i
INSTALLATION INSTRUCTIONS START ON PAGE 4.
Need Assistance?
As a manufacturer, we are committed
to providing complete customer
satisfaction.
If you have questions, or if a part
is damaged or missing, follow the
directions below based on your
location:
For U.S. and Canadian Customers:
DO NOT CONTACT THE RETAILER.
Instead call us toll free at:
1-877-793-2198
Monday - Friday, 8:00 am to 5:00 pm
(Mountain Standard Time)
For customers outside the U.S.
and Canada:
Contact the retailer for assistance.
!
WARNING:
To ensure your safety, do not
attempt to install this system
without reading and following
all instructions. Please read all
precautions in this user's
manual and the product user's
manuals before using this
equipment. Failure to comply
may result in serious injury or
death. Keep this manual for
future reference.
Document # 1001-20A-r3
© 2020 | SwimShape, LLC
Advertisement
Summary of Contents for SWIMSHAPE SSSMB-20A
- Page 1 Please read all precautions in this user’s manual and the product user’s manuals before using this equipment. Failure to comply may result in serious injury or death. Keep this manual for future reference. Document # 1001-20A-r3 © 2020 | SwimShape, LLC...
- Page 2 Proper Care and Maintenance............................Limited Warranty................................. Thanks for purchasing a quality SwimShape pool sports and fitness product. The In-Deck (Sleeve-Mounted) Base is the mechanism installed on the deck of the pool that allows you to attach and use the QuikFire (and QuikFire Pro) Pool Basketball Hoops, QuikSpike Pool Volleyball Set, and the Pool-Up Bar.
- Page 3 It is the responsibility of the owner to ensure that all users are informed of all pre-cau- tions. The In-Deck Base is intended for use with the following SwimShape products only: QuikFire and QuikFire Pro Pool Basketball Hoops QuikSpike Pool Volleyball Set Pool-Up Bar Use of this product with any other product or device can result in serious injury or death.
- Page 4 Qty. Base Anchor (Sleeve)* Anchor Insert 2” End Cap Chrome Decal Warning Sticker Grounding Lug (screw included)* 1 Tension Knob Rubber Bumper Bumper Screw Anchor (Sleeve) Cap* Rubber Washer Retainer Nut Post Level Leveling Post © 2020 | SwimShape, LLC...
- Page 5 This section details the process of installing the In-Deck Anchor (sleeve) on a new pool being constructed. The In-Deck Anchor provided by SwimShape is a proprietary design used only with SwimShape pool sports and fitness products. Important: Please read and adhere to all guidelines and instructions before attempting to install the anchor.
- Page 6 Anchor Anchor Pool Edge 10.5” - 18.0” After determining the location and setback for the anchor, prepare the surface of the ground where the anchor will be installed so that it is flat and level. © 2020 | SwimShape, LLC...
- Page 7 To help prevent the anchor from shifting or moving when pouring the deck, you can use rebar or ground stakes to Holes secure the anchor in place. The two holes in the Anchor Plate can be utilized for this purpose. Anchor Plate © 2020 | SwimShape, LLC...
-
Page 8: Post Installation Notes
Post Installation Notes: Provide this manual to the pool owner once installation is complete. Remove the leveling post and retain for future installations. Do not use the Anchor until the concrete is fully cured. © 2020 | SwimShape, LLC... - Page 9 Base (1). Loosen the Tension Knob (8). Lift up on the Base (1) until the Anchor Insert (3) is clear of the Anchor (2). After setting the Base (1) aside, insert the Anchor Cap (11). © 2020 | SwimShape, LLC...
- Page 10 SwimShape has designed and engineered its pool sports and fitness products to provide years of use and enjoyment. Properly maintaining and caring for your product is required to maintain the appearance of the equipment and to prevent rust and corrosion.
- Page 11 All SwimShape products are sold on this condition, and no representative of the company are autho- rized to waive or change this policy. Under no circumstances shall SwimShape be liable for more than the total amount paid to SwimShape by the purchaser of the defective or damaged product.
- Page 12 SWIMSHAPE, LLC 2590 Commerce Way, # L Ogden, UT 84401 TEL: (877) 793-2198 FAX: (801) 315-8595 EMAIL: sales@swimshape tness.com SwimShape Pool Sports and Fitness products are proudly manufactured in the USA.
