SSV Works US-CMP65 Quick Start Manual

SSV WORKS, 201 N. Rice Ave Unit A, Oxnard, CA 93030
www.SSVworks.com | Phone: 818-991-1778 | Fax: 866-293-6751

WARRANTY INFORMATION:

All SSV Works enclosures are covered by a limited lifetime warranty against defects in
material or workmanship. All SSV Works Electronics are covered by a limited 1 year
warranty against defects in material or workmanship. Labor for replacement of defective
components is not covered. All SSV Works Speakers are covered by a limited 1 year
warranty against defects in material or workmanship. Contact SSV Works for further
warranty information.

TOOLS NEEDED FOR INSTALLATION

- Wire Crimpers
- Wire Strippers
- 4mm and 5mm Allen
Wrench
PARTS LIST IMAGES
1. US-CMP65 Enclosures
(1 pair)
6. Clamp Base x2

INSTALLATION NOTES

The use of a thread locker is recommended on all screws to prevent loosening due to vibration. It is recommended to wrap the bag that the clamps
come in around the cage before you slide the clamp onto the cage, this will prevent scratching.
- Drill with 1/4" Drill bit
- #3 Phillips Screwdriver
- Scribe or Marker
2. M6 x 1.0 Screws x 4
7. Mounting Clamp x 2 8. 1 - 3/4" Allen Socket

PARTS LIST

1. US-CMP65 Enclosures (1 pair)
2. M6 x 1.0 Screws x 4
3. M6 Washers x 4
4. Mounting Disc x 2
5. 1/2" Allen Screw x 4
3. M6 Washers x 4 4. Mounting Disc x 2
Head and Washer x 2
US-CMP65
Universal Cage Mount
6.5" Speaker Enclosures
Please read and understand these
!
instructions completely before
installation to avoid possible injury, or
damage to the accessory or vehicle.
6. Clamp Base x2
7. Mounting Clamp x 2
8. 1 - 3/4" Allen Socket
Head x 2
9. 5/16" Nut x 2
5. 1/2" Allen Screw x 4
6. 5/16" Nut x 2
