Summary of Contents for Forme HTR-5HS9065
- Page 1 Multi Bar Towel Warmer Installation Instructions...
- Page 2 Template for tile fixing x1 Contact Forme Agents FTR Products with any questions on the contents of your order. An electrical tradesman needs to check the resistance and continuity of the heating cable coming from the towel warmer with an ohm-meter.
- Page 3 TOWEL WARMER INSTALLATION INSTRUCTIONS TOWEL WARMER INSTALLATION INSTRUCTIONS MOUNTING YOUR TOWEL WARMER CODE REQUIREMENTS • Please note that this appliance must be installed as prescribed by the relevant wiring rules and regulations, including the Do note that all models will have the power cord exiting on the bottom right bracket (when facing the towel regulations covering installation of appliances and accessories in ‘wet areas’...
-
Page 4: Wiring Instructions
Any heated towel warmer that is found to be defective due to substandard materials and/or workmanship within 3 years of purchase will receive replacement product only. To make a claim under this warranty, contact Forme 3 years of purchase will receive replacement product only. To make a claim under this warranty, contact Forme Agent FTR Products Canada. - Page 5 TOWEL WARMER INSTALLATION INSTRUCTIONS TOWEL WARMER INSTALLATION INSTRUCTIONS CODE TUBE SHAPE BARS FINISH VOLTAGE AMPERAGE RESISTANCE CODE TUBE SHAPE BARS FINISH VOLTAGE AMPERAGE RESISTANCE HTR-TS0701 Square Polished Stainless 120V 0.67A 200Ω HTR-TS0701BSS Square Brushed Stainless 120V 0.67A 200Ω 120mm 120mm 620mm / 24.4”...
- Page 6 TOWEL WARMER INSTALLATION INSTRUCTIONS TOWEL WARMER INSTALLATION INSTRUCTIONS CODE TUBE SHAPE BARS FINISH VOLTAGE AMPERAGE RESISTANCE CODE TUBE SHAPE BARS FINISH VOLTAGE AMPERAGE RESISTANCE HTR-TS0701RG Square Brushed Rose Gold PVD 120V 0.67A 200Ω HTR-TR0701 Round Polished Stainless 120V 0.67A 200Ω 120mm 120mm 620mm / 24.4”...
- Page 7 TOWEL WARMER INSTALLATION INSTRUCTIONS TOWEL WARMER INSTALLATION INSTRUCTIONS CODE TUBE SHAPE BARS FINISH VOLTAGE AMPERAGE RESISTANCE CODE TUBE SHAPE BARS FINISH VOLTAGE AMPERAGE RESISTANCE HTR-TR0701BSS Round Brushed Stainless 120V 0.67A 200Ω HTR-TR0701RG Round Brushed Rose Gold PVD 120V 0.67A 200Ω 120mm 120mm 620mm / 24.4”...
- Page 8 TOWEL WARMER INSTALLATION INSTRUCTIONS CODE TUBE SHAPE BARS FINISH VOLTAGE AMPERAGE RESISTANCE CODE TUBE SHAPE BARS FINISH VOLTAGE AMPERAGE RESISTANCE HTR-5HS9065 Square Polished Stainless 120V 0.5A 200Ω HTR-TS0602M Square Polished Stainless 120V 0.67A 200Ω 115.4mm 650mm / 25.6” / 4.5”...
- Page 9 TOWEL WARMER INSTALLATION INSTRUCTIONS CODE TUBE SHAPE BARS FINISH VOLTAGE AMPERAGE RESISTANCE HTR7006206OP Round Polished Stainless 120V 0.5A 200Ω 120mm 620mm / 24.4” / 4.7” ø19.1mm .8” ø31.8mm / 1.3” 158mm / 6.2” L(Black)1.8m/5.9’ N(White)1.8m/5.9’ 620mm / 24.4” E(Green/Yellow) 1.8m/5.9’...
