FOURSTEEL DOMOTIC TOUCH Instruction Manual

DOMOTIC TOUCH
The Domotic Touch is a simple solution with installation parameters
of a simple switch.
Economic functionality
Increases energy e ciency by programming the number of hours of
operation (1, 2 or 3 hours).
Comfort functionality
Allows rationalization of energy expenses by the temperature control
functionality (18ºC, 20ºC, 22ºC, 24ºC).
Thanks to its room temperature sensor this function allows you to
select the desired temperature for your comfort.
Flexibility
The Domotic Touch allows one or more electric radiators / towel
warmers to be controlled on the same room, until a maximum power
of 2000W.
ON / OFF
Press 2 seconds
The panel switches on when the icon ON/OFF is pressed for 2 seconds.

WARMING AND DRYING TOWELS

Press 2 seconds - continuous operation for 1, 2 or 3 hours.
In this function, the towel warmer switches on and works until
reaching the operation time of 1, 2 or 3 hours, according to the
programs I, II or III.
During the selection process, the radiator icon blinks while the
programmed functions are being detected.
In the program I the radiator works for 1 hour and switches o
automatically by the end of that period of time. This procedure is
the same for the program II (2 hours) and III (3 hours).

OPERATION MODE

Whenever there is touch contact with the panel when the
device is not working, the LED ON/OFF turns on.
Whenever there is touch contact with the panel when the
device is working, the LED light of the operating program stays
lit up.
For security reasons, to select a di erent operation mode, the
corresponding icon must be pressed for 2 seconds to activate
the operation.
Operation can be stopped at any moment by pressing the LED
ON/OFF for 2 seconds.
DUTY-CYCLE ON MODE INDICATOR

MODE DUTY-CYCLE

Press +5 seconds - Activating the mode Duty-cycle
Function to use for a more customized control equipment
temperature.
The activation of this mode is shown by the light indicator
above the icon.
Operation timed at 25%,50%, 75% and 100% per 20 minute
period.
18º = 25% (5 minutes ON / 15 minutes OFF, ...)
20º = 50% (10 minutes ON / 10 minutes OFF, ...)
22º = 75% (15 minutes ON / 5 minutes OFF, ...)
24º = 100% (continuous operation)

ROOM TEMPERATURE CONTROL

Press 2 seconds - Activating the temperature control
During the selection process, the ambient icon and the tempe-
ratures' values blink while the programmed functions are being
detected.
The sensor reads the room temperature according to the
selected LED, between 18ºC and 24ºC.
