12VDC
24VDC
DRY LOCATION
SAFETY & WARNINGS
1. Only for use with compatible 12V and 24VDC constant voltage
luminaires.
2. This product is rated for indoor installation and is not protected
against moisture.
3. Do not modify product beyond instructions or warranty will be
void.
QUICK SPECS / MODELS
DI-RF-REM-DIM-1
FRONT
Input
Operating Frequency Dimensions
3V (CR2025) Bat-
869.5/916.5/434MHz
tery (Included)
TOUCHDIAL
Mini Remote Dimmer INSTALL GUIDE
™
TOUCHDIAL
®
BACK
CR2025 Battery
1.5 x 0.5 in.
(D x H)
Mini Remote Dimmer
™
ADDITIONAL TOUCHDIAL COMPONENTS
V−
®
V−
MASTER COMPANION
TOUCHDIAL
™
V+
Receiver
LEARNING KEY
V+
GND
V+
V+
V+
D1+
W
WW
R
D1─
W
CW
G
D2+
W
WW
B
W
CW
W
D2─
®
V+
TOUCHDIAL MINI RECEIVER
V−
V−
DI-RF-REC-CV-SC
V+
V+
V−
Learning Key
APPROVED LED LUMINAIRES
The TOUCHDIAL Wall Paddle Dimmer is compatible with all
Diode LED 12V and 24VDC single color constant voltage tape
lights and fixtures.
TOOLS FOR INSTALL
Phillips-head
screwdriver
1 OF 3
INSTALLATION GUIDE
DI-RF-REC-CV-A
TOUCHDIAL Receiver, or
DI-RF-REC-CV-SC
TOUCHDIAL Mini Receiver
(Required)
IG070319-2.0
Advertisement
Summary of Contents for DIODE LED TOUCHDIAL Mini
- Page 1 3. Do not modify product beyond instructions or warranty will be void. APPROVED LED LUMINAIRES QUICK SPECS / MODELS The TOUCHDIAL Wall Paddle Dimmer is compatible with all DI-RF-REM-DIM-1 Diode LED 12V and 24VDC single color constant voltage tape lights and fixtures. FRONT BACK TOOLS FOR INSTALL Phillips-head...
- Page 2 Dimmer. Luminaire will flash to indicate pairing. SYNCING NOTE When syncing the TOUCHDIAL Mini Remote Dimmer, the LOOKING FOR SYSTEM DIAGRAMS? 1st receiver must be set to the MASTER function as outlined below. See the TOUCHDIAL Receiver Installation Guide for See the TOUCHDIAL RECEIVER (DI-RF-REC-CV-A) or more thorough information.
- Page 3 1. Place Base Mount on surface where desired, ADDITIONAL RESOURCES ensuring it is level. 2. Screw Mount to surface TOUCHDIAL MINI REMOTE DIMMER SPEC SHEET using included Screws. For full specifications. 3. Place Remote into Mount. TOUCHDIAL RECEIVER SPEC SHEET & INSTALL GUIDE For full specifications and installation instructions.
