REVELL RAIL Parts Diagram & Service Manual

Download this manual

Parts Diagram

Service Manual

R e v i s i o n A

3 / 2 / 2 0 2 2

Page 1 Parts Diagram & Service Manual R e v i s i o n A 3 / 2 / 2 0 2 2...
Page 2: Torque Specifications
Tools, Pivot Numbers & Torque Specifications Required Tools for Basic Service Torque Wrench 1x 4mm Hex Wrench 1x 4mm Hex Bit 1x 5mm Hex Bit 1x 6mm Hex Bit 1x 8mm Hex Bit Torque Specifications Pivot #1 10 Nm Pivot #2 10 Nm Pivot #3 10 Nm...
Page 3: Exploded View And Parts List
Exploded View & Parts List Part Number Description Qty. 3 1 0 - F R A 1 8 - 0 1 1 6 Piv ot #1 Ax le 3 1 0 - F R A 1 8 - 0 1 2 0 Piv ot #2 Ax le 3 1 0 - F R A 1 8 - 0 1 2 2 Pivot #3 Ax le...
Page 4 Pivot Assembly Overview When servicing your Rail’s linkage, take time to clean all parts thoroughly to ensure creak -free shredding. Apply Ti. Prep or Anti-Seize to threads of forward and rear shock mounting hardware (parts L and S in exploded view).
Page 5 Pivot Assembly Overview Pivot Number Diagram Parts List Rear Triangle 310-FRA18-0122 Pivot #3 Axle 310-FRA18-0121 Pivot #3 Spacer Front Triangle ------ 6801V Bearing 310-FRA18-0127 Pivot #3/#5 Bolt Upper Link Drive Side Torque to 10 Nm 310-FRA18-1124 Pivot #4 Axle Lower Link 310-FRA18-0115 Pivot #1/#4 Spacer 310-FRA18-1123...
