FEATURES
Speaker box with 100 mm³
„
back volume
Provides a convenient way to
„
connect and test Ganymede MEMS
speakers (Adap and Achelous)
Compatible with the development
„
board Helike UA-E3010
SPEAKER BOX
CARME 3.0 UJ-R1030
QUICK USER GUIDE
Carme 3.0 is a speaker box
designed for testing the
performance of our Ganymede
MEMS speaker series.
Carme 3.0 is designed to be
compatible with our latest
development board Helike.
*The speaker is not included.
PACKAGE CONTENT
Shell and speaker gasket glued
„
PCB with 1 m cable to 2.54 mm
„
crimp tin contact
Housing gasket
„
Two screws
„
*Carme is delivered assembled.
Advertisement
Summary of Contents for U-sound CARME 3.0 UJ-R1030
- Page 1 SPEAKER BOX CARME 3.0 UJ-R1030 QUICK USER GUIDE Carme 3.0 is a speaker box designed for testing the performance of our Ganymede MEMS speaker series. Carme 3.0 is designed to be compatible with our latest development board Helike. *The speaker is not included.
- Page 2 SETTING UP THE SYSTEM To put the Ganymede MEMS speaker inside of the speaker „ box, first, unscrew and separate the PCB from the shell. Remove the housing gasket and place the Ganymede MEMS „ speaker with the contact side up. Place the housing gasket and the PCB on the shell, matching „...
- Page 3 2x Screws Housing gasket Ganymede MEMS Speaker (Not included) Speaker gasket (Glued to the shell) Shell...
- Page 4 USound products are neither destined nor qualified for use as components in such medical devices and/or medical applications. The prohibited use of USound products in such medical devices and/or medical applications is exclusively at the risk of the customer. Carme 3.0 UJ-R1030 Quick user guide Released on September 2020 USound GmbH |...
