- Page 1 SatFi CONTROLBOX+CONTROLPANEL INSTALLATION MANUAL...
- Page 2 SatFi INSTALLATION MANUAL...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Page GENERAL ........................4 IMPORTANT SAFETY INSTRUCTIONS ..............4 BEFORE STARTING THE INSTALLATION ..............4 TOOL LIST ........................5 MECHANICAL INSTALLATION ..................5 ELECTRICAL INSTALLATION ..................9 CONNECTION DIAGRAM ..................10 OPERATING OF THE SYSTEM ................. 10... -
Page 4: General
Thank you for purchasing our SatFi automatic satellite dome. GENERAL SatFi satellite domes are designed to be used for receiving and watching satellite TV and radio broadcasts on caravans, motorhomes, RV's, narrowboats, passenger coaches, minibuses, trucks and lorries. IMPORTANT SAFETY INSTRUCTIONS Do not open the cover of the unit. -
Page 5: Tool List
De-greasing alcohol. 3. It is very important to install the SatFi antenna on the top of the vehicle to the most convenient place. The mounting place of the antenna on the vehicle should be flat, not worn or weathered and far away from the physical obstacles like air conditioner or ventilation parts of the vehicle. - Page 6 SatFi Antenna installation may be done in two different ways. I. Installation on the vehicle roof 1. SatFi antenna is carried to the top of the vehicle carefully whenever possible remaining horizontal. The SatFi antenna should be placed on the most convenient area on the top of the vehicle.
- Page 7 If surface of the vehicle is curved, left and right side feet of the antenna are not in contact with the roof surface. In such cases wedges/spacers in the proper width should be used to fill the gaps. 3. 4 pieces of 3.9x32 stainless screws and M5 washers that are included with the antenna. Using the screws with washers should be screwed loosely into the side feet of the antenna leaving sufficient space.
- Page 8 II. Installation on the vehicle roof 1. Ensure sufficient space for the installation holes and use only A2/A4 stainless steel self screws for fixing antenna feet onto the vehicle roof. We strongly recommend using branded polyurethane adhesive sealant ie Sikaflex 291 or equivelent. NOTE: Dimensions are in millimeters...
-
Page 9: Electrical Installation
12-24V fused DC supply voltage using 2x0.75mm twin core cable. 3. The antenna cable that comes from the SatFi Antenna, is connected to the input of the Control Box via F connector. 4. If satellite receiver is available, the connection between control box and satellite receiver is made with loop out cable. -
Page 10: Connection Diagram
CONNECTION DIAGRAM OPERATING OF THE SYSTEM 1. Switch on the control Box via the panel mounted rocker switch the LED's should briefly light up. Now push the control panel standby button. Select required satellite using UP/DOWN keys. You should hear the antenna moving. - Page 12 H08136 09-05-2017...
