Summary of Contents for Gate NanoAAB
- Page 1 User Guide NanoAAB Last Update in 2014-03-08 www.gatee.eu...
- Page 2 NanoAAB User Guide Notice Information contained in this document is subject to change without notice. FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY BEFORE INSTALLING THE DEVICE Safety Summary KEEP AWAY OF CIRCUIT Device cover must not be removed by user.
- Page 3 NanoAAB User Guide Table of Contents: Notice Safety Summary I. Overview II. Installation AEG standard installation diagram • Installation of NanoAAB without replacement of wires • Installation of NanoAAB with replacement of wires IV. Warranty - 3 -...
- Page 4 NanoAAB User Guide I. Overview NanoAAB is the latest, 3rd generation MOSFET with active brake. The application of most up-to-date transistors and microprocessor enabled us to create the smallest and most reliable MOSFET in the market. Thanks to its special coating, it is resistant to atmospheric conditions.
- Page 5 NanoAAB User Guide Digital Interface It provides full compatibility with micro-switches. It is fully resistant to contact bounce. You gain a bigger ROF, faster trigger response and your MOSFET becomes less heated. MOSFET of the 3rd Generation Usage of most modern transistors and microcontroller enabled us to create the smallest and most reliable MOSFET in the market.
- Page 6 NanoAAB User Guide II. Installation To install the NanoAAB into a standard AEG, we must access the trigger contacts. In the case of Version 2 gearboxes, the contacts are located inside the gearbox. With a Version 3 gearbox, installation will be easier because the contacts are on the outsideof the gearbox.
- Page 7 NanoAAB User Guide In the place of the No. 2 wire, solder additional gate wire (4 – provied the kit). The gate wire is very thin because it handles very low current is only used for switch-detection. Now, we have just connected system between battery and AEG.
- Page 8 NanoAAB User Guide IV. GATE Limited Warranty Policy 1. The product must be delivered with proof of purchase and properly completed Warranty Form. Installing the product is not considered as a warranty repair. 2. The Warranty Form is available on our website: http://www.gatee.eu/rma 3.
