UV-SA
367-5455
INSTALLATION INSTRUCTIONS

Check List for Quick Set-Up

A�ach bracketry according to instruc�ons found in this guide. See contents below.
A�ach the power cable to the circular jack
Power the device by plugging in the opposite end of the power cable to the
USB 3.0
supplied adapter, or another
Set-Up is complete.
Stand
Short
Screw
Tray
(X2)
SAFETY & DISPOSAL
Appropriate use of this product is expected and is the responsibility of the purchaser of this product.
This product uses UV-C light. Eyes and skin should be kept from exposure.
Eye inflamma�on and skin irrita�on can occur from prolonged exposure. For sensi�ve skin, burns may occur.
Do not touch the glass UV bulb surface. Fingerprints create a barrier and reduce UV ability.
Do not use this device on people, food, or pets.
Keep out of Reach of Children. This product is not a toy.
Do not a�empt to disassemble this product. Nor is it serviceable. Warranty will be void.
This UV bulb contains mercury in very small amounts. Precau�ons should be used to prevent breakage.
Mercury may cause injury if swallowed and is known to cause reproduc�ve harm.
Dispose of this product responsibly per regula�ons.
Do not expose this product to water, liquids or moisture. Electricity is present.
UV-C can discolor materials such as plas�c and fabric over a period of �me.

UV Bulb

Breakage: All visible bulb components should be cau�onarily swept into a sealable bag, box or jar and taken
outdoors.
Cau�on: The UV bulb contains a very small amount of mercury.
As suggested by the EPA, do not vacuum up broken glass unless it is the only remaining debris. The same
steps used to clean-up common CFL's may be used for this UV bulb.
As listed here: h�ps://www.epa.gov/cfl/cleaning-broken-cfl
Recycling may be an op�on in your area. www.lamprecycle.org/state-local-laws
When done, this prevents mercury from entering the environment and reuse of glass, and metal is possible.
Refuse collec�on can be handled by commercial waste contractors, municipali�es, or other local household
waste programs.
on the back of the UV-Clean unit.
4
device with output power of 900 mA.
Micro-USB
Data Cable
5mm , USB-A
Power Cable
DC 5V Power Supply
3/32" Allen Key
Cable Tie
UV-C Unit
1
2
Front View
1. Status
2. Mo�on Sensor
Indicator
White = On, Stand By
Detec�on for
Blue = Cleaning
UV auto shut-off
feature
Blue Blink = Bulb Failure
White = On, Stand By
Internal Clock Ba�ery
Ba�ery disposal is controlled by law and requires proper ac�on.
Recycling and Refuse collec�on can be handled by commercial waste contractors, municipali�es,
or other local household waste programs.
Resources
Locate centers near you: search.earth911.com
EPA www.epa.gov
Federal Universal Waste Rule

Maintenance

Do not a�empt to service this product. Contact customer service at Proximity Systems for guidance.
Do not subject the bulb to fingerprints, solvents or abrasion.
Cleaning the bulb with a damp cloth or lens �ssue is advised when the unit is not plugged in and the
device is at room temperature only.
Environmental Condi�ons for Opera�on

Designed For

1. Commercial, Indoor use only
2. Al�tude up to 3050m
3. Working temperature: 20 - 27 degrees C (68-80 deg F). Humidity 20-90% (non-condensing).
Storage temperature: 15 - 55 degrees C (59-130 deg F). Humidity <85% (non-condensing).
4
3
5
3. Push Bu�on
4. Power
For Task Light
Receptacle
Control the on/off
DC 5V supply
of the LED task Light
included, 5mm jack
Blue = Cleaning
Blue Blink = Bulb Failure
www.lamprecycle.org
batteryresponsibility.org/battery-recycling
Rear View
5. Micro-USB
Data
Receptacle
Retrieve cleaning
cycle informa�on
stored internally
