Model No. DTSL3 MKII -
Scissor Lift - Low Rise
Instruction Manual
Maintenance Manual
Spare Parts
(Rev. 04 - 10.03.2015)
The specifications stated in this manual are not binding, due to the process of continuous improvement and
development we reserve the right to change any specification without prior notification.
153-164 Bridge Street
Northampton
NN1 1QG
United Kingdom
www.dunlopge.co.uk ⁄ E. export@dunlopge.co.uk ⁄ T. +44 (0) 1604 828 540

Advertisement

loading
Need help?

Need help?

Do you have a question about the DTSL3 MKII and is the answer not in the manual?

Questions and answers

Related Manuals for Dunlop DTSL3 MKII

Summary of Contents for Dunlop DTSL3 MKII

  • Page 1 All manuals and user guides at all-guides.com Model No. DTSL3 MKII - Scissor Lift - Low Rise Instruction Manual Maintenance Manual Spare Parts (Rev. 04 - 10.03.2015) The specifications stated in this manual are not binding, due to the process of continuous improvement and development we reserve the right to change any specification without prior notification.
  • Page 2 DTSL3 MKII Model: Serial No: Year of Manufacture: Month Year Manufacturer Name: Name: Name: Name: Dunlop Garage Equipment Address: Address: Address: Address: 153-165Bridge Street Northampton NN11QG，UK Tel..: : : : +44 (0)1604 (0)1604 +44 (0)1604 (0)1604 828...

  • Page 3: Table Of Contents

    All manuals and user guides at all-guides.com DTSL3 MKII USER’S MANUAL Contents Contents Contents Contents Contents Manufacturer and service Packing, transport and storage Introduction Description of the machine Technical specifications Safety Installation Adjustment Operation Maintenance and care Troubleshooting Accessory...
  • Page 4 All manuals and user guides at all-guides.com DTSL3 MKII USER’S MANUAL PACKING, PACKING, PACKING, PACKING, TRANSPORT TRANSPORT TRANSPORT TRANSPORT AND AND STORAGE STORAGE STORAGE STORAGE PACKING PACKING PACKING PACKING (Picture 1) Picture 1 Picture 1 Transport Transport Transport Transport (Picture 2)
  • Page 5 All manuals and user guides at all-guides.com DTSL3/FR MKII USER’S MANUAL Manual Manual Introduction Introduction Manual Manual Introduction Introduction This manual has been prepared for workshop personnel expert in the use of the lift operator and technicians responsible for routine maintenance fitter.
  • Page 6 All manuals and user guides at all-guides.com DTSL3/FR MKII USER’S MANUAL Chapter Chapter Chapter 1 1 1 1 DESCRIPTION DESCRIPTION DESCRIPTION MACHINE MACHINE Chapter DESCRIPTION OF OF THE THE MACHINE MACHINE Machine Application: Machine Machine Machine Application: Application: Application: This lift can lift each kind of vehicle whose weight is less than 3000kg, and is suitable for use in vehicle tests, maintenance, and caring for automobiles, which is particularly suitable for use in the basement or on the floor, without construction and hole.
  • Page 7 All manuals and user guides at all-guides.com DTSL3/FR MKII USER’S MANUAL N N N N Chapter Chapter Chapter Chapter 2 2 2 2 SPECIFICATIO SPECIFICATIO SPECIFICATIO SPECIFICATIO Main technical parameter Main Main Main technical technical technical parameter parameter parameter Item Item Item Item...
  • Page 8 All manuals and user guides at all-guides.com DTSL3/FR MKII USER’S MANUAL N N N N Chapter Chapter Chapter Chapter 2 2 2 2 SPECIFICATIO SPECIFICATIO SPECIFICATIO SPECIFICATIO Lift Lift Lift Lift dimension dimension dimension dimension picture picture picture picture（Picture Picture Picture Picture 3) 3) 3) 3): : : : Picture 3...
  • Page 9 All manuals and user guides at all-guides.com DTSL3/FR MKII USER’S MANUAL N N N N Chapter Chapter Chapter Chapter 2 2 2 2 SPECIFICATIO SPECIFICATIO SPECIFICATIO SPECIFICATIO INSTALLATION SCHEME FOR SCISSOR LIFT Supply Supply Supply Supply at at at at the the same same same...

  • Page 10: Safety

    All manuals and user guides at all-guides.com DTSL3/FR MKII USER’S MANUAL Chapter Chapter 3 3 3 3 SAFETY SAFETY Chapter Chapter SAFETY SAFETY Read this chapter carefully and completely since important information for the safety of the operator or others in case of improper use of the lift is included.
  • Page 11 All manuals and user guides at all-guides.com DTSL3/FR MKII USER’S MANUAL Chapter Chapter Chapter Chapter 3 3 3 3 SAFETY SAFETY SAFETY SAFETY GENERAL GENERAL GENERAL GENERAL PRECAUTIONS PRECAUTIONS PRECAUTIONS PRECAUTIONS The operator and the maintenance fitter are required to observe the prescriptions of safety regulation in force in the country of installation of the lift.
  • Page 12 All manuals and user guides at all-guides.com DTSL3/FR MKII USER’S MANUAL Chapter Chapter Chapter 3 3 3 3 SAFET SAFET SAFET SAFETY Y Y Y Chapter RISKS FOR PERSONNEL This heading illustrates potential risks for the operator, maintenance fitter, or any other person present in the area around the lift, result from incorrect use of the lift.

  • Page 13: Installation

    All manuals and user guides at all-guides.com DTSL3/FR MKII USER’S MANUAL Chapter Chapter Chapter 4 4 4 4 INSTALLATION INSTALLATION INSTALLATION Chapter INSTALLATION SKILLED AUTHORISED PERSONNEL ONLY SHOULD ALLOWED PERFORM THESE OPERATIONS, SKILLED SKILLED SKILLED AND AND AUTHORISED AUTHORISED AUTHORISED PERSONNEL PERSONNEL PERSONNEL ONLY ONLY...
  • Page 14 All manuals and user guides at all-guides.com DTSL3/FR MKII USER’S MANUAL Chapter Chapter Chapter 4 4 4 4 INSTALLATION INSTALLATION INSTALLATION Chapter INSTALLATION ELECTRIC CIRCUIT CONNECTION: ELECTRIC ELECTRIC ELECTRIC CIRCUIT CIRCUIT CIRCUIT CONNECTION: CONNECTION: CONNECTION: Follow the stated line- pathway and line-number of the ‘electrical diagram’ to connect electric circuit. Only skilled person is allowed to perform the operations.

  • Page 15: Adjustment

    All manuals and user guides at all-guides.com DTSL3/FR MKII USER’S MANUAL Chapter Chapter 5 5 5 5 ADJUSTMENT ADJUSTMENT Chapter Chapter ADJUSTMENT ADJUSTMENT Add oil oil oil oil and and check check check check the the order order order order of of of of phase phase phase phase.
  • Page 16 All manuals and user guides at all-guides.com DTSL3/FR MKII USER’S MANUAL Chapter Chapter 5 5 5 5 ADJUSTMENT ADJUSTMENT Chapter Chapter ADJUSTMENT ADJUSTMENT Level Level Level Level adjustment adjustment adjustment adjustment: -By using a level bar and the horizontal pipe and adjusting the adjustment screws at tow sides of the base plate. -If platform unevenness is resulted from basic unevenness, use iron block to fill up the low place.

  • Page 17: Operation

    All manuals and user guides at all-guides.com DTSL3/FR MKII USER’S MANUAL Chapter Chapter Chapter Chapter 6 6 6 6 OPERATION OPERATION OPERATION OPERATION Only skilled having been trained personnel personnel is is is is allowed allowed allowed to to to to perform perform operations.

  • Page 18: Troubleshooting

    All manuals and user guides at all-guides.com DTSL3/FR MKII USER’S MANUAL Chapter Chapter Chapter Chapter 6 6 6 6 OPERATION OPERATION OPERATION OPERATION Down oil loop valve immediately. The process of manual operation: -Switch off the power button (avoid abruptly incoming electricity). Open the small round cover of control box to find the electromagnetic valve A for lowering.

  • Page 19: Accessory

    All manuals and user guides at all-guides.com DTSL3/FR MKII USER’S MANUAL ACCESSORY ACCESSORY ACCESSORY ACCESSORY Hydraulic Hydraulic Hydraulic Hydraulic pressure pressure pressure pressure schematic schematic schematic schematic diagram diagram diagram diagram: : : :...
  • Page 20 All manuals and user guides at all-guides.com DTSL3/FR MKII USER’S MANUAL ACCESSORY ACCESSORY ACCESSORY ACCESSORY diagram ： pipe pipe connection connection diagram diagram Oil pipe pipe connection connection diagram...
  • Page 21 All manuals and user guides at all-guides.com GC-3.0SSV(without extension extension extension ramp) ramp) GC-3.0SSV(without extension ramp) ramp) DTSL3 MKII EXPLODED DRAWING EXPLODED EXPLODED EXPLODED DRAWING DRAWING DRAWING A---------------PLATFORM A---------------PLATFORM A---------------PLATFORM A---------------PLATFORM...
  • Page 22 All manuals and user guides at all-guides.com B---------------CYLINDER B---------------CYLINDER B---------------CYLINDER B---------------CYLINDER See above above above above picture! picture! picture! picture!
  • Page 23 All manuals and user guides at all-guides.com C---------------CONTROL C---------------CONTROL C---------------CONTROL C---------------CONTROL BOX...
  • Page 24 All manuals and user guides at all-guides.com D---------------PUMP D---------------PUMP D---------------PUMP D---------------PUMP...
  • Page 25 All manuals and user guides at all-guides.com Parts list (without extension ramp) DTSL3 MKII 2012.10.17 A A A A - - - - - - - - - - - - - - - - - - - - PLATFORM...
  • Page 26 All manuals and user guides at all-guides.com Bush ZC-AT-3030 Washer MF-F-14 Oil pipe fitting GHC-14-19-14 Piston pole ring SLD0300 Bush ZC-AT-3250 Piston pole 45 SSD0102 Piston 75 SLD0102 Assemble seal kit MF-P-75-55 Guide belt MF-G-6 Cylinder cover 60 SLD0201a-30SLV Cylinder canister 60 SSD0201 Piston 60 SLD0202...
  • Page 27 All manuals and user guides at all-guides.com Bolt LS-SCS-M690 Valve block VB-100-80-72 Filter TKC-01 advise advise voltage voltage Motor(pls pls advise advise voltage voltage) Hydraulic pump Descent valve WS-SV-09 oil tank CNJ0300 Bolt LS-SCS-M616 Washer MF-F-14 Stopple CNJ0600 D D D D - - - - - - - - - - - - - - - - - - - - PUMP PUMP PUMP PUMP...
