- Page 1 P165C Play 165mm Component Kit User Manual...
- Page 2 Ensure that no moving parts catch on the speaker or grill (e.g. door handles or window glass inside the door). WARRANTY All Bass Habit products carry a full warranty depending on the conditions in the country where it is sold. The warranty is valid from the date of the original receipt as proof of purchase (warranty period differs depending on local warranty laws and policies).
- Page 3 INSTRUCTIONS INSTALLATION EXPERIENCE Installation of Bass Habit speakers may require experience with a variety of mechanical procedures. This manual only provides general installation and operation instructions. If you have any reservations about your installation skills, please contact your local authorized Bass Habit dealer for help.
- Page 4 INSTRUCTIONS INSTALLING THE COMPONENT KIT 1) Determine where the speaker will be mounted. Make sure there is a flat area large enough for the speaker to fit properly. An uneven mounting surface can damage the speaker. 2) Check to make sure the space you have selected for the speaker will not interfere with vehicle operation. 3) If a template is included in the packaging, use the template and mark the hole with a pen.
- Page 5 WIRING DIAGRAM Your P165C midwoofer uses a single 4 ohm voice coil. It is important to know the limits of your amplifier to optimize its performance. Follow the wiring diagram below to install your P165C component kit properly.
- Page 6 SPECIFICATION P165C Component Kit Component 165mm (6,5") / 25mm (1") Size RMS Power 120W MAX Power 4 Ohm Nominal Impedance 3,2 Ohm D.C Resistance 73Hz - 20Khz Freq. Response 88 dB Sensitivity Frame Material Steel (WF) / ABS (TW) Cone Material PP (WF) / PEI (TW) Suspension Material Rubber (WF) / PEI (TW)
- Page 7 Winn Scandinavia AB reserves for possible typos, factual or numeric errors that may have been printed on any products, package designs, user manuals and/or other included accessories. Bass Habit is a registered trademark by Winn Scandinavia AB and is protected by relevant laws and jurisdictions such as Copyright and Trademark laws.
