Summary of Contents for Liftsafe Fall Protection RoofGuard Classic HGC-KIT-09
- Page 1 User Instruction Guide for RoofGuard Classic Freestanding Guardrail System Liftsafe Fall Protection Inc. RoofGuard Classic User Manual Page 1 RGC-UM-3.0...
-
Page 2: Table Of Contents
Table of Contents Section Page Number 1.0 Application 2.0 System Requirements 3.0 Components 4.0 System Layout 5.0 Installation 6.0 Detailed Inspection and Maintenance Log 7.0 Warranty 8.0 Notes Page 2... - Page 3 Alterations or misuses of this system or failure to follow instructions may result in serious injury or death. If you have any questions on the use or care of this system peoples contact Liftsafe Fall Protection Inc. at 1-800-977-2005. Page 3...
-
Page 4: Application
1.0 APPLICATION 1.1 The RoofGuard Classic system is designed to be installed on flat rooftops anywhere workers may be at risk of fall from an elevated surface while working; rooftops, mezzanines, or around openings, when workers should be protected by a physical barrier from the hazard. 2.0 System Requirements 2.1 The RoofGuard Classic system is designed to be used on flat roofs (up to 5% grade) where the baseplate can sit flat on the roof surface. -
Page 5: Components
3.0 Components 3.1 Baseplates are cast in steel and hot dip galvanized for long-term outdoor use. Cone point stainless steel set screws secure the guardrail into the base plates. 3.2 Vertical posts are supplied with fittings and caps for a variety of configurations: by placing the fittings on a vertical post, the 5 common “post”... - Page 6 3.3 Horizontal rails are available in two standard sizes, 6-foot & 9-foot. For other sizes, the aluminum pipe is suitable for cut-to-fit on-site. The 6 foot sections of rail are used for the tie-backs to provide the counter weight for the system. This may also be used along the leading edge where a 9-foot section is too long.
-
Page 7: System Layout
4.0 System Layout 4.1 Install bases and rails on a flat, clean and dry surface. Clean the area where base plates will be installed, if necessary, to ensure good contact with the roof surface. 4.2 If curb or parapet is 4” or more above the top of the base-plate, then bases can be positioned against the parapet. -
Page 8: Installation
5.0 Installation 5.1 When working near the roof edge, workers should be tied-off to an alternate fall protection system. Ideally workers should use a fall-restraint system utilizing a lifeline that will allow them to reach the edge, but not be long enough to be able to fall. 5.2 If toe-boards will be required, place the toe-board adapter on the top of the baseplate before placing the vertical posts into the desired holes. - Page 9 5.5 Use a 3/16” hex drive bit (provided) or wrench, and torque baseplate screws to 25ft- lbs. All set screws for stacked plates must be secured against the wall of the vertical posts. 5.6 Once torqued the set screw can be ‘marked’ with the blue crayon (provided) to provide a visual indicator that the screw has been secured and warn of tampering.
- Page 10 Image of Complete a Complete Classic RoofGuard System Figure 13 Figure 14 Page 10...
- Page 11 Warning – Do NOT lean on, or climb on guardrails. Guardrails MUST NOT be used as an anchor fo r fall restraint or fall arrest, and shall not be used for hoisting or tie -off. Attac hment of banners / signs / equipment is not permitted. Excess forc e applied to the top rail c ould cause tipping, resulting in injury or death.
-
Page 12: Detailed Inspection And Maintenance Log
6.0 Detailed Inspection and Maintenance Log Inspection Date Inspection Items Corrective Action Maintenance Approved By Noted Taken Performed Page 12... -
Page 13: Warranty
7.0 Liftsafe Fall Protection Warranty Equipment offered by Liftsafe Fall Protection (LFP) is warranted against factory defects in workmanship and materials for a period of one year from date of installation or use by the owner, provided that this period shall not exceed 18 months from date of shipment. Upon notice in writing, LFP will promptly repair or replace all defective items. -
Page 14: Notes
8.0 Notes Page 14... - Page 15 Liftsafe Fall Protection 409 Harmony Road Ayr, Ontario N0B 1E0 TF.: 1(800) 977-2005 (519) 896-2430 (519) 896-2085 E.: info@liftsafeinspections.com W.: www.fallsafetysolutions.com Page 15...
