- Page 1 Other Accessories Meter accessories sold by eGauge Systems. eGauge Display Caster 12 Volt Power Supply eGauge CT Extension Kit Step-down transformer...
-
Page 2: Specifications
Display Caster Visit the online store page Model: EDC eGauge Display Caster The eGauge Display Caster provides an easy method display an eGauge meter device interface on a TV or monitor via HDMI through an easy-to-use interface. The Display Caster has a micro USB input for power, USB inputs for keyboard and mouse for initial configuration, and an HDMI output to connect to a TV or monitor. - Page 3 HDMI cable Printed Manual Velcro for mounting Assembly/installation information The default password for the display caster is printed on the paper attached to the manual, as well as inside the box with the eGauge Display Caster. The password can be changed during setup.
- Page 4 Display Caster Manual ...
-
Page 5: Volt Power Supply
12 Volt Power Supply Visit the online store page SKU: PSU12V The 12 Volt Power supply is a standard power supply to convert 100-240VAC @ 0.5A (50/60Hz) to +12VDC @ 1A used to power the BF430 RS485-to-Ethernet adapter, CR-Magnetics DC CTs and other powered devices. - Page 6 Can be used to supply power to: BF-430 RS485 to USB converter via barrel jack CR5220 DC CT (with eGauge supplied modified leads) IMT irradiance sensor Other future product offerings by eGauge ...
- Page 7 eGauge CT Extension Kit The eGauge CT Extension Kit (ESH044) allows up to four CTs to be connected to an eGauge located within 100'/33m of the CT Extension Kit. The CT Extension Kit is designed to be installed in a separate junction box outside the breaker panel, and requires an Ethernet run back to the eGauge meter.
- Page 8 Hardware included Sensor Hub RJ-45 coupler 19" RJ-45 to 2-pin breakout cable Assembly/installation information Do not connect the Sensor Hub Ethernet port to an Ethernet network. It is only used to carry signals from the 2-pin inputs on the Sensor Hub to the eGauge 2-pin ports. The CT Extension Kit consists of three components: 1.
- Page 9 The RJ-45 jack is used to connect the hub to the eGauge. The four switches A through D on the face of the unit must be set to the right-most position. The hub does not require power. 2. Hub RJ-45 to 2-pin breakout cable (whip) This connects the hub to the eGauge.
- Page 10 Diagrams The image below shows a simplified CT Extension kit wiring diagram. The Extension Hub must be installed in a separate enclosure. Always adhere to code requirements during installation. Multiple CT Extension Hubs can be connected to a single eGauge meter. Care should be taken to identify the hubs correctly, in order to avoid mixing up CTs.
-
Page 11: Related Information
Software configuration Information The CT Extension Hub does not require any special configuration when used with CTs. Simply specify the CT type (manufacturer, physical diameter, amperage) and create registers as normal. For example, assume two J&D 10mm 50A CTs on CT ports one and two. Assuming they are each monitoring a single 120V branch circuit (eg, CT1 is monitoring lights and CT2 is monitoring receptacles), the eGauge configuration might look like this: ... -
Page 12: Step-Down Transformer
Step-down transformer Visit the online store page Current manufacturer information: Functional Devices model TR50VA008 Stepdown transformers are intended only to power 120V equipment off higher voltage service. To measure 480V delta systems (no neutral), 600V delta systems (no neutral), or 347/600V Wye, please use the EV1000 High Voltage Sensors. - Page 13 Wire Length: 9.5 ̋ Typical w/ .5 ̋ Strip Operating Temperature: -30 to 140° F MTBF: 100,000 Hours @ 77° F Construction: Split-Bobbin Weight: 3.04 lbs. Approvals: UL5085-2 Listed General Purpose, US / Canada, CE, RoHS Hardware included Step-down transformer Assembly/installation information Follow instructions included with transformer, ensure correct primary and secondary wires are used.
