I n s t r u c t i o n s f o r t h e U s e a n d C a r e a n d I n s t a l l a t i o n o f

B F W M 7

7Kg Front Load Washing Machine

Table of Contents

Need help?

Do you have a question about the BFWM7 and is the answer not in the manual?

Questions and answers

Summary of Contents for Blanco BFWM7

Page 1 I n s t r u c t i o n s f o r t h e U s e a n d C a r e a n d I n s t a l l a t i o n o f B F W M 7 7Kg Front Load Washing Machine...
Page 2 Dear Customer You will find that the clean lines and modern look of your Blanco Front Load Washing Machine blends in perfectly with your laundry décor. It is easy to use and performs to a high standard. Blanco also makes a range of products that will enhance your kitchen – such as ovens, rangehoods, microwaves, sinks and taps.
Page 3 C O N T E N T S Pa rt 1 : Te c h n ic a l fe atu res . Pa rt 2 : St e p s b e f ore operating Fulla uto matic Wa sh i n g M a c hin e and s afety preca utions. Pa rt 3 : De t e rmin i ng Loc ation a nd In stallation Pa rt 4 :...
Page 4: General Warnings
General Warnings. • The appliance is not intended for use by young children or infirm persons without supervision. • Young children should be supervised to ensure that they do not play with the appliance. • If the appliance installed above carpet, please ensure that the carpet does not obstruct the openings •...
Page 5 P a r t 1 : Top lid Front door Kick plate Te c h n i c a l f e a t u r e s Control panel Capacity (dry fabric) Height Width Depth Net weight Power requirement Nominal current Power Washing speed...
Page 6 A mp...
Page 7 P a r t 3 : 1. Removing transport safety bolts at the rear of the machine The transport safety bolts must be removed before any operation of the machine. Bolt heads, marked “C”. Attention! Please keep the safety bolts for future transportationand reinstate them before transporting your machine. Never transport your machine without the transport bolts in position.
Page 8 l e v e l l e d l e v e l l e d...
Page 9: Water Drain Hose
b) Water drain hose Water drain hose could be placed either at the side of the laundry tub, or directly to the drain. The hose should not be bent. Water drain hose should be secured with the elbow so that it would not fall down on the ground. The hose should be placed between 40 and 100 cm.
Page 10: Sorting Laundry
Attention! Before any operation of the machine check the following. Did you close the front door? Is the tap open? Is water drain hose placed properly? Is power connected? Sorting laundry Sort the laundry according to the following groups and wash them seperately: - white and resistant colored fabrics, - colored fabrics, - delicate fabrics (silk, rayon etc.),...
Page 11: Detergent Dispenser
Detergent and softener selection Choose the appropirate detergent specifically used for FRONT LOAD washing machines. Suggested amount is given on the detergent cover. Do not attempt to use detergents and bleaching elements that contain chlorine and sulphur. The amount of the detergent depends on the dirt level of fabric, the amount of fabric and the softness of the water.
Page 12: Control Panel
Control Panel Quick wash Program follower Prewash Program selection knob Remain time On/Off Button Door open button Rinse Plus Timedelay Spin speed Detergent drawer adjustment button selection Anti Creasing Start/Pause/Cancel button...
Page 13: Quick Wash
Functions Prewash A pre-wash is only worth while with heavily soiled laundry. Without prewash you save energy, water, washing powder and time. Quick wash Shortens washing time for lightly soiled fabrics. This function can be used for cotton and synthetic programs for temperatures below 60° C. Rinse plus By using this function your machine will add another rinse process to the three rinse processes that it has already done.
Page 14: Program Selection And Washing Machine Operation
P a r t 5: Insert the plug. Press the On/Off button and then the Door Open button. Open the door. Place your laundry into the machine according to the recommended load capacity and close the front door. Select the proper program according to the dirt strength and the thermostat value by means of Program Selection Table given on the following pages.
Page 15: Program Selection
Program selection Programme Fabric type Heavy soiled fabrics made from cotton or linen, Cotton 90 heat resistant Normal soiled fabrics made from cotton or linen, Cotton 60* heat resistant Lightly soiled fabrics made from cotton, non-color Cotton 40 fast Heavy soiled fabrics made from cotton or linen, Intensive 60 heat resistant Normal soiled fabrics made from cotton/synthetics...
Page 16: Child Lock
Child Lock To prevent the knobs from being played with by your children you may activate “child lock” option. Activating the “Child Lock” option prevents any change from being made to a set program. To activate child lock, press both on the second and the fourth auxiliary function buttons together for 3 seconds after the machine starts the washing operation.
Page 17 On/Off When you press the On/Off button, your machine is ready to select the desired program. The “door open” LED will be on and the door is ready to open. When the desired program is selected, related spin speed can be adjusted and the duration of the program can be observed on the display.
Page 18 End of the Program If all the wash programs are finished, all the LEDs on the program follower will be on . “1-2 minutes” for door open is displayed on remain time display. After1-2 min door open LED will light up. At the end of the washing, all related LEDs on the control panel will be on.
Page 19 Time Delay By using the time delay buttons, starting time of any program can be delayed. Time delay can be set at intervals of 30 min. On the display, the delayed starting time is added to the duration of the program. For example, if the program duration is 2 hours and 16 min and you delayed the program for 2 hours, the display will show “4:16”.
Page 21 Cleaning the pump filter Remove the electrical power plug. Open the open the Kick plate cover located at the bottom right side of the machine by pushing on the marked area shown beside. Attention! Hot water danger! It is possible that app. 15 lt, 90˚C hot water is inside.
Page 22: Before Calling Service
You turned the machine on, but the LEDs do not light up on the panel. Check that the power cord is plugged in and power is turned on or a blown fuse. Check the front in closed properly closure. Machine does not take water. Check the front door for proper closure.
Page 23 Blanco Contact Information. NEW SOUTH WALES Head Office, Sales & Marketing Office 104 Vanessa Street Kingsgrove NSW 2208 Telephone: 02 9503 2888 Facsimile: 02 9503 2810 NSW Showroom* 40 Ebley Street Bondi Junction NSW 2022 Telephone: 02 9386 1190 Facsimile: 02 9386 1671 Agent and Sales Office.
