Summary of Contents for Adcom HD2SDIS
- Page 1 HD2SDIS GENLOCK User Manual Ver. 1.1...
-
Page 2: Table Of Contents
Content Feature ................... 3 Front Panel ................4 Rear Panel ................4 Side Panel ................5 Button/LED Indicate ..............6 Genlock mode ................9 Installation ................10 Package Contents ..............10 Specifications ................11 Firmware Upload ..............13... -
Page 3: Feature
Feature SDI Supports HD formats : 720p50 & 60 1080i50 & 60 1080p24, 25, 30, 50 & 60 SDI Support 525i & 625i SD D1 format Auto 3G/HD/SD-SDI detection One HDMI input source can split to two 3G-SDI displays simultaneously. ... -
Page 4: Front Panel
Front Panel Component Function From your SDI Display Device plug into SDI Output Port these ports ( Pass Through) The LEDs is indicate Output Format LEDs indicate (SD/HD/3G/Power) Mode Buttons Select Format/TV Wall/TV Ratio Rear Panel Component Function Power Jack The Power adapter plug into here. -
Page 5: Side Panel
Side Panel Component Function USB Connector Upgrade Firmware/Control Box by PC... -
Page 6: Button/Led Indicate
Button/LED Indicate 1. Switch Format: Chick the button 1, the box will be setting to Output Format Mode and change Frame Rate by button 2 and 3. FRAME RATE FRACTION By Pass 720x480 B -59.94i (BT.656) C- 59.94i (CEA-861) 720x576 59.94p 1280x720 59.94i... - Page 7 2. Aspect Ratio Mode: Check the button 3 , the box will be seting to Aspect Ratio Mode Mode Display 16:9 (Default) (dot by dot) 3. Function Button Mode: Hold on the button 3 until show the Func button Mode Unlock Lock FUNC BUTTON...
- Page 8 4. LED Mode: Resolution SD LED HD LED 3G LED HDCP LED ● ○ ○ ○ NTSC / PAL 720p / 1080i / ○ ● ○ ○ 1080 [24p, 25p, 30p] ○ ○ ● ○ 1080 [50p,60p] ○ ○ ○ ●...
-
Page 9: Genlock Mode
Genlock mode 480i 576i 1080 1080 1080 1080 1080 1080 480i ● ● ● ● ● 576i ● ● ● ● ● 720p ● ● 720p ● ● 720p ● ● 1080i ● ● ● ● 1080i ● ● ● ●... -
Page 10: Installation
2. Connect Video Source (HDMI) to the HDMI Connector. 3. Connect SDI Equipment to the BNCs connector 4. Connect the +12DC adaptor to the converter. Package Contents The HD2SDIS-GENLCOK package contains the following items: User Manual x 1 ... -
Page 11: Specifications
Specifications DESCRIPTION SDI Format SD-SDI, HD-SDI & 3G-SDI SDI Transition Rate 2.970Gb/s, 1.485Gb/s and 270Mb/s Audio Support Stereo 2-Channel Audio Sample Auto Ra-sample to 48Khz (For Stereo) RG6/RG59(75Ω) Coaxial Cable Type 3G: 100m of RG6/ 86m of RG59 HD: 170m of RG6/ 120m of RG59 SD: 400m of RG6/ 280m of RG59... - Page 12 Support CEA-861/VESA Format 720x480i60 720x576i50 720x480 p60 720x576 p50 1280x720p60 1280x720p50 1920x1080i60 1920x1080i50 1920x1080p24 1920x1080p25 1920x1080p30 1920x1080p60 1920x1080p50 640x350p85 640x400p85 720x400p85 640x480p60 640x480p72 640x480p75 640x480p85 800x600p56 800x600p60 800x600p72 800x600p75 800x600p85 848x480p60 1024x768p50 1024x768p59 1024x768p60 1024x768p70 1024x768p75 1024x768p85 1152x864p70 1152x864p75 1280x768pRB 1280x768p60 1280x768p75...
-
Page 13: Firmware Upload
Firmware Upload Firmware is upgradable in the field using the integrated USB port How to Firmware upgrade: Step 1. Open Upload Firmware Program tools.exe and connect box to PC by USB Cable. Step 2. Plug and un-plug “DC adapter” to power on/off the converter box (the connection check status will be changed to “Connect”) - Page 14 Step 3. Plug and un-plug “DC adapter” again (the connection check status will be changed to “Connected”) and Please click the Open File button to select the firmware bin file. Step 4. Please click “Start’ Button to proceed with new firmware programming. PASS message will appear when the procedures finished.
