PoE-S901-W POE Splitter Manual
Product Description
This product is a universal POE splitter for input and output isolated network
cameras. It can effectively suppress the input ripple interference to the output; this
product complies with the IEEE802.3af standard and is compatible with non-
standard POE power supply. It supports both the IEEE802.3af standard POE power
supply equipment and the DC38V~57V non-standard (45+/78-) POE power supply
equipment. The output voltage of this splitter is DC12V 1A, and the output network
supports 10M/100M bps;
This product has small volume, high efficiency, stable transmission distance,
overload protection, short circuit protection, plug and play, etc.
Product Appearance Size
2
1
2
Product Feature
1 Channel 10/100M Weatherproof PoE Splitter
DC Jack type 5.5 x 2.1mm (Accept customization)
Mini Size:287*28*23.5mm
Product Application Diagram
3
Advertisement
Table of Contents
Summary of Contents for Alibi Security PoE-S901-W
- Page 1 PoE-S901-W POE Splitter Manual Product Description This product is a universal POE splitter for input and output isolated network cameras. It can effectively suppress the input ripple interference to the output; this product complies with the IEEE802.3af standard and is compatible with non- standard POE power supply.
- Page 2 PORT: DC 12V Output connect to camera DC female. RJ45Network output (PIN, 1 2 3 6), connect to the camera network port. POE Network powered device input. Network indicator (green), network connection when flashing. Power indicator (yellow), duration of power connection is on.
