) is indicated by red LEDs
- It includes a volt-free contact to operate external items such as combination boilers
- Additional zones can be added by plugging in HeatMax™ UFH wiring centre
extensions
- DIN rail or wall mountable
