JKS 9608 Installation Instructions

Installation
Instructions
Product: Bar Pin Adapters™
Part Number: PN 9608
Welcome
CONGRATULATIONS on purchasing new Bar
Pin Adapters from JKS Manufacturing. We are
committed to providing you with the best
products available and your satisfaction is our
first priority.
PLEASE READ these Installation Instructions
carefully, and save them for future reference,
as they contain important installation and
maintenance information.
JKS Bar Pin Adapter Installation
Important
COMPATIBLE WITH Racing Shocks using
1/2" ID spherical bearings.
INSTALLATION OF BAR PIN ADAPTERS
effectively reduces the static length of shock
absorber by 0.40"

Tools Required

Metric/Standard Socket Wrench Set
Torque Wrench
Bench Vice or C-Clamp
Hammer and Punch *
Sanding or Grinding Wheel *
Factory Service Manual (recommended)
* Asterisk denotes tools that are not required for some
applications. Thoroughly read instructions first to
determine which tools will be required for your
application.
PN 9608

Parts

DESCRIPTION PART #
A
Cross Pin / Block Combo PN 9608BP
B
Mounting Block PN 96080B
C
1/8" Roll Pin PN 64083
D
M10 x 50mm Hex Bolt PN 40698
E
Split Washer PN 40253
F
Composite Cone PN 96060D
G
1/8" Spacers PN 960601
QTY
2
2
2
4
4
2
2
Page 1 of 2
