Summary of Contents for minikon CND1
- Page 1 CND1 - Quick start guide 4231=EN VERSION 1119...
- Page 2 Pro-Line 28/50/70 CND1 - Control box installation 4249 8080 8280 8085 8230 CND1 4x 8085 2x 8280 4x 8230 2x 4249 2x 8080 Position of spiral cable bracket...
- Page 3 Pro-Line 28/50/70 CND1 - Connection of door control boxes 4x 9382...
- Page 4 Connect cables to circuit boards in door control boxes Opto: Module 10 + 11 DW: Module 12 + 13 Duo Opto: Module 20 + 21 Connections A = Spiral cable B = Connecting cable C = OPTO / OSE1 / OSE2 D = SCD L/R / PD Switch...
- Page 5 Pro-Line 28/50/70 CND1 - Basic installation 1/2 NOTE! Do not plug in CEE plug yet! ✓...
- Page 6 Pro-Line 28/50/70 CND1 - Basic installation 2/2 NOTE! Do not plug in CEE plug yet! SCD / Passdoor Opto / Light curtain X3.7 X3.8 X3.7 X3.8 X3.7 Spiral cable X3.8 X3.7 X3.8 X3.7 X3.8 Programming mode X3.7 X3.8 Shaft drive encoder...
- Page 7 Pro-Line 28/50/70 CND1 - Basic programming 1/2 ✓ NOTE! Plug in the CEE plug to program the control box. Activate programming mode Display Move switch 1 to ON Determine open door position Until Display: Display: Keep pressed Display: Release button 4 sec.
- Page 8 Pro-Line 28/50/70 CND1 - Basic programming 2/2 Determine closed door position Until Display: Display: Keep pressed Display: Release button 4 sec. Door closed Exit programming mode ✓ Move Switch 1 to OFF Check the operation of the door Door open...
- Page 9 Pro-Line 28/50/70 CND1 - Installing remote control Option remote control NOTE! Only plug in the CEE plug and peripheral equipment after connecting all of the plug-in plugs in the way described below. NOTE! Insert the plug-in circuit board firmly to ensure a good contact.
- Page 10 Pro-Line 28/50/70 CND1 - Programming the remote control Option remote control ✓ NOTE! Plug in the CEE plug to be able to connect to the remote control. A sound will be made as long as the button on the plug-in circuit board is sec.
- Page 11 Pro-Line 28/50/70 CND1 - Reinstall factory settings ✓ NOTE! Plug in the CEE plug! Switch DIL switch Display: Move switch 4 to ON Reinstall CND1 factory settings Display: Display: Display: 2 sec Version Number Move DIL switch to OFF ✓...
