Richards-Wilcox Aurora Shelving 3501-A Assembly Instructions

Assembly Instructions
IMPORTANT-Before You Start
Before you begin assembly of your shelving sections:
1. Check your floor plan. Assemble sections from left to
right.
2. Check that all items have been received.
3. Check that floor will support shelving load. It is the
end user's responsibility to provide adequate flooring
for the system and its application.
IT IS THE CUSTOMER'S (USER'S) RESPONSIBILITY
TO PROVIDE FOR ANCHORING SHELVING.
WARNING!
Storage units that are unleveled or not properly
anchored can be accidentally tipped over causing
serious bodily injury.
Use wall ties and floor anchors to fasten units to the
building. Use aisle ties to anchor multiple units to
each other.
Floor shims may be used for leveling.These items
available in the current price list.
All units should be anchored to prevent accidental
tipping. Refer to Assembly Instructions.
Aurora Shelving
NO. 3501-A
600 South Lake Street • Aurora, IL • 708-897-6951 • Fax 708-897-6994

General Assembly Instructions

1. Always assemble sections from the bottom up.
2. Always assemble additional sections from left to
right, and from the bottom up. Do not start the next
section until first section is completed.
3. Always seat each shelf support as it is installed by
tapping each end with a rubber mallet.This drives
the rivets into tight engagement with the keyhole in
the upright posts to provide a rigid unit.
4. Insure that uprights are leveled at the bottom, and
plumb on all additional sections by using shims
(available from factory) as required. Proper fit of
parts on the additional sections will be adversely
affected if they are not level.This is especially impor-
tant when backs or door units will be added (see
applicable Assembly Instructions).
5. If backs are provided, install the backs before
installing rear shelf supports. If shelf supports are
assembled first, it will be impossible to insert the
back.
6. Door units and ledge tops should be added after
sections have been assembled. See applicable
Assembly Instructions.

Related Instruction Sheets

Before beginning assembly of your shelving, refer to the
following related instruction sheets as applicable .
Aurora Shelving Product
Hinged Doors
Sliding Doors
Assembly Instruction No.
3502
3503
