  • Page 1 ® USER MANUAL W W W . T R I T O N K E Y M A C H I N E . C O M...
  • Page 2 PLEASE FOLLOW THESE INSTRUCTIONS WHEN USING YOUR TRITON KEY CUTTER: The equipment is designed to be operated at DC24V. The machine will only operate normally at 24VDC. Low/high voltage can harm the machine motor. The cutter should be replaced on a regular basis.

  • Page 3: Table Of Contents

    CONTENTS PAGE Safety ........................4 Power Safety ......................4 Installation Safety ....................4 Usage Safety ......................5 Additional Safety Notes ....................5 Parts ........................6-7 Part Names ......................8-9 Power Adapter ......................10 Specifications ......................11 Consumable Items ....................12-13 Cutter ........................12 Decoder........................13 Key Clamping ......................14-17 Jaw Instructions ......................18 S1 Jaw ........................15 S2 Jaw ........................16 S3 Jaw ........................16...

  • Page 4: Safety

    TRITON KEY MACHINE SAFETY Safety Instructions Make sure to observe the following for using the equipment safely; The information below is provided to enhance the user security awareness and prevent property loss. Read the safety precautions carefully for correct use.

  • Page 5: Usage Safety

    TRITON KEY MACHINE SAFETY Usage Safety The machine cutting bit spins at high speed Placing foreign objects in the cutting area during operation. Keep your body, clothing and must be avoided to prevent potential injury to loose items away from the equipment when machine operator.

  • Page 6: Parts

    TRITON KEY MACHINE Parts P a r t s T r i t o n A u t o m a t i c K e y Cu t t i n g M a c h i n e...
  • Page 7 TRITON KEY MACHINE Parts P a r t s T r i t o n A u t o m a t i c K e y Cu t t i n g M a c h i n e...

  • Page 8: Part Names

    TRITON KEY MACHINE Part Names P a r t s N a m e T r i t o n A u t o m a t i c K e y Cu t t i n g M a c h i n e...
  • Page 9 TRITON KEY MACHINE Part Names (continued...) Power Port (24V/5A) Backup USB Port Power Port ATTENTION • Avoid touching screen with sharp objects, it is easily damaged. • Decoder is a consumable item, replace when damaged. • Handle decoder with care to avoid damaging.

  • Page 10: Power Adapter

    TRITON KEY MACHINE Power Adapter P o w e r A d a p t e r T r i t o n A u t o m a t i c K e y Cu t t i n g M a c h i n e...

  • Page 11: Specifications

    TRITON KEY MACHINE Specifications S p e c i f i c a t i o n T r i t o n A u t o m a t i c K e y Cu t t i n g M a c h i n e Eq u i p m e n t S p e c i f i c a t i o n Equipment Specifications...

  • Page 12: Consumable Items

    TRITON KEY MACHINE Consumables Co n s u m a b l e I t e m s T r i t o n A u t o m a t i c K e y Cu t t i n g M a c h i n e Cutter 1.1 Installation...

  • Page 13: Decoder

    TRITON KEY MACHINE Consumables (continued...) Co n s u m a b l e I t e m s T r i t o n A u t o m a t i c K e y Cu t t i n g M a c h i n e Decoder 2.1 Installation...

  • Page 14: Key Clamping

    TRITON KEY MACHINE Key Clamping K e y F i x a t i o n T r i t o n A u t o m a t i c K e y Cu t t i n g M a c h i n e...

  • Page 15: S1 Jaw

    TRITON KEY MACHINE Key Clamping (continued...) Key Fixation T r i t o n A u t o m a t i c K e y Cu t t i n g M a c h i n e Please avoid the mistakes below when clamping keys:...

  • Page 16: S2 Jaw

    TRITON KEY MACHINE Key Clamping Please avoid the mistakes below when clamping keys: P l e a s e a v o i d b e l o w m i s t a k e s w h e n f i x i n g t h e k e y s...

  • Page 17: S4 Jaw

    TRITON KEY MACHINE Key Clamping (continued...) Please avoid the mistakes below when clamping keys: S4 Jaw - Available for Ford/Jaguar F021 Tibbe keys...

  • Page 18: Jaw Instructions

    TRITON KEY MACHINE Jaw Instructions J a w I n s t r u c t i o n T r i t o n A u t o m a t i c K e y Cu t t i n g M a c h i n e...

  • Page 19: Standard Menu

    TRITON KEY MACHINE Standard Menu S t a n d a r d M e n u T r i t o n A u t o m a t i c K e y Cu t t i n g M a c h i n e...
  • Page 20 TRITON KEY MACHINE Standard Menu (continued...) tandard enu riton utomatic Key Cutting achine nput bitting aw o e numbers nput e isting bitting et bitting numbers to get numbers by key unknown bitting code number Decode key Cut key Collect common...
  • Page 21 TRITON KEY MACHINE Standard Menu (continued...) tandard enu riton utomatic Key Cutting achine Cutter Please insert the cutter shown as picture. ou can ad ust the cutter diameter alue You can manually set the cutting depth when within the range o 2mm, based on the cutting laser keys.

  • Page 22: Jaw Calibration

    TRITON KEY MACHINE Jaw Calibration 1. A u t o m o b i l e K e y J a w ( S 1- A ) 1. Automobile Key Jaw (S1-A) S t e p 1 Step 1. Choose Automobile...
  • Page 23 TRITON KEY MACHINE Jaw Calibration (continued...) 2. A u t o m o b i l e K e y J a w ( S 1- B ) 2. Automobile Key Jaw (S1-B) Step 1. Choose Automobile Ch o o s e A u t o m o b i l e...
  • Page 24 TRITON KEY MACHINE Jaw Calibration 3. A u t o m o b i l e K e y J a w ( S 1- C) 3. Automobile Key Jaw (S1-C) Step 1. Choose Automobile Ch o o s e A u t o m o b i l e...
  • Page 25 TRITON KEY MACHINE Jaw Calibration (continued...) 4. A u t o m o b i l e K e y J a w ( S 1- D ) 4. Automobile Key Jaw (S1-D) Step 1. Choose Automobile Ch o o s e A u t o m o b i l e...
  • Page 26 TRITON KEY MACHINE Jaw Calibration 5. S i n g l e S t a n d a r d K e y J a w ( S 2- A ) 5.Single Standard Key Jaw (S2-A) Step 1. Choose Single...
  • Page 27 TRITON KEY MACHINE Jaw Calibration (continued...) 6. S i n g l e S t a n d a r d K e y J a w ( S 2- B ) 6.Single Standard Key Jaw (S2-B) Step 1. Choose Single...
  • Page 28 TRITON KEY MACHINE Jaw Calibration 7. T u b u l a r K e y J a w ( S 3) 7. Tubular Key Jaw (S3) Step 1. Choose Tubular Key Jaw (S3) Ch o o s e T u b u l a r K e y J a w ( S 3) Step 2.
  • Page 29 TRITON KEY MACHINE Jaw Calibration (continued...) 8. F o r d / J a g u a r T i b b e K e y J a w ( S 4) 8. Ford/Jaguar Tibbe Key Jaw (S4) Step 1.

  • Page 30: Search

    TRITON KEY MACHINE Search Key Blank Search Example: HU66 (Volkswagen, Audi, Skoda) ample olkswagen, udi, koda You can search key data by key blank ou can search key data by key blank (You must be familiar with car key blank in order to use this function.) owe er you ha e to be amiliar with car key blank or using this unction Step 1.

  • Page 31: Ic Card Search

    TRITON KEY MACHINE Search ID Search Example:909 (Volkswagen, Audi, Skoda) ample olkswagen, udi, koda You can search key data by ID ou can search key data by D (You must be familiar with ID from Instacode in order to use this function.) owe er you ha e to be amiliar with D rom nstacode or using this unction Step 1.

  • Page 32: Settings Menu

    TRITON KEY MACHINE Settings Menu anguage Language Step 1. Click button Step 2. Click “Language” button Click anguage button Step 3. Choose the language Choose the you need language you need...

  • Page 33: Software Upgrade

    TRITON KEY MACHINE Settings Menu o tware pgrade Software Upgrade Step 1. Click button Step 2. Click “Software Upgrade” button Click o tware pgrade button Step 3. Click upgrade Click “Upgrade” button to upgrade button to upgrade your e uipment...

  • Page 34: Cutting Speed

    TRITON KEY MACHINE Settings Menu Cutting peed Cutting Speed Step 1. Click button Step 2. Click ettings Click “Settings” button button Step 3. Click “Cutting Speed” button Click Cutting peed” button Step 4. lide progress bar to Slide progress bar to...
  • Page 35 TRITON KEY MACHINE Settings Menu thers Shield Override Step 1. Click button Step 2. Click ettings Click “Settings” button button Step 3. Click “Others” button Click thers button Step 4. Slide to “On” to allow shield to be open during cutting...

  • Page 36: About Us

    TRITON KEY MACHINE Settings Menu bout s About Us Step 1. Click button Step 2. Click “About Us” button Click bout s button Step 3. View details of “About Us” iew details o bout s”...

  • Page 37: Key Decoding

    TRITON KEY MACHINE Key Decoding Key Decoding Key Decoding Step 1. Click button Step 2. 1. Confirm key’s position 2. Place the decoder shown 1. Confirm key’s position as picture 2. Place the decoder as shown in picture 3. Click ”Decode” button 3.

  • Page 38: Key Cutting

    TRITON KEY MACHINE Key Cutting Ex a m p l e : A u d i Q 7 Example: Audi Q7 (Input known bitting numbers to cut a key when the original key is lost) ( I n p u t k n o w n b i t t i n g n u m b e r s t o c u t a k e y w h e n t h e o r i g i n a l k e y i s l o s t ) Step 1.
  • Page 39 TRITON KEY MACHINE Key Cutting Ex a m p l e : A u d i Q 7 Example: Audi Q7 (cont.) (Input known bitting numbers to cut a key when the original key is lost) ( I n p u t k n o w n b i t t i n g n u m b e r s t o c u t a k e y w h e n t h e o r i g i n a l k e y i s l o s t ) Step 5.

  • Page 40: Cutting Depth Adjustment

    TRITON KEY MACHINE Cutting Depth Adjustment Ex a m p l e : H o n d a A c c o r d Example: Honda Accord Step 1. Click button on Home Page Step 2. Choose “Honda” in the list Ch o o s e “...
  • Page 41 TRITON KEY MACHINE Cutting Depth Adjustment Ex a m p l e : H o n d a A c c o r d Example: Honda Accord (cont.) Step 4. Ch o o s e t h e y e a r o f...

  • Page 42: Layered Cutting

    TRITON KEY MACHINE Layered Cutting Example: Audi Q7 Ex a m p l e : A u d i Q 7 (Input known bitting numbers to cut a key when the original key is lost) ( I n p u t k n o w n b i t t i n g n u m b e r s t o c u t a k e y w h e n t h e o r i g i n a l k e y i s l o s t ) Step 1.
  • Page 43 TRITON KEY MACHINE Layered Cutting Example: Audi Q7 Ex a m p l e : A u d i Q 7 (cont.) (Input known bitting numbers to cut a key when the original key is lost) ( I n p u t k n o w n b i t t i n g n u m b e r s t o c u t a k e y w h e n t h e o r i g i n a l k e y i s l o s t ) Step 4.

  • Page 44: Move

    TRITON KEY MACHINE Move Example: Audi Q7 Ex a m p l e : A u d i Q 7 (Input known bitting numbers to cut a key when the original key is lost) ( I n p u t k n o w n b i t t i n g n u m b e r s t o c u t a k e y w h e n t h e o r i g i n a l k e y i s l o s t ) Step 1.
  • Page 45 TRITON KEY MACHINE Move Example: Audi Q7 Ex a m p l e : A u d i Q 7 (cont.) (Input known bitting numbers to cut a key when the original key is lost) ( I n p u t k n o w n b i t t i n g n u m b e r s t o c u t a k e y w h e n t h e o r i g i n a l k e y i s l o s t ) Step 4.

  • Page 46: Code

    TRITON KEY MACHINE Code Ex a m p l e : H o n d a A c c o r d Example: Honda Accord (How to cut a key when original key is lost) ( H o w t o c u t a k e y w h e n o r i g i n a l k e y i s l o s t ) Step 1.
  • Page 47 TRITON KEY MACHINE Code Ex a m p l e : H o n d a A c c o r d Example: Honda Accord (cont.) (How to cut a key when original key is lost) ( H o w t o c u t a k e y w h e n o r i g i n a l k e y i s l o s t ) Step 4.

  • Page 48: Progression

    TRITON KEY MACHINE Progression Ex a m p l e : A u d i - Q 7 Example: Audi-Q7 Step 1. Click button on Home Page Ch o o s e " A u d i " i n t h e l i s t Step 2.
  • Page 49 TRITON KEY MACHINE Progression Ex a m p l e : A u d i - Q 7 Example: Audi Q7 (cont.) Step 5. Click button Step 6. Ex a m p l e : I n p u t k n o w n b i t t i n g Example: Input known bitting n u m b e r s "...

  • Page 50: Duplicate

    TRITON KEY MACHINE Duplicate S i n g l e S t a n d a r d K e y Single Standard Key Step 1. Step 2. Click “Duplicate” Click “Single Cl i c k “ D u p l i c a t e ”...

  • Page 51: Double Standard Key

    TRITON KEY MACHINE Duplicate D o u b l e S t a n d a r d K e y Double Standard Key Step 1. Step 2. Click “Duplicate” Click “Double Cl i c k “ D u p l i c a t e ”...

  • Page 52: Single External Groove Key

    TRITON KEY MACHINE Duplicate S i n g l e Ex t e r n a l G r o o v e K e y Single External Groove Key Step 1. Step 2. Click “Duplicate” Click “Single External Cl i c k “ D u p l i c a t e ”...

  • Page 53: Double External Groove Key

    TRITON KEY MACHINE Duplicate D o u b l e Ex t e r n a l G r o o v e k e y Double Exernal Groove Key Step 1. Step 2. Click “Duplicate” Click “Double External Cl i c k “ D u p l i c a t e ”...

  • Page 54: Internal Groove

    TRITON KEY MACHINE Duplicate I n t e r n a l G r o o v e K e y Internal Groove Key Step 1. Step 2. Click “Duplicate” Click “Internal Cl i c k “ D u p l i c a t e ”...

  • Page 55: Tubular Key

    TRITON KEY MACHINE Duplicate T u b u l a r K e y Tubular Key (continued...) Step 1. Step 2. Click “Duplicate” Click “Tubular” button Cl i c k “ D u p l i c a t e ”...
  • Page 56 TRITON KEY MACHINE Custom Keys D o u b l e S t a n d a r d K e y Double Standard Key Step 1. Step 2. Click “Custom Keys” Click “Add New Key” button Cl i c k “ Cu s t o m K e y s ”...
  • Page 57 TRITON KEY MACHINE Custom Keys (continued...) Step 6. Step 7. Input the parameters in space Input the parameters width of the key and click in depth of the key “Next” button and click “Next” button Step 8. Step 9. Input the parameters in width Choose correct “Jaw”...
  • Page 58 TRITON KEY MACHINE Custom Keys S i n g l e I n t e r n a l G r o o v e K e y Single Internal Groove Key Step 1. Step 2. Click “Custom Keys” Click “Add New Key” button button on Home Page Step 3.
  • Page 59 TRITON KEY MACHINE Custom Keys (continued...) Step 6. Step 7. Input the parameters in space Input the parameters width of the key and click in depth of the key “Next” button and click “Next” button Step 8. Step 9. Input the parameters in Width, Choose correct “Jaw”...
  • Page 60 TRITON KEY MACHINE Custom Keys D o u b l e I n t e r n a l G r o o v e K e y Double Internal Groove Key Step 1. Step 2. Click “Custom Keys” Click “Add New Key” button button on Home Page Step 3.
  • Page 61 TRITON KEY MACHINE Custom Keys (continued...) Step 6. Step 7. Input the parameters in space Input the parameters width of the key and click in depth of the key “Next” button and click “Next” button Step 8. Step 9. Input the parameters in Width, Choose correct “Jaw”...
  • Page 62 TRITON KEY MACHINE Custom Keys Dimple Key Step 1. Step 2. Click “Custom Keys” Click “Add New Key” button button on Home Page Step 3. Step 4. Click “Dimple” button, then Click “Shoulder” button, “Next” button then “Next” button Step 5.
  • Page 63 TRITON KEY MACHINE Custom Keys (continued...) S t e p 7 Step 6. Step 7. Input the parameters in depth of Input the parameters the key and click “Next” button in Width & Thickness and click “Next” button Step 8.
  • Page 64 TRITON KEY MACHINE Custom Keys Single Standard Key Step 1. Step 2. Click “Custom Keys” Click “Add New Key” button button on Home Page Step 3. Step 4. Click “Single Standard” button, Click “Shoulder” button, then “Next” button then “Next” button Step 5.
  • Page 65 TRITON KEY MACHINE Custom Keys (continued...) Step 6. Step 7. Input the parameters in space Input the parameters width of the key and click “Next” in depth of the key and button click “Next” button Step 8. Step 9. Input the parameters Name the new key data and in Width and click “Next”...
  • Page 66 TRITON KEY MACHINE Custom Keys Single External Groove Key Step 1. Step 2. Click “Custom Keys” Click “Add New Key” button button on Home Page Step 3. Step 4. Click “Single External Groove Click “Shoulder” button, Key” button, then “Next” button then “Next”...
  • Page 67 TRITON KEY MACHINE Custom Keys (continued...) Step 6. Step 7. Input the parameters in space Input the parameters width of the key and click in depth of the key “Next” button and click “Next” button Step 8. Step 9. Input the parameters in Width, Choose correct “Jaw”...
  • Page 68 TRITON KEY MACHINE Custom Keys Double External Groove Key Step 1. Step 2. Click “Custom Keys” Click “Add New Key” button button on Home Page Step 3. Step 4. Click “Double External Groove Click “Shoulder” button, Key” button, then “Next” button then “Next”...

  • Page 69: Custom Keys

    TRITON KEY MACHINE Custom Keys (continued...) Step 6. Step 7. Input the parameters in space Input the parameters width of the key and click in depth of the key “Next” button and click “Next” button Step 8. Step 9. Input the parameters in Width, Choose correct “Jaw”...
  • Page 70 TRITON KEY MACHINE Custom Keys Tubular Key Step 1. Step 2. Click “Custom Keys” Click “Add New Key” button button on Home Page Step 3. Step 4. Click “Tubular” button, then Input the parameters in “Next” button space location of the key and click “Next”...
  • Page 71 TRITON KEY MACHINE Custom Keys (continued...) Step 6. Step 7. Input the parameters in Width, Name the new key data Thickness, Cut Depth and click and click “OK” button “Next” button Step 8. Review the key data you just added...

  • Page 72: Favorites

    TRITON KEY MACHINE Favorites/Cut History F a v o r i t e s Favorites You can check what keys you’ve saved before. Cu t H i s t o r y Cut History You can check what keys you’ve cut before.

  • Page 73: Wifi Connection

    TRITON KEY MACHINE WIFI Connection WIFI Connection Step 1. Click “Set Up” button on Desktop Step 2. Click “WLAN” button Choose the available WIFI connections shown in the list Step 3. Step 4. Input password and click “Connect” button...

  • Page 74: Software Activation

    TRITON KEY MACHINE Software Activation Software Activation Step 1. Open the software and log in Serial Number and Registration code Step 2. Find the label on the back cover of the equipment. The serial number and registration code are there.

  • Page 75: Warranty

    DISCLAIMED, THE IMPLIED WARRANTIES ARE LIMITED IN DURATION TO THE LIFE OF THE EXPRESS WARRANTY. LOCK LABS SHALL HAVE NO LIABILITY FOR INCIDENTAL AND CONSEQUENTIAL DAMAGES THAT ARISE FROM THE SALE OF TRITON TM PRODUCTS OR ARE A RESULT OF A BREACH OF THE LIMITED MANUFACTURER’S WARRANTY REPRODUCED ABOVE.
  • Page 76 ® W W W . T R I T O N K E Y M A C H I N E . C O M 5275 S. Ar ville Street Ste. 328 Las Vegas, NV 89118 Tel: (855) 562-5522 Email: info@lock-labs.com...
