Summary of Contents for Redline Communications AN 80i
- Page 1 AN 80i Configuration Instructions - 1 -...
- Page 2 Configuration Instructions AN80i For connections please refer to Figure 1. For the link distance of three meters and antenna gain of 9 or 15 dBi, 10dB attenuator should be used on the client side. Figure 1 - 2 -...
- Page 3 Figure 2: Block Diagram of the EUT To access AN80i using GUI Open Internet Explorer and access AN80i Web page at IP address http://192.168.25.3 http://192.168.25.2 ( IP address of each unit is given on the label attached to the unit) Login using admin as User Name and Password.
- Page 4 Figure. 4 General Information From the Web page menu select Configure System to set RF parameters. The frequency can be set in steps of 2.5MHz. Please note that antenna gain should be entered according to the antenna used. After changes are done, click on Save button at the bottom of the page. - 4 -...
- Page 5 Figure. 5 Configure System - 5 -...
- Page 6 Figure. 6 Configure System (continued) TxOff or Chg Freq should be selected depending on the test performed When Chg Freq is selected Client should have Auto scan enabled. - 6 -...
- Page 7 The link status can be checked by selecting System Status from the Web page menu Figure. 7 System Status - 7 -...
-
Page 8: Telnet Session
Telnet Session Start a telnet session by entering the following commands: telnet 192.168.25.2 or 192.168.25.3 Figure. 8 Telnet Login using debug as User Name and Password At the prompt type dbg dfs to enter DFS debug mode Commands available for testing purpose: evtime Evaluation time 60 sec.
