Service Manual
Colour Television
CHASSIS : CM-905S/SF
Model :
DTD-14D3/20D3/21D3 ME/MT/MP/MZ
14D4/20D4/21D4
14D6/21D6
14D7/20D7/21D7
21U6/21U8
Specification
Items
Model
TV Standards
Mains Voltage
Power Consumption
Sound Ouput1
Speaker
Antenna
Tuning System
Memory Channel
Remocon Control
Reception Channel
Remark
DAEWOO ELECTRONICS CO., LTD
http : //svc.dwe.co.kr
S/M No. : TCM905SEF0
ME/MT/MP/MZ
ME/MT/MP/MZ
ME/MT/MP/MZ
ME/MT/MP/MZ
DTD-14D3/20D3/21D3 ME/MT/MP/MZ
14D4/20D4/21D4 ME/MT/MP/MZ
14D6/21D6 ME/MT/MP/MZ
14D7/20D7/21D7 ME/MT/MP/MZ
21U6/21U8 ME/MT/MP/MZ
PAL-SECAM-B/G,D/K,I,NTSC-M,NTSC-4.43(AV)
AC 100~250V, 50/60Hz
Stand-by mode : 5W
Normal Operating Mode :
14"=85W, 20"=95W, 21"=105W, 21"(flat)=115W
14/20"=5W+5W Over(80% MOD.at 1KHz THD.10%)
21U6=5W+5W Over(80% MOD.at 1KHz THD.10%)
21",21U8=7W+7W Over(80% MOD.at 1KHz THD.10%)
14/20"=7.5W 8 Ohm (2pcs)
21U6=5W 8 Ohm (2pcs) , 21",21U8=12W 8 Ohm (2pcs)
75 Ohm Unbalanced. (DIN Standard)
FS Tuning System
100 Channels
R-44C07
VHF - BAND1 : CH2-CH4
BAND2 : CH5-CH12
CABLE BAND : S1'-S3, S1-S20
HYPER BAND : S21-S41
UHF-BAND : CH21-CH69
OSD
TELETEXT (Top & Flop Teletext)
PIP(AV PIP , Swap, Size, Position)
Digital Eye
June.2001
