Summary of Contents for VIBO NES P.240
- Page 1 Istruzioni di montaggio - Assembling instructions Notice de montage - Montageanleitung - Manual de montaje NES... P.240 20 min A X 1 C X 14 B X 4 Ø4x16 4004110297 17/03/2021...
- Page 2 -Sistema di regolazione laterale -Side adjustment by 3 mm...
- Page 3 FRONT BACK BACK FRONT 220,5 1 - Allentare i grani B, fissare il meccanismo ai fianchi del mobile - Loosen the grub screws B, fasten the mechanism to the unit sides. - Desserrer les vis sans tête B, fixer le mécanisme aux côtés du meuble - Aflojar los tornillos sin cabeza B, fijar el mecanismo en los costados del mueble...
- Page 4 BACK FRONT...
