Sensor-
Operated,
Deck-Mount
Foam Soap
Dispenser
Installation & Operating
Instruction Manual
Thoroughly read this instruction booklet
before installing or operating the Sloan
JANSAN dispenser.
Keep the Installation & Operating
Instruction Manual with other product
information for future reference.
Sensor-Operated Dispenser
SJS-1750 Sensor-Operated, Deck-Mount
Foam Soap Dispenser
Specifications
Width
Height
Depth
Dispenser Rate
Capacity
Specifications are subject to change
without notice.
Table of Contents
Parts/Dimensions
Installation Instructions
Operation
Maintenance/Replacements
Emergency Measures
Consumables
1.65" (42 mm)
4" (102 mm)
4.25" (107mm)
Approximately
1.2 mL per use
1000 mL bottle
Page
2
3-5
6
7
8
8
Advertisement
Table of Contents
Summary of Contents for SLOAN JANSAN SJS-1750
- Page 1 JANSAN dispenser. Deck-Mount Keep the Installation & Operating Foam Soap Instruction Manual with other product information for future reference. Dispenser Sensor-Operated Dispenser SJS-1750 Sensor-Operated, Deck-Mount Foam Soap Dispenser Specifications Width 1.65” (42 mm) Height 4“ (102 mm) Depth 4.25” (107mm)
- Page 2 OVERVIEW OF PARTS AND DIMENSIONS Note: Deck mount foam soap dispenser shown mounted with faucet for reference. Foam soap dispenser Foam soap dispenser Liquid soap and air tubes Foam tank case unit Wiring Power cord...
-
Page 3: Installation
INSTALLATION Check that all parts are included in Choosing Installation Placement original packaging for proper installation. For indoor use only. Do not install in areas with high humidity Package contents: or where the unit may be exposed to Foam soap dispenser (1) direct sunlight. - Page 4 INSTALLATION STEP 3. Foam soap tube Air tube from foam from foam soap soap dispenser Install foam tank case unit to wall dispenser Before installing on the wall, check that no other piping and wiring is running behind hole locations. Wall should sufficiently Tube clamps Foam soap tube reinforced or risk failure due to foam tank...
- Page 5 Connect wiring Protect wire connections Connect the relay harness, which comes Feed the connectors of the relay harness from the bottom of the foam tank base and hand sensor harness into the case unit, with the hand sensor harness, connector case as shown in illustration. which comes from the foam soap After positioning all wiring, fold the dispenser.
-
Page 6: Operation
OPERATION MAINTENANCE Operation Replacing Soap Mount soap bottle to the foam tank case The foam soap indicator light on the unit. Press the reset switch, which begins foam soap dispenser blinks and stops the pumping cycle to purge air from the dispensing when the soap bottle in the tube. - Page 7 Cleaning the hand sensor Cleaning foam soap dispenser Clean the hand sensor periodically (about If the tip of the soap nozzle is clogged, the once a month) according to the following dispensing capability may fail or function procedure: partially. Clean the nozzle according to the following procedure: •...
-
Page 8: Emergency Measures
The information contained in this document is subject to change without notice. For most current information, refer to online installation and operating instruction manuals at www.sloanjansan.com SLOAN JANSAN A Division of Sloan Valve Company 10500 Seymour Avenue Franklin Park, IL 60131-1259...
