- Page 1 I414500.A INSTALLATION, OPERATION AND MAINTENANCE GUIDE FOR APOLLO 3-Way Diversion Valves: 70-600 SERIES 70-900 SERIES 76-600 SERIES Ball Valve Division P.O. BOX 125 PAGELAND, S.C. 29728 803-672-6161...
- Page 2 **** CAUTION **** BEFORE INSTALLATION: Ensure that the component materials of the Valve are compatible with the media, with regard to corrosiveness, pressure, and temperature. Valves must be installed in piping systems that comply to the applicable portions of A.N.S.I. B31 Standard. Special considerations must be taken with respect to pipe line expansions and contractions and the media expansions and contractions within the piping system.
- Page 3 MAINTENANCE Normal stem packing wear can be compensated for by tightening the packing gland screw clockwise. If all of the adjustment to the packing gland screw has been made, remove the lever and packing gland screw and add one or two replacement bearings on top of the old packing.
- Page 4 A. RETAINER B. BODY SEAL (1-1/4” – 2” SIZES) C. SEAT D. BALL E. STEM F. BEARING G. BODY H. PACKING I. GLAND SCREW J. LEVER / GRIP ASSEMBLY K. WASHER (1-1/2” – 2” S.S. ONLY) L. LEVER NUT...
