Assembly Instruction
Parts List
Parts List
A
TOP
B
BOTTOM FRAME
C
POST
D
BUN FOOT
A
STEP 2
Assembly Procedures:
Step 1: Lay out all parts and hardware. Make sure the quantity of each is correct.
Step 2: Rest the top face down onto a clean soft flat surface such as a blanket and ensure that the surface is clear of any objects that could scratch or damage the top. Assemble the post to the bottom of
the top.
Step 3: Place the bottom frame on top of four posts and assemble the bun foot to the post through the bottom frame.
Step 4: Turn the desk to the upright position.
Assembly is now complete.
QTY
1 pc
1 pc
4 pcs
4 pcs
D
B
STEP 3
C
0850-6101 Computer Desk
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for LC 0850-6101
Summary of Contents for LC 0850-6101
- Page 1 Assembly Instruction 0850-6101 Computer Desk Parts List Parts List 1 pc BOTTOM FRAME 1 pc POST 4 pcs BUN FOOT 4 pcs STEP 2 STEP 3 Assembly Procedures: Step 1: Lay out all parts and hardware. Make sure the quantity of each is correct.
- Page 2 OPTION 1: The vanity mirror can be used with 0850-6101 computer desk. Place the mirror on the desk and align the center mark on back of the mirror with center mark on the desk. Secure the mirror to the desk with the short rails (C) and the hardware provided.
- Page 3 Assembly Instruction THANK YOU FOR PURCHASING THIS QUALITY PRODUCT. BE SURE TO CHECK ALL PACKING MATERIAL CAREFULLY FOR SMALL PARTS THAT MAY HAVE COME LOOSE INSIDE THE CARTON DURING SHIPMENT. CAUTION: (1) THESE PARTS ARE CUMBERSOME AND HEAVY. THIS PRODUCT CAN BEST BE ASSEMBLED WITH THE ASSISTANCE OF ONE OR MORE PERSONS IN ORDER TO PREVENT PERSONAL INJURY AND TO INSURE PARTS ARE NOT DAMAGED DURING THE ASSEMBLY PROCESS.
