52" VENTUS

™

INDOOR LED FAN

LED

CEILING FAN INSTRUCTION MANUAL

Table of Contents

Need help?

Do you have a question about the VENTUS and is the answer not in the manual?

Questions and answers

Summary of Contents for Hinkley Lighting VENTUS

Page 1 52" VENTUS ™ INDOOR LED FAN CEILING FAN INSTRUCTION MANUAL...
Page 2 WE WANT YOU TO LOVE YOUR NEW FAN SO WE’RE HERE IF YOU HAVE A QUESTION, NEED SOME HELP OR WANT TO CHAT ABOUT OUR PRODUCTS. SEND SUGGESTIONS OUR WAY TOO—WE’RE ALWAYS LOOKING TO MAKE YOUR EXPERIENCE WITH HINKLEY A POSITIVE ONE. >...
Page 3: Table Of Contents
TROUBLESHOOTING HANGING THE FAN ENERGY GUIDE ELECTRICAL CONNECTIONS SPECIFICATIONS FINISHING THE INSTALLATION SMART BY BOND INSTALLING THE BLADES WARNING: Read and follow these instructions carefully and be mindful of all warnings shown throughout. ©2019 Hinkley Lighting, Inc. | hinkley.com |...
Page 4 GENERAL INSTALLATION & OPERATION INSTRUCTIONS To ensure the success of the installation, be sure to read the instructions and review the diagrams thoroughly before beginning. To avoid possible electric shock, be sure electricity is turned off at the main power box before wiring. All electrical connections must be made in accordance with local codes, ordinances and/or the National Electric Code.
Page 5: Important Safety Precautions
These factors must be supplied by the person(s) installing, caring for and operating the unit. TOOLS & MATERIALS REQUIRED • PHILLIPS SCREWDRIVER • FLAT SCREWDRIVER • WRENCH OR PLIERS • WIRE CUTTER • STEPLADDER • WIRING SUPPLIES AS REQUIRED BY ELECTRICAL CODE ©2019 Hinkley Lighting, Inc. | hinkley.com |...
Page 6: Unpacking Your Fan
• Do not discard the carton. If warranty replacement or repair is ever necessary, the fan should be returned in original packing. Remove all parts and hardware. Do not lay motor housing on its side, or the decorative housing may shift, be bent or damaged. • Examine all parts. You should have the following: VENTUS PACKAGE CONTENT Blade Set of 3 BL902852Fxx...
Page 7: Preparation
35 pounds. Attach hanging bracket to outlet box using screws provided with the outlet box. Flat Washer Spring Washer Outlet Box Screw Fig. 1 ©2019 Hinkley Lighting, Inc. | hinkley.com |...
Page 8: Hanging The Fan
HANGING THE FAN Remove ball from downrod by loosening set screw in the side of the ball. Slide ball down and remove ball pin; Cross Pin remove ball. (Fig. 1) Carefully support fan body (motor) in its styrofoam packing Hanger with the mounting collar (where the wires come out) facing Ball upward.
Page 9 Hanger bracket cable through lag bolt as possible. Feed end of Safety cable cable into clamp hole and ﬁrmly tighten screw Safety cable clamp (Fig. 4). Cut off excess safety cable. Fig. 4 ©2019 Hinkley Lighting, Inc. | hinkley.com |...
Page 10: Electrical Connections
ELECTRICAL CONNECTIONS REMEMBER -Turn off the power! NOTE - Control must be installed within 30 feet of fan. WARNINGS: Check to see that all connections are tight, including ground, and that no bare wire is visible at the wire nuts, except for Outlet box the ground wire.
Page 11: Finishing The Installation
WARNING: Make sure the hook on the hanging bracket properly sits in the groove in the hanger ball before attaching the canopy to the bracket by turning the housing until it drops into place. ©2019 Hinkley Lighting, Inc. | hinkley.com...
Page 12: Installing The Blades
INSTALLING THE BLADES Place Fiber washer on screw. Insert this assembly through the blade and start the screw into the blade arm. Repeat this procedure without tightening the screw until all 3 screws have been started into the blade arm. Tighten each screw starting with center screw.
Page 13: Installing The Led Assembly And Glass Shade
Raise the glass shade against the LED assembly and turn Light clockwise until snug, DO NOT OVERTIGHTEN. assembly Screws Restore power and your LED assembly is ready for operation. Fig. 2 ©2019 Hinkley Lighting, Inc. | hinkley.com...
Page 14: Installing The Wall Control
INSTALLING THE WALL CONTROL Option 2. For single gang box REMEMBER to turn off the power before you begin. NOTE - Secures to any surface or application: ﬂat wall, single gang Remove the existing wall plate and the old switch from the wall outlet box, multi gang box.
Page 15 Cradle A of Hinkley switch will ﬁt in any standard decora face plate. Remote transmitter will be held in place with built in magnets. Fig. 4 Outlet box Face plate Switch Fig. 3 HIRO Control System ©2019 Hinkley Lighting, Inc. | hinkley.com |...
Page 16: Operation
OPERATION Your DC brushless motor is equipped with an button: automatically learned type remote control. Press this button and release instantly to There is no frequency switches on the receiver turn on or off the light. or transmitter. The fan can start to use once the pairing process is done.
Page 17 An UPWARD airﬂow moves warmer air off the ceiling area as shown in Figure 4. This allows you to set your heating unit on a cooler setting without affecting your comfort. SUMMER MODE WINTER MODE (COUNTERCLOCKWISE DIRECTION) (CLOCKWISE DIRECTION) Fig. 3 Fig. 4 ©2019 Hinkley Lighting, Inc. | hinkley.com...
Page 18: Care And Cleaning
CARE AND CLEANING Periodically it may be necessary to re-tighten blade to blade arm screws or blade arm to motor screws to prevent clicking or humming sound during operation. This is especially true in climates with broad temperature and humidity ranges. When dusting the blades, you must support the blade to prevent bending - no pressure should be applied to the blades.
Page 19: Energy Guide
0.42 0.22 • Energy Use: 34 Watts All estimates based on typical use, excluding lights ftc.gov/energy RPMs Airﬂow Shown Is a Weighted Average of High and Low Cubic Feet per Minute Based on Downrod ©2019 Hinkley Lighting, Inc. | hinkley.com...
Page 20: Smart By Bond
SMART BY BOND (SOLD SEPARATELY) HINKLEY SMART FAN OPTIONS: • Brute Force Method In addition to the included wall control, you can control your Hinkley fan a) Turn mains power OFF to the fan. through the Bond app. b) Turn mains power back ON on the fan. c) Hold down the Power button on the transmitter for 5 seconds, •...
Page 21 HINKLEY IS PROUD TO PROVIDE YOU WITH CEILING FAN PRODUCTS THAT ENHANCE YOUR SPACE WITH COMFORT, PURPOSE AND STYLE. AS A FAMILY COMPANY, WE ARE COMMITTED TO DESIGN, PERFORMANCE AND QUALITY, AND WHAT’S IMPORTANT TO YOU IS PARAMOUNT TO US. FOR A COMPLETE ASSORTMENT OF OUR PRODUCTS AND SOURCE BOOKS, VISIT HINKLEY.COM.
Page 22 GLOBAL HEADQUARTERS 33000 Pin Oak Parkway | Avon Lake, Ohio 44012 T (440) 653 5500 | F (440) 653 5555 | hinkley.com...
