Summary of Contents for Gecko Infento
- Page 1 YEARS GECKO CONSTRUCTION MANUAL Length 97 - 133 cm / 38 - 52 inch Max weight 37 kg / 81 lbs Time to build 1,5 hour...
-
Page 2: Safety Warning
WARNING - IMPORTANT NOTICE TO PARENTS Before you start constructing and use our product, please carefully read the following safety warning and download our manual from our website. This safety warning and manual contains important informa- tion relating to your child’s safety. It is your responsibility to review this information with your child and make sure they are fully aware of all the warnings before they start riding. - Page 3 Wet we- 30. Only one rider at a time on an Infento ride. diff er from the offi cial rides that we show in our ather impairs traction, braking and visibility.
-
Page 4: Maintenance
SECTION SAFETY OUR KITS CONTAIN SMALL PARTS This package contains small parts which, before assembly, present a choking hazard to children under the age of three. Care should be taken during unpacking and assembly to insure that all small parts and plastic bags are accounted for and kept out of the reach of children. - Page 5 Profi le nut short holes without threa T-Positioning block 12.60 inch | 320 mm 14.17 inch | 360 mm ride GECKO First, get all required materials stated here and then follow the instructions. 2.91” | 74 mm 4.06” | 103 mm Tighten the bolts with full force.
- Page 6 TOP 3 REQUIREMENTS MAKING A GREAT INFENTO EXPERIENCE: Tighten bolts with full force (15Nm) to prevent them from coming loose. Constructing and playing always under supervision of an adult. Check frequently if all parts are still fi rmly tightened and function...
- Page 7 Multi angle joint Profi le nut short holes without threa T-Positioning block 11.02 inch | 280 mm 12.60 inch | 320 mm ride GECKO If your protect cap has a hole, use a M8x12 countersunk bolt to fasten it When tightening the bolt always check whether the profi...
- Page 8 40x40_8 T-Positioning block Knurled disc 2 stripes Bolt M8x20 nylock Knurled disc 2 stripes Bolt M8x35 ride GECKO Depending on your Kit, the knurled discs can be of There are two types of a diff erent type, knurled discs. Please looking like this: see education section.
- Page 9 (low head) 70S gray L-joint T-Positioning block Parrellel clamp joint ride GECKO TIP! It is best to tighten the bolt in such a way that you can still move the block and easily deter- mine the right position with a tape measure.
- Page 10 If not, please skip to the next page of the manual. Nock washer M8-16 ride GECKO This is the 4’’ Swivel Wheelhouse. Before being able to use this part, you need two Nock Washers M8-16.
- Page 11 Swivel fork Swivel fork Locknut M8 Bolt M8x45 4 inch wheel 4 inch wheel 4 inch wheel ride GECKO check If your Swivel Fork 4’’ Wheel contains a metal bearing on top (instead of a red plastic ring), you can skip this step! V 1.8...
- Page 12 9.15 inch | 232.4 mm Connector Metal spacer Bolt M8x20 nylock Swivel fork Swivel fork 4 in | 2000 mm 4 inch wheel house (low head Washer M8-24 Positioning block 4 inch wheel 4 inch wheel ride GECKO V 1.8...
- Page 13 Bearing b Locknut M8 Positioning block Bolt M8x60 40x40_H ride GECKO If you look carefully you can see that the sides of the profi le slope slightly inwards. If you tighten a bolt securely the profi le will be pulled fl ush against the block so the profi...
- Page 14 4 inch wheel house (low head Locknut M8 Bolt M8x45 4 inch wheel 4 inch wheel 4 inch wheel ride GECKO check If your Swivel Fork 4’’ Wheel contains a metal bearing on top (instead of a red plastic ring), you can skip this step! V 1.8...
- Page 15 Positioning block Multi angle joint holes without threa .56 inch | 192 mm 9.15 inch | 232.4 mm Connector Swivel fork Swivel fork Washer M8-24 Positioning block 4 inch wheel 4 inch wheel ride GECKO V 1.8...
- Page 16 T-Positioning block Multi angle joint holes without threa Locknut M6 Bearing b Locknut M8 Positioning block Bolt M8x60 40x40_H ride GECKO V 1.8...
- Page 17 3.15 inch | 80 mm Parrellel clamp joint ride GECKO Most nuts that you use for Infento are self-locking. This means that they cannot vibrate loose. On the inside of the bolt you will see a plastic washer that ensures it cannot turn freely, even if there is no tension on the bolt.
- Page 18 Profi le nut short T-Positioning block L-joint Parrellel clamp joint ride GECKO The plastic parts of Infento are made using injection moul- ding technology where molten plastic is pressed under high pressure into a mould. A mould consists of steel blocks in which a shape is recessed.
- Page 19 If not, please skip to the next page of the manual. Nock washer M8-16 ride GECKO This is the U-block. Before being able to use this part, you need two Nock Washers M8-16. Press these washers into the slots.
- Page 20 U-Block T-Positioning block ride GECKO 2.36” | 60 mm The positioning blocks are some of the smallest Infento parts but they are also some of the most important. They ensure that everything connects to each other properly. This prevents parts from twisting and com- ing loose when under pressure.
- Page 21 Locknut M6 Brake caliper holder Bolt M6x25 T-Positioning block 1.57 inch | 40 mm Bolt M8x20 nylock Axle clamp ride GECKO Use the Allen key handle so you can tighten the bolt well. Leave a gap of at least 0.5mm when tightening the bolts.
- Page 22 Bolt M6x25 extension Angle limiter Locknut M8 Bolt M8x60 Washer M8-16 40º pulley protection 28T ride GECKO If your U-block or Kit doesn’t have the M8-16 Nock Washers, you can use the regular M8-16 washers as shown here. V 1.8...
- Page 23 .37 in | 1000 mm 59.06 in | 1500 mm Brake caliper holder Bolt M6x25 4 mm 12.95 inch | 329 mm onnector Swivel fork Bolt M8x40 nylock Washer M8-16 pulley protection 28T 4 inch wheel 4 inch wheel ride GECKO V 1.8...
- Page 24 Handgrip Adjusting bolt Handlebar short M8x35 Protect cap Profi le nut short Axle plate T-Positioning block ride GECKO V 1.8...
- Page 25 Square nut M6 Bolt M6x50 Seatboard Filler Seatboard Base ride GECKO If you have this type of seat in your Kit, please skip to the next page. If not, follow the instructions below to construct your seatboard. Put the M6...
- Page 26 (low head) Ducktail board Bolt M8x20 Profi le nut short extension + foam ride GECKO V 1.8...
- Page 27 28T Handgrip ride GECKO V 1.8...
- Page 28 Bolt M8x20 nylock Word mark ride GECKO V 1.8...
- Page 29 GECKO THANK YOU FOR READING ME!
