P24M300 user's manual
Caution:
1. Thank you for purchasing the PolarPlus P24M300. Please refer to
the manual before installation;
2. The installation should be done by the experienced technicians.
Please refer to the manual strictly;
3. Do not open the generator or controller without instructions while
doing the maintenance.
4. Please install the system under no-wind weather.
5. The series are street lighting wind generators and do not
recommend for family power generation.
Advertisement
Summary of Contents for PolarPlus P24M300
- Page 1 P24M300 user's manual Caution: 1. Thank you for purchasing the PolarPlus P24M300. Please refer to the manual before installation; 2. The installation should be done by the experienced technicians. Please refer to the manual strictly; 3. Do not open the generator or controller without instructions while doing the maintenance.
- Page 2 1. Technical Parameter Model P24M300 Rated Power(W) Rated Voltage（DCV） Start-up wind speed （M/S） Survival wind speed（M/S） Generator type Rotor diameter（M） 0.82 Blade No.（pcs） Blade material Plastic Housing material Aluminum alloy Controller Built-in Slip ring type Sealed/water proof Over charging protection short circuit Designed lifetime（year）...
- Page 3 3. Structure Description Description Front cover Gyro support Blades Gyro Stator Pressing plate Back cover Back nose cone Clamp Tail vane Slip ring...
- Page 4 4. Installation ⚫ Connect the cables with the terminal from generator. Please pay attention to the positive and negative. The cable will be elicited from the tower. ⚫ Connect the small pole and tower with 4 pcs of nuts (M 10*16 ). ⚫...
- Page 5 ⚫ Fasten the tail rod, rod plate and gyrator with 4 pcs of screws (M6*30). ⚫ Fasten the gyrator front cover to the back cover via 3 pcs of bolts (M5*10).
- Page 6 ⚫ Connect the cable elicited from generator to the battery. (Note: red for positive and black for negative) 3. Special note: Connection diagram between wind generator and pole...
- Page 7 1. Connect small pole and pipe (48*2.5mm diameter). 2. Drill 2 pcs of symmetrical screw holes (12mm diameter) above a diatance of 20mm at the upper end of pipe. 3. Clockwise 90°in the hole above the distance of 20mm, and drill 2 pcs of symmetrical screw holes (12mm diameter) above a diatance of 38mm at the upper end of pipe.
