- Page 1 Save This Manual for Future Reference ® ESD MOBILE CART Owner’s Manual Part Number ESD-EVH-1000 US Patent Number 10,881,040 For Your Safety Read and understand the entire manual before use Page | 1...
-
Page 2: Table Of Contents
Save This Manual for Future Reference TABLE OF CONTENTS Contents ................................3 UPPORT ................................3 ISCLAIMER REPLACEMENT COMPONENTS ..........................3 SPECIFICATIONS ..............................3 SAFETY ................................... 4 CART PINCH POINTS ............................... 5 INSTALLATION AND SETUP ............................ 6 ELECTRONIC SPECIFICATIONS ..........................7 ELECTRONIC SPECIFICATIONS CONTINUED...................... -
Page 3: Support
The information contained in this document is subject to change without notice or obligation. Kendall Howard LLC assumes no responsibility for the accuracy, completeness or reliability of the information contained in this document. -
Page 4: Safety
Save This Manual for Future Reference Safety Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on the ESD cart. Always read and obey all safety messages. This is the safety alert symbol. This symbol alerts you to potential hazards that can hurt you or others. -
Page 5: Cart Pinch Points
Save This Manual for Future Reference Cart Pinch Points IMPORTANT SAFETY INSTRUCTIONS Keep fingers, hands, and limbs away from these areas when initially raising or lowering. NOTE that external obstructions are not identified but could be or cause a possible pinch point. -
Page 6: Installation And Setup
Save This Manual for Future Reference Installation and Setup Step 1: Cut and remove the two plastic banding and any shrink wrap material Step 2: Lift off and remove the wooden cover. This will take 2 people. Step 3: Unfasten the wing nuts that anchor the ESD cart into the crate. Remove the 2 boards. Step 4: Lift the cart out of the crate. -
Page 7: Electronic Specifications
Save This Manual for Future Reference Electronic Specifications CHARGER •Power 175W. •Standby power consumption 0.1W. •Nominal output voltage: 29V DC ±10%. •Plug type C7. •Plug type: Mini fit 2-pole. •Thermal switch. Usage: •Storage and transport temperature: 14°f to 158°F (-10°C to +70°C). •Approved according to: EN 60335-1. -
Page 8: Electronic Specifications Continued
Save This Manual for Future Reference Electronic Specifications Continued Observe all governing codes and ordinances. Nominal input voltage 100V AC to 240V AC ±10% Nominal input: 1.2 A Nominal input frequency 50 Hz/ 60 Hz The cart is shipped with 3 power cords used for charging. •CP-5031 MAINS CABLE, AC- 3000 mm (US) •CP-5046... -
Page 9: Cart Components
Save This Manual for Future Reference Cart Components 1. Locking drawer, keyed 8. Caster brake (rear only) 2. ESD 3-layer vinyl mat, middle shelf 9. Rear linear motor 3. Front linear motor 10. Operator controls 4. Rubber bumper 11. Ergonomic handle 5. -
Page 10: Cart Control Panel Features
Save This Manual for Future Reference Cart Control Panel Features Display When the battery is connected the display will stay blank. Up/Down ˄ The up arrow will move the upper shelf/ work surface up at .10” (2.5 mm) increments. ˅ The down arrow will move the upper shelf/ work surface down at .10” (2.5 mm) increments. Preset Height •... -
Page 11: Cart Use
Save This Manual for Future Reference Cart Use ESD Control The ESD 3-layer vinyl mats are required for proper ESD protection when using this mobile cart. This unit provides a RTT value of < 1 X 10⁹ ohms for each shelf. This unit provides a RTG value of 1 X 10⁵... -
Page 12: Cart Use Continued
Save This Manual for Future Reference Cart Use Continued Middle Shelf The middle shelf is fixed at a height of 24.0” (61.0cm). Lower Shelf The lower shelf is fixed at a height of 8.8” (22.4cm). Drawer The drawer is mounted on the underside of the upper shelf. It has a full slide out extension of 8.0”... -
Page 13: Care And Cleaning
Save This Manual for Future Reference Care and Cleaning Painted Surfaces All painted surfaces can be cleaned with a non-abrasive, non-ammonia or non-bleached based cleaner. Do not use soap or detergents on exposed metal surfaces located on the lower shelf, middle shelf, and upper shelf/ work surface. -
Page 14: Troubleshooting
Save This Manual for Future Reference Troubleshooting Upper Shelf/ Work Surface will not raise or lower • Check the battery charge. To do this remove the ESD mat from the upper shelf/ worksurface and press the battery indicator button. If none of the LED light bars light up then the battery needs to be recharged. -
Page 15: Troubleshooting Continued
Save This Manual for Future Reference Troubleshooting Continued ESD non-compliant on middle shelf • Verify that the flooring has a RTT value of 10⁵<10⁹. • Verify that the ESD mat has a RTT value of 10⁵<10⁹. If it does not, clean mat and repeat test. -
Page 16: Labels
Save This Manual for Future Reference Labels Crush hazard warning Working load per shelf + total Main marking plate Page | 16... -
Page 17: Declaration Of Conformity
Save This Manual for Future Reference Declaration of Conformity Kendall Howard hereby declares that the ESD Worksurface/ Cart complies with Machinery Directive 2006/42/EC, ANNEX 1: Essential health and safety requirements relating to the design and construction of machinery and according to the standards: •... -
Page 18: Warranty
MISCELLANEOUS: NO SALESPERSON, EMPLOYEE OR AGENT OF KENDALL HOWARD IS AUTHORIZED TO ADD TO OR VARY THE TERMS OF THIS WARRANTY. Warranty terms may be modified, if at all, only in writing signed by a Kendall Howard officer. This Warranty is effective as of the date of Kendall Howard receipt of full payment and supersedes all previous warranties Kendall Howard reserves the right to supplement or change the terms of this Warranty in any subsequent warranty offering to User or others.
