Summary of Contents for CHINT NB1-63H/2
- Page 1 NO:2020.07 NB1-63H/2 Moulded Case Circuit Breaker User Instruction Standard: IEC/EN 60947-2...
-
Page 2: Safety Warning
Safety Warning Installation in any damp, condensed-phase environment with inflammable and explosive gas is forbidden. It is strictly prohibited to operate the product with wet hands. You are prohibited from touching the conductive part when the product is operating. It is strictly prohibited to test the performance of the product by the direct contact of the hot wire against the grounding device or the direct short circuit of the hot wire and the neutral wire. -
Page 3: Purpose Of Use
Purpose of Use The NB1-63H/2 moulded case circuit breakers are applicable to circuits with frequency of AC 50/60 Hz, rated voltage up to 230/400 V and rated current up to 63 A. They provide overload and short circuit protection, and can also be used for infrequent switching of the circuit under normal circumstances. -
Page 4: Installation
Installation 1. Outline and installation dimensions Unit:mm -1.20 49.5±0.31 -0.43 1P+N、2P -0.62 -1.20 3P+N、4P -1.20 2. On-off indication Green I•ON O•OFF... - Page 5 3. Installation TH35-7.5 type mounting rail...
- Page 6 4. Disassembly ① ② 5. Wiring: copper wires only Table 2 Copper wire cross-sectional area Copper wire cross-sectional Rated current (In) area (mm ) 16, 20 40, 50...
- Page 7 14mm Wiring torque 2.0N·m 16mm 25mm 15mm 16mm 25mm 6. Operation Instruction It is recommended to carry out the closing operation from the middle of the handle. I•ON I•ON...
-
Page 8: Maintenance
Maintenance 1.Check the circuit breaker on a regular basis during operation; 2.After the circuit breaker cuts off the overload or short-circuit current, the fault should be eliminated before closing the circuit breaker. Table 3 Analysis and troubleshooting of common faults Symptoms Cause analysis Troubleshooting method... - Page 9 QC PASS NB1-63H/2 Moulded Case Circuit Breaker IEC/EN 60947-2 Check 12 Test date: Please see The packing ZHEJIANG CHINT ELECTRICS CO.,LTD.
- Page 10 NB1-63H/2 Moulded Case Circuit Breaker User Instruction Zhejiang Chint Electrics Co., Ltd. Add: No.1, CHINT Road, CHINT Industrial Zone,North Baixiang, Yueqing, Zhejiang 325603,P.R.China E-mail: global-sales@chint.com Website: http://en.chint.com...
