Summary of Contents for Photoneo Bin Picking Studio
- Page 1 Bin Picking Studio Quick Start Guide...
-
Page 2: Scope Of Delivery
Scope of Delivery Vision Controller - industrial-grade device Pre-installed Bin Picking Studio software Power adapter (230VAC/20VDC, 60W) Power cable with an EU plug Power connector Power DC Cables 2 / 12... - Page 3 Operation of the Bin Picking Studio The Bin Picking Studio is operated through the Vision Controller. First, you need to plug the Vision Controller into a power outlet using the provided cables. To work with the Vision Controller, you need to connect the monitor, keyboard, and mouse (like a standard desktop).
- Page 4 Vision Controller. When the Vision Controller is booted up, the Bin Picking Studio application will launch automatically. When Bin Picking Studio runs for the first time, a Welcome Page appears, which will guide you through the initial setup of BPS. 4 / 12...
- Page 5 Firstly you will be asked to select your local timezone, either by clicking on the map or by selecting it from the list. 5 / 12...
- Page 6 After selecting your timezone, you will be prompted to create a Master account. This account serves to manage Bin Picking Studio from your side. It allows full usage and setup of BPS solutions, plus access to employee user management. In the next step, you will see a form to create any number of Employee accounts, which have basic access to BPS solutions.
- Page 7 After finishing this initial setup, your BPS installation will have one Master account and any number of Employee accounts (optional). Connection to the scanner and robot To connect the VC to the scanner and robot, please use 1 Gbit ethernet cable - RJ45 (not included) and connect them to the following ports (Figure 4).
- Page 8 ■ Network port (internet) ■ Fig. 5. Bin Picking Studio product topology When the robot and scanner are connected to the VC, you need to set up their IP addresses (both are mandatory) on the Network page (Figure 6) of the Bin Picking Studio.
- Page 9 Documentation page (Figure 7). To obtain a robotic package for a specific brand (modules and robot program), please contact support@photoneo.com Fig. 7. Documentation page overview 9 / 12...
-
Page 10: Remote Support
(must be duplicated). Remote support Photoneo offers remote support for its customers. To connect to your Vision Controller, it needs to be connected to the internet (through the Network port). Your Vision Controller comes with a pre-installed TeamViewer. - Page 11 Fig. 8. TeamViewer login credentials 11 / 12...
- Page 12 Contact us www.photoneo.com support@photoneo.com Support sales@photoneo.com Business Inquiries Headquarters Plynárenská 1 82109 Bratislava Photoneo s.r.o. Slovakia 12 / 12...
