- Page 1 INSTALLATION MANUAL CANDOCK RGB LIGHTS...
- Page 2 Here are very important details regarding the assembly of Candock RGB lights: THE FOLLOWING INSTRUCTIONS ARE GUIDELINES TO BE FOLLOWED AND RESPECTED. CANDOCK WILL NOT BE RESPONSIBLE FOR DAMAGES CURRED BY THE NON-COMPLIANCE WITH THESE GUIDELINES. All distributors are required and responsible to provide theoretical and practical...
-
Page 3: Installation
A. Put the main 12v power cable in place by putting it on the path created by the service bases. Use the cable provided by Candock or a no. 14 12v low voltage cable made for external features, 2 multi-stranded wires. - Page 4 2. Each set of lights has a small rubber ring you must first install on the service lids. The ring has a small slit that allows putting the fla nges of the hole done t the factory inside it. You will notice that if you push the ring completely on one side, it will o longer be inserted on the other...
- Page 5 5. Unscrew the tip located at the other end of the connector. There are 3 small pieces insi 6. Put the 12v power cable inside the connector by putting the different pieces as shown below. 7. T ake out the cable enough on the other side of the connector to be able to link it to the previously removed white part.
- Page 6 12. Take the black wire linked to the control box that has no connector at its end and connect it to a power plug adapted for your country. The blue wire being the negative one, the brown wire being the positive one, and the yellow and green wire being the ground.
- Page 7 16. Firmly press the wires in the connector. After put the superior part of the connector on the inferior part, making sure the wires are lying flat. 7. Using both thumbs, press firmly on both parts of the connector until you hear a click on each side of the connector.
- Page 8 21. he lights’ power supply complete. You must now link the lights between each other so the communication can be made between them and the control box. Take the white wire of the control box that should normally already be linked to it and connect it to the first light of the series.
- Page 9 26. ently remove the lid by paying attention not to disconnect the wires linking the base to the lid. 27. Inside you will find a selector that allows you to choose the appropriate voltage. Put the selector in the right position. (Beware, selectors are very fragile) 8.
- Page 10 You must never install a cable of more than 100m or 300ft, to avoid power losses. Contrary to white LED lights that do not have any polarity, RGB lights must be connected in the correct way to avoid any damage. Please follow instructions to the letter.
