M&M Web Riderz MM00124 Installation Instructions

INSTALLATION INSTRUCTIONS
1. Do not install home playground equipment over concrete, asphalt, packed earth, grass, carpet or any other hard surface.
A fall onto a hard surface can result in serious injury or death to the equipment user
2. To prevent serious injury children must not use the equipment until properly installed.
3. Confirm that the supporting structure is secure, it will support at least 600 lbs., is over level ground, has a minimum height
of 7 ft. and is no less than 6 ft. on all sides from vertical elements. Web swing should have a clearance of at least 1.5 times
the total length of all the rope measured from the tree limb/horizontal beam to the spring clip(s) attachment point.
• TREE LIMB ASSEMBLY - Test tree limb to ensure that it will hold the weight limit of 600 lbs. safely. Bottom of swing
should be no more than 24 in. and no less than 18 in. from the ground.
• SWING SET OR OTHER HORIZONTAL BEAM ASSEMBLY -Attach the web swing to a swing set by removing two sets
of swings from the existing swing set and attach the spring clips to the chain support hooks. Allow 1.5 times the total
length of the rope to the spring clips of clearance on each side of the swing from stationary objects or other swinging
elements of any kind. Bottom of swing should be no more than 24 in. and no less than 18 in. from the ground.
ADJUSTING SWING HEIGHT
The height adjustment of your web swing must be made
before use. The supporting ropes that go through the swing
tubing are not permanently tied. The temporary loop shown
at right must be undone and a permanent knot must be tied
after the height of the swing is adjusted. After the height of
the swing is set (see Clearance Requirements below), a
permanent knot (as shown at right) must be made on each of the ropes to ensure proper use and safety.
OPERATION INSTRUCTIONS
1. An adult should supervise play on this product for children of all ages.
2. Only for family residential domestic use. Design for multi-rider use. 600 lb. maximum load.
3. Riders should be dressed appropriately including wearing well-fitting shoes that fully protect feet. Remove articles
before swinging that create hazards when they get tangled and caught (examples include: ponchos, scarves, and
other loose-fitting clothing, bike or sports helmets.
4. INSTRUCT CHILDREN: Not to swing higher than hook attachment • Get off swing only after it has completely
stopped and hold onto the rope or chain until both feet are planted firmly on the ground • Not to twist swing
chains or ropes or loop them over the top support bar since this may reduce the strength of the chain or rope •
To avoid swinging empty seats • Not to walk close to, in front of, or behind, or between moving items • To sit in
center of the swings with their full weight on the seats • Not to use the equipment in a manner other than
intended • Not to attach items to the playground equipment that are not specifically designed for use with the
equipment, such as, but not limited to, jump ropes, clothesline, pet leashes, cables and chain as they may cause a
strangulation hazard • To remove their bike or other sports helmet before playing on the playground equipment
All manuals and user guides at all-guides.com
CLEARANCE
REQUIREMENTS
MM00124 Web Riderz® Web Swing
MM00124-SNO Web Riderz® Snowflurry
MM00124-HEO Web Riderz® Superhero
MM00124-PNK Web Riderz® Tickled Pink
MM00152 46" Web Riderz® Web Swing
MM00159 32" Web Riderz® Web Swing
MM00160 Elite Stainless Steel Web Riderz®
SINGLE
ATTACHMENT
ATTACHMENT
EXAMPLE EXAMPLE
TEMPORARY LOOP
DOUBLE OVERHAND KNOT
Ages 5+
DUAL
PULL TIGHT
