Summary of Contents for Soho FamilyChef Duo
- Page 1 FamilyChef User Manual X-LARGE Capacity SO-80DAF Dual 4L Baskets Independently Controlled Baskets 8 Pre-Set Programs Digital Touch Controls 1700 Watts Turbo Power 8.0L Dual Basket Air Fryer Preset Cooking Modes & Digital Touch Control...
- Page 2 IMPORTANT SAFEGUARDS SAVE THESE INSTRUCTIONS. FOR HOUSEHOLD USE ONLY When using electrical appliances, basic safety precautions should always be followed, including the following: PLEASE READ ALL INSTRUCTIONS. 2. DO NOT touch hot surfaces. Use handles, oven mitts or potholders. 3. To protect against electric shock DO NOT immerse the cord, plugs, or appliance in water or other liquid.
- Page 3 WARNING! THE AIR FRYER WILL NOT OPERATE UNLESS BOTH FRYING BASKETS ARE FULLY CLOSED. CAUTION! AFTER HOT AIR FRYING, EXTREME CAUTION MUST BE USED WHEN HANDLING THE HOT FRYING BASKET, REMOVEABLE AIRFLOW TRAY, AND COOKED FOODS. WARNING: DO NOT USE ON ACRYLIC OR STONE SURFACES AS HEAT MAY CAUSE CRACKS OR SURFACE DAMAGE.
-
Page 5: Table Of Contents
CONTENTS GETTING TO KNOW YOUR FAMILYCHEF DUO 8L AIR FRYER ....6 DUAL TOUCHSCREEN CONTROL ............7 ON/OFF ........................7 SHAKE ........................8 DUAL COOK ......................8 SYNC FINISH ......................9 START/PAUSE ......................9 BEFORE USING FOR THE FIRST TIME ............9 OPERATING INSTRUCTIONS ..............10... -
Page 6: Getting To Know Your Familychef Duo 8L Air Fryer
1. GETTING TO KNOW YOUR FAMILYCHEF DUO 8L AIR FRYER Whats in the box: • Air fryer with 2 removable baskets • 2x Removeable Airflow Trays Air Inlet Heat insulator Dual located on TouchScreen the back to Control allow hot air... -
Page 7: Dual Touchscreen Control
2. DUAL TOUCHSCREEN CONTROL 12. TEMP ON/OFF SEAFOOD 13. TIME Dual Digital TIME/ FRIES TEMP Display VEGETABLES SHAKE FOOD LEFT /RIGHT BAKE SYNC FINISH Basket Control DEHYDRATE DUAL COOK MEAT PREHEAT START/PAUSE CHICKEN ON/OFF • When the Air Fryer is plugged in, a beep will sound and the control panel will illuminate, then disappear. -
Page 8: Shake
HOW TO USE THE LEFT/RIGHT BASKET • When the red is pressed, a beep will sound. From here, you can choose to cook in each basket together or separately by pressing NOTE: DUAL COOK CAN BE USED TO COOK THE SAME TYPE OF FOOD IN BOTH BASKETS. -
Page 9: Sync Finish
SYNC FINISH • Program each basket before use. • Press to ensure both baskets will complete cooking together. • will appear on the display as the Dual Air Fryer synchronises the final cook times. NOTE: YOU CAN NOT SYNC YOUR COOKING ONCE COOKING HAS BEGUN (IF SYNC COOKING HAS NOT ALREADY BEEN SET). -
Page 10: Operating Instructions
4. OPERATING INSTRUCTIONS IMPORTANT! THE MAXIMUM FOOD CAPACITY RECOMMENDED FOR EACH AIR FRYER BASKET IS 1.7KG OF FOOD PER BASKET. WARNING! THIS DUAL BASKET AIR FRYER IS NOT TO BE USED TO BOIL WATER. WARNING! THIS DUAL BASKET AIR FRYER SHOULD NEVER BE USED TO DEEP FRY FOODS. -
Page 11: Pre-Programmed Temperature & Times Chart For Manual Operation
6. PRE-PROGRAMMED TEMPERATURE & TIMES CHART FOR MANUAL OPERATION DEFAULT TIME (Min) PRESET DEFAULT SHAKE FUNCTIONS TEMP SINGLE BASKET DUAL BASKET MEAT 175°C 15min 20min CHICKEN 200°C 25min 30min SEAFOOD 180°C 8min 10min FRIES 200°C 20min 28min VEGETABLES 150°C 10min 12min BAKE 150°C... -
Page 12: Individual Basket: Manual Operation
INDIVIDUAL BASKET: MANUAL OPERATION Plug cord into the wall outlet. An audible tone will sound, the control panel will illuminate. The button will light up red. 2. When the is pressed, a tone will sound and the power button will turn green buttons. -
Page 13: Dual Basket: Manual Operation
10. When cooking has finished and time says , the display will show then change to and beep 5 times when it is safe to remove food. NOTE: THE QUANTITY, DENSITY & WEIGHT OF FOOD WILL ALTER THE TOTAL COOKING TIME NECESSARY. -
Page 14: Sync Finish
TO MANUALLY CHANGE THE TIME AND TEMP SETTINGS FOLLOW THESE INSTRUCTIONS: You can now change temperature and time by pressing button. The change will be 5:00 5:00 applicable to both baskets at the same time. You can also change the setting of an individual basket ONLY by pressing the FIG. -
Page 15: Air Frying Technique
10. AIR FRYING TECHNIQUE Please refer to the Air Fry / Roast Cooking Chart and/or follow package directions for suggested TIME and TEMP. ALWAYS pat food dry before you start cooking to encourage better and more consistent browning and to avoid excess smoke. 2. -
Page 16: Air Frying Pre-Packaged Frozen Foods
11. AIR FRYING PRE-PACKAGED FROZEN FOODS • As a rule, depending on the food and amount to be cooked, recommended cooking times can be reduced slightly. Always check food halfway to determine final cook TIME and TEMP. Always check cooking progress after TIME has finished. •... -
Page 17: Air Fry / Roast Cooking Chart
15. AIR FRY / ROAST COOKING CHART Times are estimated and based on average sizes and weights. ALWAYS USE A MEAT THERMOMETER TO ENSURE THAT MEAT, POULTRY AND FISH ARE COOKED THOROUGHLY BEFORE SERVING. NOTE: FRYING SMALLER BATCHES WILL RESULT IN SHORTER COOKING TIMES AND HIGHER FOOD QUALITY. - Page 18 SINGLE BASKET DUAL BASKET BEEF TEMP TIME TIME Hamburger, 110g (up to 4) 180°C 12-16 minutes 16-18 minutes Hot Dogs / Sauages 180°C 10-15 minutes 20-25 minutes Meat Loaf, 450g 180°C 33-40 minutes 45-50 minutes Steak, 2 (225g) Steaks 180°C 8-21 minutes 10-24 minutes Beef Tenderloin, 450g, rare...
-
Page 19: Dehydrate Chart
SINGLE BASKET DUAL BASKET All items are to be air fried from frozen (do not thaw). FROZEN FOODS TEMP TIME TIME Cheese Sticks 175°C 6-9 minutes 10-12 minutes French Fries, Thick, 2 cups 200°C 17-21 minutes 24-30 minutes French Fries 200°C 15-17 minutes 20-24 minutes... -
Page 20: Fruit / Vegetables
17. FRUIT / VEGETABLES Wash all fruit skins well. 2. Slice fruit into 13mm thick slices and arrange with space between each slice to ensure even drying. 3. Rotate foods halfway through DEHYDRATE operation for even drying. DEHYDRATE TEMP TIME DEHYDRATE TEMP TIME... -
Page 21: Storing Instructions
20. STORING INSTRUCTIONS Make sure the Air Fryer is unplugged and all parts are clean and dry before storing. 2. Never store the Air Fryer while it is hot or wet. 3. Lock the frying basket into the drawer, and store inside the Air Fryer body. 4. -
Page 22: Warranty Terms & Conditions
Soho services, relating to or arising out of your breach of any provision of these terms, your misuse of the Soho products or services, or your unauthorized modification or... -
Page 23: Warranty Disclaimer
24. WARRANTY DISCLAIMER Soho has a limited warranty whereby Soho warrants to you and only to you that Soho products will be free from defects in materials and workmanship for one (1) year from the date of your purchase of the Soho products (unless a longer warranty period is required by law). - Page 24 w w w . s o h o h o m e . c o m . a u ANOTHER All Images, Information and Content are Copyright © 2021 DIRECTED Directed Electronics Australia Pty Ltd. All Rights Reserved. BRAND www.directed.com.au | www.directed.co.nz...
