Summary of Contents for GeoMax ZENITH04
- Page 1 ZENITH04 USER MANUAL V1.1 Sept. 2014 Central phone +49 (0)2052 78 81 0 GeoMax International Mobile phone +49 (0) 162 635 98 20 Liegnitzer Str. 1-3 Direct E-Mail customercare@geomax-positioning.com 42489 Wülfrath www.geomax-positioning.com Deutschland...
-
Page 2: Table Of Contents
Table of Contents Chapter 1 Product Introduction ..........1 1.1 Front Components .............. 6 1.1.1 Keypad ................7 1.2 Back Components ............... 9 1.3 Bottom Components ............10 Chapter 2 Basic Skills .............. 11 2.1 Turning on Suspending Turning Off Resetting ..11 2.1.1 Turning on .............. - Page 3 4.5.2 Drawing and Writing on the Screen Directly ..... 29 4.5.3 Recording a Message ..........29 4.5.4 Camera (Select Models Only) ........30 4.5.4.1 Taking Pictures ............30 4.5.4.2 Recording Video Clips........... 32 4.6 Personal Settings .............. 33 4.6.1 Buttons ................ 34 4.6.2 Home ................
- Page 4 6.2 Resetting Your Device ............62 6.3 Caring for Your Device ............63 Chapter 7 Legal Notice ............616 7.1 Copyrights and trademarks ..........616 7.2 Standard limited warranty ..........626 7.3 Service procedure ............639 7.4 Enviromental recycling ............. 80 Appendix 1 Specification ……………………………………………………………61 4/76...
- Page 5 REFACE ZENITH04 is a highly integrated handheld mobile termi- nal, with an 806MHz processor, 4G -board FLASH memo- ry, high-capacity battery, integrated wireless access cap- ability diversification (including GPRS, WIFI and Blue- tooth). For integrating many functions, it can be very convenient to collect, store and transfer data in the wild using the ZENITH04.
-
Page 6: Chapter 1 Product Introduction
HAPTER RODUCT NTRODUCTION This chapter mainly introduces you to the external com- ponents of your device. 2.1 1.1 F RONT OMPONENTS Component Description Flashes in red to indicate that your device is being turned on. When battery charging, Flashes Charge/Power in green to indicate battery on Indicator charging is in progress. -
Page 7: Keypad
Flashes in blue to indicate that Wireless com- the Bluetooth function is on. munication indi- Flashes in green to indicate that cator the Phone function is on. Serves as the phone earpiece Earpiece during a call. Displays the output of your de- Touch Screen vice and responds to your tap- ping. - Page 8 Provide functions as indicated by the red icons when Fn lock is on. Moves up, down, left and right within the screen or menu. Goes to the next input field. Alternative Increases the brightness level Function Keys of the screen. It cycles to the lowest level after reaching the highest level.
-
Page 9: Back Components
2.2 1.2 B OMPONENTS Component Description Takes still pictures or records Camera Lens video clips. Speaker Plays music, sounds and voices. Hand Strap Hol- The hand strap attaches here. ders Battery Cover Inside is the battery. 9/76... -
Page 10: Bottom Components
2.3 1.3 B OTTOM OMPONENTS Component Description Provides D-sub 9 pins RS232 Serial Connector function. USB OTG (Host & Connects to the USB cable. Client) Connector Power Connector Connects to the AC adapter. Used to place the stylus that is served as the input device by Stylus Pinhole tapping on the touch screen to... -
Page 11: Chapter 2 Basic Skills
HAPTER ASIC PERATION This chapter mainly introduces you to the basic operati- ons of your device. 3.1 2.1 T URNING ON USPENDING URNING ESETTING 3.1.1 2.1.1 Turning on Press the Power Button and don not let go until the indi- cator color turns to green from red. -
Page 12: Resetting
Figure 1 3.1.4 2.1.4 Resetting If the device stops responding to the stylus or if it does not respond when you press any of the keypad buttons, you may need to reset it by performing a hard reset. 3.1.4.1 2.1.4.1 Performing a Hard Reset Press both buttons one second at the same time and then press the power button to turn on your... -
Page 13: Charging The Battery
2. We can see two slots then, with the upper side one in- stalling SIM card and the bottom side one installing TF card. To install the SIM card, push the SIM card holder right. With the SIM card’s chip side facing down put the card into the slot. -
Page 14: Fitting The Hand Strap
charge of the battery can affect the charging performance. 3.5 2.5 F ITTING THE TRAP Align the upper hand strap bracket with the two mounting holes behind the device and then use a screwdriver to tighten the screws. The other side is fixed to the hand strap holders at the bottom of the device. -
Page 15: Installing The Windows Mobile Device Center
device and a PC you must connect the device to a PC. If the computer is running: • Windows 7 or Windows Vista operating system, use the Windows Mobile Device Center (WMDC) to manage the connection. • Windows XP or 2000 operating system, use ActiveSync to manage the connection. -
Page 16: Managing The Connection And Synchronization Using The Windows Mobile Device Center
Use a USB connection: Plug the USB cable into the USB port on the device. Plug the other end of the USB cable into a USB port on the PC. 4.2.1 3.2.1 Managing the Connection and Synchronization Using the Windows Mobile Device Center Connect the device to the PC. - Page 17 Click “connect without setting up your device” shown as in figure 4. Figure 4 Click “File Management”. Appear a drop-down menu shown as in figure 5. 17/76...
- Page 18 Figure 5 Click “Browse the contents of your device” shown as in figure 6. 18/76...
-
Page 19: Managing The Connection And Synchronization Using The Activesync
Figure 6 Open the data of the corresponding letter of the disk, sel- ect the files in the desired path you want to realize uplo- ading and downloading files. 4.2.2 3.2.2 Managing the Connection and Synchronization Using the ActiveSync Connect your device and a computer, and then it will appear the dialog box shown as “Microsoft Outlook”, tap “×”... - Page 20 Figure 7 When the Welcome to the Pocket PC sync setup wizard shown as in figure 8 appears, tap “×” on the upper-right corner. Figure 8 Enter the synchronization interface shown as in figure 9, tap “Explore”. 20/76...
- Page 21 Figure 9 You will enter the Mobile device interface shown as in fi- gure 10. Tap “My Windows Mobile-Based Device” to enter the letter of disk interface and import and export data Figure 10 21/76...
-
Page 22: Connecting With U Disk Mode
4.2.3 3.2.3 Connecting with U Disk Mode When you have established connection between your de- vice and your computer, the U disk mode will complete before ActiveSync mode. Open “My computer” and then you can see the letter of “Mobile Device” shown as in fi- gure 11. -
Page 23: Otg Connection
Figure 12 CAUTION: please ensure the device has enough power during synchronously transmitting data. 4.2.4 3.2.4 OTG Connection Use OTG function connecting cord to connect the U disk or other USB mobile storage devices to USB connector on the bottom of the device. Open File Explorer, tap the pull- down box of my device, then you can see the letter of “Hard Disk”. - Page 24 Figure 13 Click the Windows icon in the lower left corner of the home screen. We can see the start menu shown as figure 14 where we can conduct basic settings and start rele- vant procedures. Figure 14 24/76...
-
Page 25: Status Indicators
Press and hold the program icon until the icon bounce shown as figure 15, then drag the icon to the location where you want shown as figure 16. Figure 15 Figure 16 5.2 4.2 S TATUS NDICATORS The status indicators appear in the title bar at the top of the screen. -
Page 26: Speaker Status Indicators
external charge 5.2.2 4.2.2 Speaker Status Indicators The battery status icon on the title bar of the Home screen or the Start screen shows the status of the spea- ker. Icon Description Speaker is on Speaker is off 5.2.3 4.2.3 Network and Modem Status Indicators The network and modem status icons on the title bar of the Home screen or the Start screen show the status of each radio. -
Page 27: Interacting With The Device
Text Send, receive and organize text messages. E-mail Compose, send and receive E-mail messages. Internet Brows the world wide web. Explorer Keep track of appointments and arrange mee- Calendar tings. Contacts Keep track of your friends and colleagues. Windows Access Windows Live services, including: E- mail, instant messenger and Internet search. -
Page 28: Entering Information
5.5 4.5 E NTERING NFORMATION Depending on the program you are using, you can enter information in several ways, as described below: Input method Description Use Microsoft connection management soft- Synchronizing ware to exchange information between the device and a PC. Use the Keyboard input panel to enter typed Typing text by clicking keys on the on- screen key-... -
Page 29: Drawing And Writing On The Screen Directly
5.5.2 4.5.2 Drawing and Writing on the Screen Directly In some applications, for example Notes, you can directly draw (or write) on the screen using the stylus. / Notes shown as in figure 19, tap menu, select Draw, and then you can write or draw directly on the screen. -
Page 30: Camera (Select Models Only)
5.5.4 4.5.4 Camera (Select Models Only) Camera function built-in allows you to take photo or vi- deo in real time. 5.5.4.1 4.5.4.1 Taking Pictures 1. To start the program, press the key on your device or tap / Pictures & Videos/ Camera. The Camera screen appears shown as in figure 20. - Page 31 Figure 21 Menu Descriptions Items Three choices: 1. Normal 2. Burst- Continuous shooting of Mode 5 pictures 3. Timer-5 second countdown before shooting Three choices: 1. 640×480 Resolution 2. 1024×768 3. 2048×1536 Full Full screen on or off. Screen Overall settings to the Camera Options program.
-
Page 32: Recording Video Clips
CAUTION: By default, the display area blanks out and shows the word “standby” when the camera has been idle for one minute. To resume, tap the screen. 3. Press the key to take the picture. 4. The result shows on the screen if the picture was taken in Normal or Timer mode. -
Page 33: Personal Settings
Figure 23 CAUTION: By default, the display area blanks out and shows the word “standby” when the camera has been idle for one minute. To resume, tap the screen. 4. Press the key to start recording. If needed, you can tap “Pause”... -
Page 34: Buttons
5.6.1 4.6.1 Buttons Use the Buttons control under Personal settings to assign the action you want to be performed when you press theF1, F2 or F3. By default, these keys perform the sa- me action as the left and right tiles in the tile bar. / Settings/ Personal/ Buttons, open the button in- terface shown as in figure 24. -
Page 35: Items
Figure 25 To use a predefined theme select it from the list. Select “Use this picture as the background” check box, and then tap “Browse” to search for a file on the device. Tap “OK” to complete the theme picture settings. 5.6.2.2 4.6.2.2 Items You can customize which items appear on the Home screen and the order in which they appear by the item... -
Page 36: Set Date And Time
Figure 26 Select the items to appear on the home screen and the order in which they appear, and then tap “OK”. 5.6.2.3 4.6.2.3 Set Date and time There are three methods as follows to open the Clock &Alarms interface: 1. -
Page 37: Screen Lock
Figure 27 Set the required hours, minutes, seconds from the drop- down list then. 5.6.3 4.6.3 Screen Lock Tap the Screen Lock icon on the Start screen to lock the screen and keypad while the device remains turned on. After that you can see the interface shown as in figu- re 28. -
Page 38: Set Passwords
Figure 28 Slide the unlock icon to unlock. 5.6.4 4.6.4 Set Passwords It is possible to keep your data secure by requiring a password each time the handheld is turned on, tap Settings / Lock to set a password or to change password settings shown as in figure 29. -
Page 39: Sounds And Notifications
Figure 30 Figure 31 Tap “Battery” tab to check the battery level. Tap “Advan- ced” tab shown as in figure 31 to set the time before the device turns off when idle. 5.6.6 4.6.6 Sounds and Notifications Use the Sounds & Notifications control set preferences for the speaker volume and system sounds. -
Page 40: Screen
Figure 32 Figure 33 Tap “Notifications” tab shown as in figure 33 to set the Ring type and Ring tone of the event. 5.6.7 4.6.7 Screen Use the Screen interface to align the touch screen or to change the appearance of text on the screen. Tap / Settings/ System/ Screen, and then tap “General”... -
Page 41: Backlight
Figure 34 Figure 35 Tap “Text Size” tab shown as in figure 35 and drag the slider control to change the size of the text, tap “OK”. 5.6.8 4.6.8 Backlight The backlight makes the screen easier to read in low light but uses extra power. -
Page 42: Align Screen
Figure 36 Figure 37 Unselect “Turn off backlight if device is not used for”, then the device won’t turn off the backlight when idle. Tap “Brightness” shown as in figure 37 to change the brightness of the device. 5.6.9 4.6.9 Align Screen Whenever the screen doesn’t respond to the stylus or y- our finger, you should align the screen. -
Page 43: Gprs Network Setting
Figure 38 Figure 39 Tap the target to align the screen, the device will exit the align interface automatic after the screen is aligned. 5.7 4.7 GPRS N ETWORK ETTING Use GPRS to connect the internet, you can receive and send messages through the network. - Page 44 Figure 40 Figure 41 2. Choose “advanced” as shown in figure 41, tap “select networks” shown as in figure 42. Remarks: if internet had been set, you can turn to step 5. 3. Choose “My ISP” in drop-down box and click “Ok” to return to figure 41 and then click the “tasks”...
-
Page 45: Bluetooth Connecting
4. Tap “Add a new modem connection” as shown in figure 5. In “select a modem” choose “cellular line (GPRS)” and then click the next step. Input the name of access point “CMNET”. Figure 44 Figure 45 Tap “Next” as shown in figure 45, it’s not need to fill User name, Password and Domain. - Page 46 Figure 46 Tap “Add new device” and select the specified Bluetooth device. Tap “Next” to input password (default password is 1234) as shown in figure 47, tap “Next”, and then tap “OK”. Figure 47 Figure 48 Back to Bluetooth main screen, select “COM ports”. Choo- se “New Outgoing Port”.
-
Page 47: Phone And Text Messages (Select Models Only)
COM7, COM8, COM9) as show in figure 48, and then click “Finish”. CAUTION: To delete the port matched before when we are using Bluetooth, the right operation method is delete it first in the matching port, and then delete the specific device in the “disconnected”. - Page 48 1. Tap / Settings/ Connections/ Wireless Manager, or tap the tittle bar, tap connectivity indicator on the pull- down list, and then tap “Wireless Manager”. 2. Appear the screen as shown in figure 49. Figure 49 Tap “Phone” to switch it from off to on. 3.
-
Page 49: Making A Call
CAUTION: if the phone is currently off, you will be asked to turn it on. Whenever you start Phone, the Phone screen displays the soft keypad. You can tap Hide Keypad (left soft key). You can use other programs during a call. To quickly switch back to Phone, press the Send key on your device. - Page 50 3. Press the Send key on your device to make the call. CAUTION: If you enter a wrong number, use the Backspace key to eraser indi- vidual numbers one at a time. If you are making an international call, tap and hold on the number key 0 until + sign appears.
-
Page 51: Responding To A Call
2. Do one of the followings to call a person in the Call History list: Select the number to call and then tap “Call” or press the Send key on your device. Tap and hold on the number to call and then tap “Call”... - Page 52 5.9.1.4.2 4.9.1.4.2 U SING THE UNCTION During a call, you can mute your microphone so that the person with whom you are speaking cannot hear you, but you can still hear him or her. On the Phone keypad, tap “Mute” to switch on the mute function.
- Page 53 Placing a Call on Hold to Make a Second Call 1. During a call, tap “Hold” to place the first call on hold. 2. Dial a second number or the first few letters of the se- cond contact’s name by using the numeric keypad on y- our device.
-
Page 54: Using Call History
2. The icon indicates that the phone call entry contains a note. Tap and hold the name or number for that entry, and tap “View Note” in the shortcut menu. CAUTION: You can also tap “Programs”, “Notes”, and ac- cess the note in the Calls folder. 5.9.1.5 4.9.1.5 Using Call History Call History provides the time and duration of all inco- ming, outgoing, and missed calls, and a summary of total... -
Page 55: Using Speed Dial
5.9.1.6 4.9.1.6 Using Speed Dial You can create Speed Dials for frequently-called phone numbers so you can dial a number with a single key press. 5.9.1.6.1 4.9.1.6.1 C REATING A PEED NTRY Speed dials can only be created for numbers stored in Contacts. - Page 56 You can customize phone settings, such as the ring type and ring tone to be used for incoming calls, and the keypad tone to be used when entering phone numbers. CAUTION: To use custom .mp3, .wav or .mid files as ring tones for incoming calls, copy the files to the Application data/ Sounds folder on your device or to the inserted sto- rage card.
-
Page 57: Additional Phone Operations
You can view available wireless networks, determine the order in which your phone accesses another network if the current one is unavailable, and specify whether you want to change networks manually or automatically. The current network will remain active until you change it, lo- se your signal, or change your SIM card. -
Page 58: Text Messages
Some mobile phone network services may require that a SIM card be inserted, and in some cases that the PIN be entered. There may be other emergency numbers available. Your mobile phone network service may save additional local emergency numbers in the SIM card. 5.9.1.8.5 4.9.1.8.5 D IALING AN NTERNATIONAL... -
Page 59: Wifi Connecting
To select phone numbers from Contacts, tap “To”. 4. Enter your message. To quickly add common messages, tap Menu/ My Text, and tap a desired message. 5. Tap “Send”. 5.10 4.10 WIFI C ONNECTING 5.10.1 4.10.1 Switching On or Off the Wi-Fi Radio By default, the Wi-Fi radio is switched off. -
Page 60: Chapter 5 Software Operation
to change the network settings. Tap the desired network and change the settings. 5. When you have finished using the wireless network, end the Wi-Fi connection by switching off its radio. CAUTION: Leaving the radio on will consume more power. HAPTER OFTWARE PERATION... -
Page 61: Uninstalling Programs
6.2 5.2 U NINSTALLING ROGRAMS / Settings/ System/ Remove Programs and select the program you want to uninstall, tap “Remove” to ac- complish the operation. HAPTER ROUBLESHOOTING AND AINTENANCE This chapter gives solutions to common device problems you may encounter. It also provides guidelines on taking care of your device. -
Page 62: Resetting Your Device
In some specific cases, your device may experience connection prob- lems when it is connected to a Windows computer running Active- Sync. To resolve the problems, please tap / Settings/ Connec- tions/ USB to PC, and then clear “Enable advanced network” functio- nality. -
Page 63: Caring For Your Device
2. Upgrade BOOT: Press and hold the power button, number keys 4 and 7 when your device is off until the screen appears upgrade BOOT. Restart your device when the upgrade has successfully completed. 3. Upgrade OS: Press and hold the Power button, number key 4 and “*”... - Page 64 Regulations Statements European Notice Products with the CE marking comply with Radio & Telecom- munication Terminal Equipment Directive (R&TTE) (1999/5/EEC), the Elec- tromagnetic Compatibility Directive (89/336/EEC) and the Low Voltage Di- rective (73/23/EEC) – as amended by Directive 93/68/ECC – issued by the Commission of the European Community.
- Page 65 User and the consequences thereof, which may alter the con- formity of the product with the CE Marking. FCC Regulations This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received,...
- Page 66 which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. Regulatory Information 9-3 Changes or modifications not expressly approved by the party responsible for compliance could void the user‘s authority to operate the equipment. The antenna(s) used for this transmitter must not be co- located or operating in conjunction with any other antenna or transmitter.
- Page 67 with paper or other objects that will reduce cooling. Do not use the charger while it is inside a carrying case. 9-4 Regulatory Information Connect the charger to a proper power source. The voltage grounding requirements are found on the product case and/or packaging.
- Page 68 measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg. *Tests for SAR are conducted using standard oper- ating positions accepted by the FCC with the device transmitting at its highest certified power level in all tested frequency bands.
-
Page 69: Chapter 7 Legal Notice
Bluetooth is a trademark owned by Bluetooth SIG, Inc. and licensed to Trimble Navigation Limited. All other trademarks are the property of their respective owners. This is the February 2014 release of the GEOMAX® ZENITH04 Series re- ceiver user guide. The following limited warranties give you specific legal rights. You may have others, which vary from state/jurisdiction to state/jurisdiction. -
Page 70: Standard Limited Warranty
GEOMAX® Europe agrees to repair or replace the defected instrument within thirty (30 ) days only if GEOMAX® Europe recognizes that the defects of the instrument are not caused by human factors or no obvious damage to its surface is visible. - Page 71 Return policy Dead On Arrival instruments All returned products have to be shipped to GEOMAX® Europe represen- tative office. The original Purchaser has a period of seven (7) days starting from date of purchasing to signal the existence of a defect in the instrument for a...
- Page 72 ELECTRONICS AT TIMES. IF THIS PRODUCT FAILS TO WORK AS WARRANTED ABOVE, CUSTOMER’S SOLE AND EXCLUSIVE REMEDY SHALL BE REPAIR OR REPLACEMENT. IN NO EVENT WILL GEOMAX®, ITS AFFILIATES OR SUPPLIERS BE LIABLE TO CUSTOMER OR ANY THIRD PARTY FOR ANY DAMAGE IN EXCESS OF THE PURCHASE PRICE OF THE PRODUCT.
-
Page 73: Enviromental Recycling
Battery chargers: 6 months. Cables, Bracket, Pole, Carrying case, Antennas : 1 year. 7.4 Environmental recycling The cardboard box, the plastic in the package and the various parts of this product have to be recycled and disposed of in accordance with the current legislation of your Country. -
Page 74: Appendix 1 Specification
PPENDIX PECIFICATIONS Model Zenith04 Physical specification Operation System Windows Mobile6.5 Processor Marvell PXA-310 806MHz Xscale 256MB Internal storage 4G + 256MB Extended storage TF card up to 32G Weight 550g(with internal battery) Size 177*91*33mm Camera 5,000,000 pixels, VGA resolution video capture... - Page 75 Safety Precautions Prolonged listening of music in maximum volume can damage the ears. The use of headphones other than those recommended/supplied can cause hearing impairment due to excessive sound pressure. About Charging Use only the AC adapter supplied with your device. Use of another type of AC adapter will result in malfunction and/or danger.
- Page 76 About Radio Frequency Exposure This device meets the government’s requirements for exposure to radio waves. This device is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government. The exposure standard for wireless devices employs a unit of measurement known as the Specific Absorption Rate, or SAR.
