Table of Contents
loading
Need help?

Need help?

Do you have a question about the E-Class and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mercedes-Benz E-Class

Summary of Contents for Mercedes-Benz E-Class

  • Page 1 Possible variations to your vehicle may not to receive a printed Owner‘s Manual for other vehicle models and vehicle be taken into account as Mercedes-Benz constantly updates their vehicles to Ihrem konkreten Fahrzeug könnten nicht berücksichtigt sein, da Mercedes-Benz model years.
  • Page 4 Welcome to the world of Mercedes-Benz The technical documentation team at Daimler AG wishes you safe and pleasant Before you first drive off, read this Owner's motoring. Manual carefully and familiarise yourself with your vehicle. For your own safety and a longer vehicle life, follow the instructions and warn- ing notices in this manual.
  • Page 6 Contents Index ............4 At a glance ........... 27 Introduction ......... 21 Safety ........... 39 Opening and closing ......75 Seats, steering wheel and mirrors . . 107 Lights and windscreen wipers ..121 Climate control ......... 139 Driving and parking ......157 On-board computer and displays ..
  • Page 7 Index Airbags 1, 2, 3 ... Front airbag (driver, front 12 V socket passenger) ........44 see Socket Important safety guidelines ..... 42 Kneebag ........... 45 Pelvis airbag ........46 Sidebag ..........45 ABS (Anti-lock Braking System) Triggering ......... 41 Display message ......

  • Page 8: Table Of Contents

    Index Resetting the service interval dis- Auxiliary heating play ..........311 Activating/deactivating ....149 Service message ......311 Activating/deactivating (on the Special service requirements ..311 centre console) ......150 ATA (Anti-Theft Alarm system) Display message ......272 Activating/deactivating ....71 Important safety notes ....
  • Page 9 Index Notes/function ......210 Bulbs Trailer towing ......... 212 see Changing bulbs see Active Blind Spot Assist Bonnet Active bonnet (pedestrian protec- Calling up a fault tion) ..........306 see Display messages Closing ........... 308 Display message ......271 see Vehicle Opening .........
  • Page 10 Index Changing bulbs Setting the air distribution ..... 145 Dipped-beam headlamps ....134 Setting the airflow ......146 Important safety notes ....132 Setting the air vents ...... 153 Main-beam headlamps ....134 Setting the climate mode ....144 Overview of bulb types ....133 Setting the temperature ....
  • Page 11 Index Display message ......267 Display messages Driving system ....... 182 Calling up (on-board computer) ..249 Important safety notes ....182 Driving systems ......262 LIM indicator lamp ......183 Engine ..........259 Selecting ........183 Key ..........274 Setting a speed ......
  • Page 12 Index Driving on flooded roads ....181 Icy road surfaces ......182 Driving safety system Limited braking efficiency on sal- BAS PLUS (Brake Assist System ted roads ........181 PLUS) ..........65 New brake pads/linings ....181 Electronic Brake-force Distribu- Running-in tips .......
  • Page 13 Index Emergency spare wheel Exhaust tail pipe (cleaning instruc- Important safety notes ....363 tions) ..........317 Points to remember ....... 363 Exterior lighting Storage location ......363 Settings options ......122 Technical data ....... 364 see Lights Emergency unlocking Exterior mirrors Vehicle ..........
  • Page 14 Warning and indicator lamps Opening/closing the garage door .. 299 Insect protection on the radiator ..308 Programming (button in the rear- Inspection view mirror) ........297 see ASSYST PLUS Genuine Mercedes-Benz parts ..368 Glove compartment ......287...
  • Page 15 Index Instrument cluster Problem (malfunction) ..... 81 Overview ........30, 229 Starting the engine ......160 Settings ......... 242 KEYLESS-GO Warning and indicator Convenience closing ......90 lamps ........32, 275 Display message ......274 Instrument cluster lighting ....230 Locking ..........
  • Page 16 (on-board computer) ..244 Memory card (audio) ......237 Turn signals ........126 Memory function ....... 120 see Changing bulbs Mercedes-Benz Service Centre see Interior lighting see Qualified specialist workshop Light sensor (display message) ..258 Message memory (on-board com- LIM indicator lamp puter) ..........
  • Page 17 Index Overhead control panel ...... 36 Override feature Navigation Rear side windows ......64 Menu (on-board computer) .... 235 Neck-level heating see AIRSCARF Paint code .......... 371 NECK-PRO head restraints Paintwork (cleaning instructions) . . . 313 Operation ......... 47 Panic alarm ..........
  • Page 18 Index Sensor range ......... 200 Rear-compartment seat belt sta- Trailer towing ......... 202 tus indicator ........52 Warning display ......201 Rear foglamp PASSENGER AIRBAG OFF warning Display message ......258 lamp ............56 Switching on/off ......125 Petrol ..........372 Rear seat Plastic trim (cleaning instructions) .
  • Page 19 Index Reversing camera Adjusting the 4-way lumbar sup- Cleaning instructions ..... 317 port ..........113 Function/notes ......206 Adjusting the head restraint ..111 Switching on/off ......207 Cleaning the cover ......318 Reversing lamp (display message) . . 258 Correct driver's seat position ..
  • Page 20 Index Problem (malfunction) ..... 92 SPEEDTRONIC resetting .......... 91 Deactivating variable ..... 188 Sliding sunroof Display message ......267 see Panorama sliding sunroof Function/notes ......185 Snow chains ........343 Important safety notes ....185 Socket LIM indicator lamp ......186 Centre console ......
  • Page 21 Index Surround lighting (on-board com- Towing a trailer puter) ..........244 Active Blind Spot Assist ....217 Switching off the alarm (ATA) .... 71 Active Lane Keeping Assist .... 220 Axle load, permissible ....381 Bulb failure indicator for LED lamps ..........
  • Page 22 Index Turn signal see Turn signals Vanity mirror (in sun visor) ....293 Turn signals Variable SPEEDTRONIC Changing bulbs (front) ....135 see SPEEDTRONIC Switching on/off ......126 Vehicle Correct use ........24 Operating (on-board computer) ..237 Data acquisition ....... 24 see Separate operating instructions Display message ......
  • Page 23 Index LIM (cruise control) ......183 Winter operation LIM (DISTRONIC PLUS) ....190 Important safety notes ....342 LIM (variable SPEEDTRONIC) ..186 Radiator cover ....... 308 Overview ........32, 275 Slippery road surfaces ....182 PASSENGER AIRBAG OFF ....56 Snow chains ........
  • Page 24 Mercedes-Benz will take back your planet to be used sparingly and in a manner Mercedes-Benz to dispose of it in an environ- which takes the requirements of both nature mentally responsible manner, in accordance and humanity into account.
  • Page 25 Mercedes-Benz therefore recommends that systems in your vehicle. you use genuine Mercedes-Benz parts, con- Should you have any questions concerning version parts and accessories that have been equipment and operation, please consult a approved for the type of vehicle.
  • Page 26 Directive 1999/5/EC. You can obtain further information from any Mercedes-Benz Service Centre. Qualified specialist workshop A qualified specialist workshop has the nec- Electromagnetic compatibility essary special skills, tools and qualifications...
  • Page 27 Introduction Mercedes-Benz recommends that you use a Implied warranty Mercedes-Benz Service Centre. ! Follow the instructions in this manual about the proper operation of your vehicle as well as about possible vehicle damage. Vehicle registration Damage to your vehicle that arises from...
  • Page 28 Introduction save and edit data required for the operation THIS SOFTWARE IS PROVIDED BY THE of the respective device. REGENTS AND CONTRIBUTORS "AS IS" AND ANY EXPRESS OR IMPLIED WARRANTIES, Further information on operation (e.g. on INCLUDING, BUT NOT LIMITED TO, THE deleting data) can be found in the separate IMPLIED WARRANTIES OF MERCHANTABIL- operating instructions.
  • Page 30 Cockpit ..........28 Instrument cluster ......30 Multifunction steering wheel ..... 33 Centre console ........34 Overhead control panel ...... 36 Door control panel ......37...

  • Page 31: Play

    Cockpit Cockpit Function Page Function Page Automatic transmission: Adjusts the steering wheel steering wheel gearshift manually paddles Adjusts the steering wheel Cruise control lever electrically Instrument cluster Combination switch Horn Parking brake PARKTRONIC warning dis- Diagnostics connection play Opens the bonnet Overhead control panel Releases the parking brake Climate control systems...
  • Page 32 Cockpit Illustration: Coupé Function Page Function Page Opens the bonnet Overhead control panel Diagnostics connection PARKTRONIC warning dis- Ignition lock play Start/Stop button Cruise control lever Adjusts the steering wheel manually Instrument cluster Adjusts the steering wheel Horn electrically Automatic transmission: Combination switch steering wheel gearshift paddles...
  • Page 33 Instrument cluster Instrument cluster Displays and controls Instrument cluster: kilometres Function Page Function Page Multifunction display Fuel gauge Rev counter Clock: see the separate Coolant temperature operating instructions Instrument cluster lighting Speedometer with seg- ments...
  • Page 34 Instrument cluster Instrument cluster: miles Function Page Function Page Multifunction display Fuel gauge Rev counter Clock: see the separate Coolant temperature operating instructions Instrument cluster lighting Speedometer with seg- ments...
  • Page 35 Instrument cluster Warning and indicator lamps Function Page Function Page L Dipped-beam head- ® å ESP lamps % Diesel engine: pre- ü Seat belt glow 6 SRS N Front foglamps ; Engine diagnostics R Rear foglamp J Brakes #! Turn signals ? Coolant ®...
  • Page 36 Multifunction steering wheel Multifunction steering wheel Function Page Function Page Multifunction display Selects a menu Audio/COMAND display; see the separate operating Selects a submenu or instructions scrolls through lists Switches on LINGUA- Confirms the selection TRONIC; see the separate Hides display messages operating instructions Back Rejects or ends a call...
  • Page 37 Centre console Centre console Coupé Function Page Function Page Hazard warning lamps Auxiliary heating ATA indicator lamp Ashtray Cigarette lighter PASSENGER AIRBAG OFF Power socket indicator lamp Gear lever Moves the seat-belt Selector lever extender forwards Stowage compartment Audio system/COMAND Online;...
  • Page 38 Centre console Cabriolet Function Page Function Page Hazard warning lamps Ashtray Cigarette lighter ATA indicator lamp Power socket PASSENGER AIRBAG OFF Gear lever indicator lamp Selector lever Moves the seat-belt Stowage compartment extender forwards Cup holders Audio system/COMAND Online; see the separate Stowage compartment operating instructions AIRCAP...
  • Page 39 Overhead control panel Overhead control panel Function Page Function Page u Switches the rear 3 Opens/closes the interior lighting on/off panorama sliding sunroof (Coupé only) with roller sunblind (Coupé only) | Switches the auto- ê Deactivates the inte- matic interior lighting con- trol on/off rior motion sensor p Switches the right-...
  • Page 40 Door control panel Door control panel Function Page Function Page r45= W Opens/closes the Stores settings for the seat, side windows exterior mirrors and steer- n Activates/deacti- ing wheel vates the override feature Adjusts the seats electri- for the side windows in the cally rear compartment %&...
  • Page 42 Useful information ......40 Panic alarm .......... 40 Occupant safety ........40 Children in the vehicle ......53 Driving safety systems ....... 64 Anti-theft systems ......71...

  • Page 43: Useful Information

    Occupant safety Useful information Occupant safety Important safety notes This Owner's Manual describes all mod- els, series and optional equipment for your WARNING vehicle that were available at the time of If service work is not carried out correctly, the going to press.

  • Page 44: Occupant Safety

    Occupant safety To ensure that the restraint systems can SRS reduces the risk of occupants coming deliver their full potential protection, make into contact with the vehicle's interior in the sure that: event of an accident. It can also reduce the forces to which occupants are subjected dur- the seat and head restraint are adjusted ing an accident.
  • Page 45 Occupant safety If there is an even higher rate of vehicle decel- The belt tensioners can only be triggered eration or acceleration in a longitudinal direc- if the seat belt tongues are correctly tion, the front airbags are also deployed. engaged in the seat belt buckles.
  • Page 46 Occupant safety move the front-passenger seat as far back deployed and you are holding the inside of as possible. This is especially important if the steering wheel. you have secured a child in a child restraint do not lean on the doors/rear sidewalls system on the front-passenger seat.
  • Page 47 Occupant safety The front airbags increase protection for the WARNING driver's and front-passenger's head and The airbag parts are hot after the airbag has chest. been deployed. Do not touch them as you They are deployed: could burn yourself. Have the airbags replaced at a qualified spe- at the start of an accident with a high rate cialist workshop.
  • Page 48 WARNING Cabriolet: if the vehicle overturns, the side- If you wish to use seat covers, Mercedes-Benz bags are generally not deployed. Sidebags recommends that, for safety reasons, you are deployed if the system detects high vehi-...
  • Page 49 Pelvisbags Pelvisbags are only available in certain countries. WARNING If you wish to use seat covers, Mercedes-Benz recommends that, for safety reasons, you only use seat covers that have been approved for Mercedes-Benz vehicles. The seat covers must have a special tear seam for sidebags/pelvisbags.
  • Page 50 Windowbags are deployed: Only use head restraint covers which have at the start of an accident with a high rate been tested and approved by Mercedes-Benz of lateral vehicle deceleration or accelera- for your vehicle model. tion, e.g. in a side impact...
  • Page 51 WARNING no longer be adjusted. When adjusting the seat, make sure that Mercedes-Benz recommends that you have nobody can become trapped. the NECK-PRO head restraints checked at a qualified specialist workshop after a rear-end ! Make sure that there are no objects in the collision.
  • Page 52 Occupant safety If the seat belts are not released: Only one person should use each seat belt at any one time. Children must never travel Move the backrest or seat back slightly, but sitting on the lap of another occupant. The only when the vehicle is stationary.
  • Page 53 For safety reasons, Mercedes-Benz recom- mends that you only use seat belts which have been approved by Mercedes-Benz for your vehicle. Seat belts are the most effective means of restraining the movement of vehicle occu- You can also extend seat-belt extender : by pants in the event of an accident.
  • Page 54 Occupant safety Seat belt adjustment The seat-belt adjustment function adjusts the driver's and front-passenger seat belt to the upper body of the occupants. The belt strap is tightened slightly when: you engage the belt tongue in the belt buckle and you then turn the key to position 2 in the ignition lock.
  • Page 55 Occupant safety Rear seat belt status indicator Display for securely fastened occupants on right side of rear compartment (example) The rear-compartment seat belt status indi- cator tells you if the rear passengers have their seat belts fastened. The rear-compart- ment seat belt status indicator indicates the rear seat on which the belt is fastened.

  • Page 56: Children In The Vehicle

    Comply with safety regulations when dispos- ing the initial stages of the impact ing of belt tensioners. Any Mercedes-Benz if, in the event of a side impact, on the side Service Centre can provide details of these opposite the impact the vehicle deceler- regulations.
  • Page 57 Mercedes-Benz Service Centre. Mercedes-Benz vehicles. It is advisable to use Mercedes-Benz care products to clean child restraint systems. WARNING You can obtain information about this at Do not leave children unsupervised in the any Mercedes-Benz Service Centre.
  • Page 58 Always comply with the manufacturer's Information about recommended child installation instructions. restraint systems is available at any Mercedes-Benz Service Centre. Press the seat belt release button and guide the belt tongue to the belt outlet. The child seat lock function is deactivated.
  • Page 59 Children in the vehicle only use a forward-facing child restraint system on the front-passenger seat and move the front-passenger seat to the rear- most position. have the automatic child seat recognition checked at a qualified specialist workshop. To ensure that the automatic child seat rec- ognition on the front-passenger seat func- tions/communicates correctly, never place objects, e.g.
  • Page 60 The front-passenger seat sensor system for child restraint systems detects whether a For this reason, have child restraint systems special Mercedes-Benz child seat with a and their anchorages which have been dam- transponder for automatic child seat recog- aged or subjected to a load in an accident nition has been fitted.
  • Page 61 Fold up cover ; of Top Tether anchorage and right of the rear seats. Mercedes-Benz recommends the use of ISO- FIX child restraint systems listed together Route Top Tether belts A on the left and with the insertion guides included right past head restraint :.
  • Page 62 Children in the vehicle Make sure that Top Tether belt A is not twisted. Fit the ISOFIX child restraint system with Top Tether. Comply with the manufactur- er's installation instructions when doing so. Make sure that Top Tether belt A is tight.
  • Page 63 Problem Possible causes/consequences and M Solutions The 4 PASSENGER A special Mercedes-Benz child seat with a transponder for auto- matic child seat recognition has been fitted to the front-passenger AIRBAG OFF indicator seat. The front-passenger front airbag has therefore been disabled lamp on the centre con- as desired.
  • Page 64 Children in the vehicle transponder for automatic child seat recog- "Universal" category which are approved nition must be fitted when the front- for use in this weight category. passenger airbag is disabled. The 4 Suitable for ISOFIX child restraint sys- PASSENGER AIRBAG OFF indicator lamp tems as recommended;...
  • Page 65 Children in the vehicle Weight category I: 9 to 18 kg, approx- Size cate- Equipment Rear seat, imately 9 months to 4 years gory left and right Manufac- Britax Römer Britax Römer turer ISO/F2X Type DUO PLUS DUO PLUS ISO/F3 Approval 03 301133 03 301133...
  • Page 66 Children in the vehicle Order num- Approval 970 18 00 970 19 00 04 301146 – number (A 000 ...) (E1 ...) Automatic Order num- B6 6 86 – child seat 8224 recognition Automatic – child seat Suggested "Universal" category ISOFIX recognition child restraint systems: Carry-cot weight category...
  • Page 67 Driving safety systems Driving safety systems be seriously or even fatally injured by pro- longed exposure to extreme heat or cold. Driving safety systems overview Do not expose the child restraint system to In this section, you will find information about direct sunlight.

  • Page 68: Driving Safety Systems

    Driving safety systems tions as a reminder to take extra care while ABS (Anti-lock Braking System) driving. Important safety notes Observe the "Important safety notes" sec- BAS (Brake Assist System) tion ( page 64). Observe the "Important safety notes" sec- WARNING tion ( page 64).
  • Page 69 Driving safety systems If you are driving at a speed over For BAS PLUS to assist you when driving, the 30 km/h: if you depress the brake sharply, radar sensor system must: BAS PLUS automatically raises the brake be switched on ( page 245) pressure to a value adapted to the traffic sit- be operational (...
  • Page 70 Driving safety systems cialist workshop. This also applies to colli- Observe the information on warning lamps sions at slow speeds where there is no visible page 278) and display messages which damage to the front of the vehicle. may be shown in the instrument cluster page 250).
  • Page 71 Driving safety systems the vehicle/trailer combination from swerv- ® Only deactivate ESP in the situations descri- ing. Trailers with a high centre of gravity can bed in the following. ® tip over before ESP can detect this. There is To deactivate:( page 240).
  • Page 72 Driving safety systems vehicle automatically at speeds up to approx- ADAPTIVE BRAKE imately 200 km/h. ADAPTIVE BRAKE enhances braking safety Due to the nature of the system, particularly and offers increased braking comfort. In addi- complicated driving conditions may cause tion to the braking function, ADAPTIVE BRAKE unnecessary warnings or the unnecessary also has the HOLD function (...
  • Page 73 Driving safety systems WARNING ® As a result, PRE-SAFE Brake may neither give warnings nor intervene in all critical sit- ® PRE-SAFE Brake will initially brake your vehi- uations. There is a risk of an accident. cle by a partial application of the brakes if a danger of collision is detected.

  • Page 74: Ata (Anti-Theft Alarm System)

    Anti-theft systems For information on switching off the radar To prime: lock the vehicle with the key or sensor system using the on-board computer, KEYLESS-GO. see ( page 245). Indicator lamp : flashes. The alarm sys- tem is primed after approximately Following damage to the front end of the vehi- 15 seconds.

  • Page 75: Interior Motion Sensor

    Anti-theft systems Activating To prevent a false alarm, deactivate the tow- away protection if you lock your vehicle and Make sure that: the doors are closed. is being transported the boot lid is closed. is being loaded onto a ferry or car trans- Only then is the tow-away protection porter, for example primed.
  • Page 76 Anti-theft systems To deactivate inside after the vehicle has been locked from the outside. Observe the "Important Unlock the vehicle with the key or KEY- safety notes" ( page 82). LESS-GO. The interior motion sensor is switched off automatically. Deactivating Remove the key from the ignition lock.
  • Page 78 Useful information ......76 Key ............76 Doors ............ 82 Boot ............85 Side windows ........87 Soft top (Cabriolet) ......92 Sliding sunroof (Coupé) ....103...

  • Page 79: Useful Information

    Useful information open a door from inside the vehicle at any time, even if it has been locked This Owner's Manual describes all mod- start the vehicle using a key which has been els, series and optional equipment for your left in the vehicle vehicle that were available at the time of release the parking brake...
  • Page 80 Locking and unlocking centrally Key functions You can start, lock or unlock the vehicle using KEYLESS-GO. To do this, you only need carry the key with you. When you touch the surface of the sensors on the vehicle's outside door handles, KEYLESS-GO establishes a radio connection between the vehicle and the key.
  • Page 81 Changing the settings of the locking Emergency key element system General notes You can change the settings of the locking If the vehicle can no longer be locked or system. This means that only the driver's door unlocked with the key, use the emergency and the fuel filler flap are unlocked when the key element.
  • Page 82 Take discharged batteries to a qualified spe- cialist workshop or to a col- lection point for used batter- ies. Mercedes-Benz recommends that you have the batteries replaced at a qualified specialist Battery compartment cover workshop. Emergency key element Checking the battery Press emergency key element ;...
  • Page 83 Battery Repeatedly tap the key against your palm until battery = falls out. Insert the new battery with the positive ter- minal facing upwards. Use a lint-free cloth to do so. Make sure that the surface of the battery is free from lint, grease and all other forms of contamination.
  • Page 84 Problems with the key Problem Possible causes/consequences and M Solutions You cannot lock or The key battery is discharged or nearly discharged. unlock the vehicle Try again to lock/unlock the vehicle using the remote control using the key. function of the key. Point the tip of the key at the driver's door handle from close range and press the % or &...
  • Page 85 Doors Problem Possible causes/consequences and M Solutions You have lost the emer- Report the loss immediately to the vehicle insurers. gency key element. If necessary, have the locks changed as well. The engine cannot be the on-board voltage is too low. started using the key.

  • Page 86: Doors

    Doors Pull door handle ;. They could thereby endanger themselves and If the door is locked, locking knob : pops others. Never leave children unsupervised in up. The door is unlocked and can be the vehicle. Always take the key with you opened.
  • Page 87 Doors If the vehicle has been locked using the lock- Unlocking the driver's door (emer- ing button for the central locking, or has been gency key element) locked automatically, and a door is opened If the vehicle can no longer be unlocked with from the inside: the key, use the emergency key element.

  • Page 88: Boot

    Boot ! The boot lid swings upwards when Check whether the locking knob on the front-passenger door is still visible. Press opened. Therefore, make sure that there is down the locking knob by hand, if neces- sufficient clearance above the boot lid. sary ( page 83).
  • Page 89 Boot ! The boot lid swings upwards when opened. Therefore, make sure that there is sufficient clearance above the boot lid. Opening dimensions of the boot lid page 378). To open You can unlock and open the boot lid simul- taneously with the key.

  • Page 90: Side Windows

    Side windows Close the boot lid. Take the emergency key element out of the key ( page 78). Neutral position To unlock Turn the emergency key element anti- clockwise from position 1 as far as it will Basic position go to position 2. Pulling the boot lid han- Locking dle at the same time.
  • Page 91 Side windows WARNING Children may injure themselves if they open or close the side windows. Never leave children unsupervised in the vehi- cle. Always take the key with you when leaving the vehicle, even if you are only leaving it for a short time.
  • Page 92 Side windows To close all side windows: press the & button on the key until the side win- dows are fully closed. To interrupt the closing procedure: release the & button. Convenience closing with KEYLESS-GO WARNING When using the convenience closing feature, make sure that nobody can become trapped.
  • Page 93 Side windows Convenience opening (Coupé) With the key: release the & button. General notes press and hold the % button until the You can ventilate the vehicle before you start side windows and the panorama sliding driving. To do this, the key is used to carry out sunroof open again.
  • Page 94 Side windows If the side window opens again slightly: Immediately pull the corresponding switch on the door control panel until the side win- dow is completely closed ( page 88). Hold the switch for an additional second. If the corresponding side window remains closed after the button has been released, the side window has been reset correctly.
  • Page 95 Soft top (Cabriolet) Problems with the side windows WARNING Closing the side windows with increased force or without the anti-entrapment feature could lead to serious or even fatal injury. Make sure that nobody can become trapped when closing the side windows.
  • Page 96 In this case, reduce speed or stop in order to close the soft top fully. For safety reasons, Mercedes-Benz recom- mends that you only open or close the soft top when the vehicle is stationary.
  • Page 97 Soft top (Cabriolet) If the soft top cannot be closed automatically, The side windows close if you keep on check the following points: pressing the soft-top switch. Is the boot separator engaged page 99)? Opening and closing with the key Are the head restraints on the rear bench seats extended? Important safety notes...

  • Page 98: Soft Top (Cabriolet)

    Soft top (Cabriolet) Turn rotary catch : anti-clockwise and Pull out catch B on both sides as far as it fold down cover ;. will go and turn it approximately a quarter of a turn anti-clockwise. Make sure catch B is not drawn in again. If this happens, pull out catch B again as far as possible and turn it about a quarter turn anti-clockwise.
  • Page 99 Soft top (Cabriolet) Pull the straps between the soft-top com- Each person takes a strap. partment hinges and the soft-top compart- Pulling with force, simultaneously lift out ment. the cover of the soft-top compartment back/up by the straps in the direction of Do not pull the straps as long as the boot the arrow.
  • Page 100 Soft top (Cabriolet) WARNING Do not reach between the cover halves and the hinges. You could otherwise become trap- ped. To open To lock Pull off the cover of the roof lock behind the overhead control panel. Insert the Allen key into the roof lock. Reach under the tip of soft top G in the Turn the Allen key clockwise I as far as soft-top compartment from the right-hand...
  • Page 101 Soft top (Cabriolet) WARNING You could trap your hands. Do not push the soft-top compartment cover forwards in front of the soft-top support with your hands. Insert the Allen key into the roof lock. Turn the Allen key anti-clockwise N as far as possible.
  • Page 102 ! Mercedes-Benz recommends that you place any objects in or behind the net on only use draught stops which have been the side that are so long they could...
  • Page 103 Soft top (Cabriolet) When installing the draught stop, use lat- Turn the key to position 2 in the ignition eral brackets :. lock. Open the cover on the lower centre con- Observe the manufacturer's installation sole. instructions. Press AIRCAP button :. The two indicator lamps on the AIRCAP but- AIRCAP ton light up.
  • Page 104 Soft top (Cabriolet) Removing AIRCAP cannot be extended or retracted if the vehicle speed exceeds 160 km/h. Retracting AIRCAP Turn the key to position 2 in the ignition lock. Open the cover on the lower centre con- sole. Press AIRCAP button :. The two indicator lamps on the AIRCAP but- ton go out.
  • Page 105 Soft top (Cabriolet) Fitting Keeping the AIRCAP draught stop horizon- tal, guide it into the slot between the head restraints in the direction of the arrow with both racks straight down. Push the AIRCAP draught stop down until the bolts are at the same height as the brackets on the head restraints.

  • Page 106: Sliding Sunroof (Coupé)

    Sliding sunroof (Coupé) Problems with the soft top Problem Possible causes/consequences and M Solutions The soft top will not The ignition is not switched on. open or close. Make sure that the key is in position 2 in the ignition lock. The boot lid is open.
  • Page 107 Sliding sunroof (Coupé) If you press the 3 switch beyond the Never leave children unsupervised in the vehi- point of resistance, an automatic opening/ cle. Always take the key with you when leaving closing process is started in the corre- the vehicle, even if you are only leaving it for sponding direction.
  • Page 108 Sliding sunroof (Coupé) Opening and closing until the panorama sliding sunroof is fully closed ( page 105). Keep the 3 switch pulled for an addi- tional second. Pull the 3 switch repeatedly to the point of resistance in the direction of arrow = until the roller sunblind is fully closed.
  • Page 109 Sliding sunroof (Coupé) Problems with the sliding sunroof WARNING You could be severely or even fatally injured when closing the sliding sunroof with increased closing force or if the anti-entrapment feature is deactivated. Make sure that nobody can become trapped when closing the sliding sunroof. In the following section, the term "sliding sunroof"...
  • Page 110 Useful information ......108 Correct driver's seat position ..108 Seats ..........109 Steering wheel ........115 Mirrors ..........117 Memory function ......120...

  • Page 111: Useful Information

    Correct driver's seat position you can fasten the seat belt properly. Useful information you have moved the backrest to an almost vertical position. This Owner's Manual describes all mod- els, series and optional equipment for your you have set the seat angle so that your vehicle that were available at the time of thighs are gently supported.

  • Page 112: Seats

    Seats settings with the memory function head restraint. If your head is not supported page 120). correctly by the head restraint, you could suf- fer a severe neck injury in the event of an accident. Never drive if the head restraints are Seats not engaged and set correctly.
  • Page 113 Seats heating should also not be used to dry Seat cushion angle the seats. Seat fore-and-aft adjustment clean the seat covers as recommended; Seat fore-and-aft adjustment: see "Interior care". Lift handle ? and slide the seat forwards do not transport heavy loads on the or backwards.
  • Page 114 Seats Rear seat head restraints Vehicles with memory function: when the seat is moved forwards or backwards, the Lowering and extending the rear seat headrest is moved up or down automati- head restraints from the front (Cabriolet) cally. Adjusting the head restraints Adjusting the head restraints manually Adjusting the head restraint height Make sure the key is in position 2 in the...
  • Page 115 Seats Lower the head restraints in the rear com- Folding the front-seat backrests partment manually if: forward/back the head restraint electronics are malfunc- Important safety notes tioning. the opening or closing procedure of the soft WARNING top is interrupted, leaving the soft top com- Make sure that the backrest engages fully.
  • Page 116 Seats Vehicles without memory function: To adjust the backrest contour in the release the head restraint if necessary and upper back region push it down. To adjust the side bolsters of the seat Pull seat release handle : forwards and backrest fold the backrest forwards until the seat You can adjust the contour of the front seats...
  • Page 117 Seats Switching the seat ventilation on/off Switching on/off Driver's and front-passenger seat The three red indicator lamps in the button indicate the heating level you have selected. The system automatically switches down The three blue indicator lamps in the buttons from level 3 to level 2 after approximately indicate the ventilation level you have selec- eight minutes.

  • Page 118: Steering Wheel

    Steering wheel Problems with the seat ventilation Press button : repeatedly until the desired heating level is set. The seat ventilation has switched off prema- To switch off: press button : repeatedly turely or cannot be switched on. The vehicle's until all the indicator lamps go out.
  • Page 119 Steering wheel Further related subjects: Adjusting the steering wheel man- ually EASY-ENTRY/EXIT feature page 116) Storing settings ( page 120) EASY-ENTRY/EXIT feature Important safety notes WARNING Make sure that nobody can become trapped when you activate the EASY-ENTRY/EXIT fea- ture. Release lever If there is a risk of someone becoming trap- To adjust the steering wheel height...

  • Page 120: Mirrors

    Mirrors Position of the steering wheel when the Mirrors EASY-ENTRY/EXIT feature is active Rear-view mirror The steering wheel tilts upwards if you: remove the key from the ignition lock open the driver's door and KEYLESS-GO is in position 1 open the driver's door and the key is in position 0 or 1 in the ignition lock The steering wheel only moves upwards if it has not already reached the upper end...
  • Page 121 Mirrors Setting the exterior mirrors Make sure that the key is in position 1 or 2 in the ignition lock. If the battery has been disconnected or com- Press button : for the left-hand exterior pletely discharged, the exterior mirrors must mirror or button ;...
  • Page 122 Mirrors Make sure that the vehicle is stationary and Automatic anti-dazzle mirrors that the key is in position 2 in the ignition WARNING lock. If incident light from headlamps is prevented Press button ; for the exterior mirror on from striking the sensor in the rear-view mir- the front-passenger side.

  • Page 123: Memory Function

    Memory function Calling up a stored parking position set- The following settings are stored as a single ting memory preset: position of the seat, backrest and head Turn the key to position 2 in the ignition restraint lock. driver's side: steering wheel position Adjust the exterior mirror on the front- passenger side using button ;.
  • Page 124 Useful information ......122 Exterior lighting ........ 122 Interior lighting ......... 131 Replacing bulbs ......... 132 Windscreen wipers ......135...

  • Page 125: Useful Information

    Turn housing cover : anti-clockwise and pull it out. Important safety notes Push switchover lever ; down. For reasons of safety, Mercedes-Benz recom- Insert housing cover : and turn it clock- mends that you drive with the lights switched wise.

  • Page 126: Exterior Lighting

    Exterior lighting combination switch ( page 126) cally. This could endanger you and others. In on-board computer ( page 243) such situations turn the light switch to L. The automatic headlamp feature is only an Light switch aid. The driver is responsible for the vehicle's lighting at all times.
  • Page 127 Exterior lighting To switch on automatic headlamp Even if the light sensor does not detect that mode: turn the light switch to Ã. is dark, the side lamps and dipped-beam headlamps switch on when the key is inserted The daytime driving lights improve the visibil- into the ignition lock and the light switch is ity of your vehicle during the day.
  • Page 128 Exterior lighting Press the N button. Press the R button. The green N indicator lamp in the instru- The yellow R indicator lamp in the ment cluster lights up. instrument cluster lights up. To switch off the front foglamps: press To switch off the rear foglamp: press the the N button.
  • Page 129 Exterior lighting Parking lamps Driver's seat and front-passenger seat occupied Left-hand parking lamps Driver's seat, front-passenger seat and Right-hand parking lamps rear seats occupied Side lamps, licence plate and instru- Driver's seat, front-passenger seat and ment cluster lighting rear seats occupied, boot laden Automatic headlamp mode, control- 4Ã...
  • Page 130 Exterior lighting To indicate briefly: press the combination Vehicles with Adaptive Highbeam Assist: switch briefly to the pressure point in the when Adaptive Highbeam Assist is active, direction of arrow ; or ?. it controls activation of the main-beam headlamps ( page 129).
  • Page 131 Exterior lighting Active light function only the turn signal lamp on the corre- sponding side of the vehicle will flash. To switch off the hazard warning lamps: press button :. The hazard warning lamps automatically switch on if: an airbag is deployed. the vehicle decelerates rapidly from a speed of more than 70 km/h and comes to a standstill.
  • Page 132 Exterior lighting The cornering lamp may remain lit for a short Adaptive Highbeam Assist time, but is automatically switched off after Important safety notes no more than three minutes. WARNING Motorway mode Adaptive Highbeam Assist is only an aid designed to assist driving. The driver is responsible for adjusting the vehicle's lighting to the prevailing light, vision and traffic con- ditions.
  • Page 133 Exterior lighting Switching Adaptive Highbeam Assist on/off Main-beam headlamps Turn signal, right Headlamp flasher Turn signal, left To activate: activate the Adaptive High- You can use this function to set the head- beam Assist function using the on-board lamps to change between dipped beam and computer ( page 244).

  • Page 134: Interior Lighting

    Interior lighting indicator lamp in the multifunction display c Switches the front interior lighting remains lit. on/off To deactivate: move the combination p Switches the left-hand reading lamp switch back to its normal position. on/off The _ indicator lamp in the instrument cluster goes out.
  • Page 135 Replacing bulbs The interior lighting automatically switches Crash-responsive emergency lighting on if you: The interior lighting is activated automatically unlock the vehicle if the vehicle is involved in an accident. open a door To switch off the crash-responsive remove the key from the ignition lock emergency lighting: press the hazard The interior lighting is activated for a short warning lamp button.

  • Page 136: Replacing Bulbs

    Replacing bulbs Keep bulbs out of the reach of children. Oth- erwise, they could damage the bulbs, for example, and injure themselves. Never use a bulb which has been dropped. Such a bulb may break or even explode and injure you. Halogen bulbs are pressurised and can explode when you change them, particularly if they are very hot.
  • Page 137 Due to their location, have the bulbs in the Open the bonnet. left-hand headlamp changed at a qualified Turn housing cover : anti-clockwise and specialist workshop, e.g. a Mercedes-Benz pull it out. Service Centre. Turn bulb holder ; anti-clockwise and pull Switch off the lights.

  • Page 138: Windscreen Wipers

    Windscreen wipers Pull out bulb holder ;. tions, thereby causing an accident. Replace the wiper blades twice a year, ideally in spring Take the bulb out of bulb holder ;. and autumn. Insert the new bulb into bulb holder ;. Insert bulb holder ;.
  • Page 139 Mercedes-Benz recommends that you have the wiper blades changed at a qualified Switch off the engine using the Start/Stop button and open the driver's door.
  • Page 140 Windscreen wipers The windscreen wipers are inoperative The windscreen wiper drive is malfunctioning. Select another wiper speed on the combi- nation switch. Have the windscreen wipers checked at a qualified specialist workshop.
  • Page 142 Useful information ......140 Overview of climate control sys- tems ........... 140 Operating the climate control sys- tem ............. 143 Adjusting the air vents ..... 153...

  • Page 143: Useful Information

    Overview of climate control systems interval for replacing the filter, which is Useful information specified in the Service Booklet. As it depends on environmental conditions, e.g. This Owner's Manual describes all mod- heavy air pollution, the interval may be els, series and optional equipment for your shorter than stated in the Service Booklet.

  • Page 144: Overview Of Climate Control Systems

    Overview of climate control systems Control panel for THERMATIC automatic climate control (2-zone) Activates/deactivates air-recirculation mode ( page 147) Demists the windscreen ( page 146) Switches the ZONE function on/off ( page 146) Display Sets climate control to automatic mode ( page 144) Switches cooling with air dehumidification on/off ( page 143)
  • Page 145 Overview of climate control systems Control panel for THERMOTRONIC automatic climate control (3-zone) Front control panel Sets climate control to automatic mode ( page 144) Demists the windscreen ( page 146) Switches the ZONE function on/off ( page 146) Display Activates/deactivates air-recirculation mode ( page 147) Activates/deactivates the residual heat function (...

  • Page 146: Operating The Climate Control System

    Operating the climate control system Switching on/off Information about using THERMOTRONIC automatic climate Turn the key to position 2 in the ignition control lock. The following contains instructions and rec- To switch on: press the à button. ommendations to enable you to get the most The indicator lamp above the Ã...
  • Page 147 Operating the climate control system Switching on/off THERMATIC automatic climate control: press button F( page 141). To activate: press the ¿ button. THERMOTRONIC automatic climate con- The indicator lamp above the ¿ button trol: press button I( page 142). lights up. The indicator lamp above the Ã...
  • Page 148 Operating the climate control system THERMOTRONIC automatic climate Setting the air distribution control Air distribution settings P Directs the airflow through the centre and side air vents O Directs the airflow through the foot- well air vents S Directs airflow through the centre, side and footwell air vents (Cabriolet or Coupé...
  • Page 149 Operating the climate control system Switch off the "demisting" function as soon Setting the airflow as the windscreen is clear again. THERMATIC automatic climate control Turn the key to position 2 in the ignition lock. Turn the key to position 2 in the ignition lock.
  • Page 150 Operating the climate control system Turn the key to position 2 in the ignition Demisting the windows lock. Windows misted up on the inside Press the ¤ button. The indicator lamp above the ¤ button Activate the ¿ cooling with air dehu- lights up or goes out.
  • Page 151 Operating the climate control system matically, the indicator lamp above the dows and the panorama sliding sunroof g button does not light up. are closed. The indicator lamp above the g button Outside air is added after about lights up. Air-recirculation mode is activa- 30 minutes.
  • Page 152 Operating the climate control system have heated or ventilated the vehicle a If you activate the residual heat function maximum of two times, drive for a longer at high temperatures, only the ventilation distance. will be activated. The blower runs at medium speed.
  • Page 153 Operating the climate control system Switching the auxiliary heating/venti- the remote control being in an unfavoura- lation on/off using the centre console ble position in relation to the vehicle button transmitting from an enclosed space The colours of the indicator lamps on the but- The optimum range can be achieved if you ton have the following meanings: hold the remote control vertically, pointing...
  • Page 154 Operating the climate control system The following messages may appear in the Press the , or . button to set the display: desired departure time. The longer you press the , or . Display Meaning button, the faster the time changes. The auxiliary heating/ Press the u and ^ buttons simulta- ventilation is switched...
  • Page 155 Operating the climate control system environmentally responsible recycling system. Dispose of batteries in an environmentally responsible manner. Take discharged batteries to a qualified spe- cialist workshop or to a col- lection point for used batter- ies. One 6 V pin battery, type 2CR11108 is required.

  • Page 156: Display Message

    Adjusting the air vents Problems with the auxiliary heating/ventilation Display messages Possible causes/consequences and M Solutions The starter battery is not charged sufficiently or the system is FAIL faulty. Charge the starter battery. Make another attempt to switch on the auxiliary heating using the remote control.
  • Page 157 Adjusting the air vents midification" function. Otherwise, temper- Setting the centre air vents ature-sensitive items stored in the glove compartment could be damaged. : Centre air vent, left ; Centre air vent, right Air vent thumbwheel = Centre vent thumbwheel, right Air vent ? Centre vent thumbwheel, left When automatic climate control is activated,...
  • Page 158 Adjusting the air vents Rear control unit, only with THERMOTRONIC automatic climate con- trol Rear-compartment air vent, left To open/close: turn thumbwheel : up or down. Setting the AIRSCARF vents WARNING Very hot air can flow out of the AIRSCARF vents in the head restraints when AIRSCARF is in operation.
  • Page 160 Useful information ......158 Running-in notes ....... 158 Driving ..........158 Manual transmission ......166 Automatic transmission ....167 Refuelling ........... 173 Parking ..........177 Driving tips ........179 Driving systems ........ 182 Towing a trailer ......... 220...

  • Page 161: Useful Information

    Driving After 1500 km, you may gradually accelerate Useful information the vehicle to full road and engine speeds. This Owner's Manual describes all mod- You should also observe these notes on els, series and optional equipment for your running in if the engine or parts of the drive vehicle that were available at the time of train on your vehicle have been replaced.
  • Page 162 Driving KEYLESS-GO WARNING If the parking brake has not been fully General notes released when driving, the parking brake can: Do not keep the KEYLESS-GO key together overheat and cause a fire with: lose its hold function. electronic devices, e.g. a mobile phone There is a risk of fire and an accident.
  • Page 163 Driving Switching on the power supply time. You can then use Start/Stop but- ton :. Position 0: if Start/Stop button : has not yet been pressed, this corresponds to the key being removed from the ignition. Starting the engine Position 1: press Start/Stop button :. Important safety notes The power supply is switched on.
  • Page 164 Driving To start a petrol engine: turn the key to Depress the brake pedal and keep it position 3 in the ignition lock depressed. page 159) and release it as soon as the To start a petrol engine: press the Start/ engine is running.
  • Page 165 Driving Take your foot off the brake pedal. When engaging transmission position D or R, The vehicle is then held for about a second. always firmly depress the brake pedal and do Pull away. not simultaneously accelerate. Hill start assist will not function if: Depress the brake pedal and keep it you are pulling away on a level road or a depressed.
  • Page 166 Driving Automatic engine switch-off Vehicles with manual transmission Method of operation The ECO start/stop function is operational and the ¤ symbol is displayed in green in the multifunction display, if: the indicator lamp in the ECO button is lit green. the vehicle is stationary.

  • Page 167: Automatic Engine Start (Eco Start/ Stop Function)

    Driving Automatic engine start Deactivating/activating the ECO start/ stop function General notes The engine is started automatically if: you switch off the ECO start/stop function by pressing the ECO button. you engage reverse gear R. the vehicle starts to roll. the brake system requires this.
  • Page 168 Driving Problems with the engine Problem Possible causes/consequences and M Solutions The engine does not The HOLD function or DISTRONIC PLUS is activated. start. Deactivate the HOLD function ( page 198) or DISTRONIC PLUS ( page 196). Try to start the engine again. The engine does not There is a malfunction in the engine electronics.

  • Page 169: Manual Transmission

    Manual transmission Problem Possible causes/consequences and M Solutions Vehicles with a petrol There is a malfunction in the engine electronics or in a mechanical engine: component of the engine management system. The engine is not run- Only depress the accelerator pedal slightly. ning smoothly and is Otherwise, non-combusted fuel may get into the catalytic con- misfiring.

  • Page 170: Automatic Transmission

    Automatic transmission ! On long and steep downhill gradients, Gearshift recommendation especially if the vehicle is laden or towing a trailer, you must shift into gear 1, 2 or 3 in good time. This uses the engine's braking effect. This relieves the load on the brake system and prevents the brakes from over- heating and wearing too quickly.
  • Page 171 Automatic transmission Selector lever Transmission positions Overview of transmission positions Park position This prevents the vehicle from roll- ing away when stopped. Do not shift the transmission into position page 177) unless the vehicle is stationary. The key can only be removed if the transmission is in position P.

  • Page 172: Accelerator Pedal Position

    Automatic transmission the position of the accelerator pedal Program selector button the road speed General notes Driving tips Accelerator pedal position Your style of driving influences how the auto- matic transmission shifts gear: little throttle: early upshifts more throttle: late upshifts Double-clutch function Program selector button E 350 BlueEFFICIENCY and E 500 BlueEF-...
  • Page 173 Automatic transmission The program selector button allows you to Automatic drive program choose between different driving character- Drive program E is characterised by the fol- istics. lowing: E Economy Comfortable, economical comfort-oriented engine settings driving optimal fuel consumption resulting from the automatic transmission shifting up S Sport Sporty driving style...
  • Page 174 Automatic transmission Clearing the shift range restriction Shift range: Press and hold the selector lever towards = To use the engine's braking effect D+ until D is shown once more in the mul- 5 To use the braking effect of the tifunction display.
  • Page 175 Automatic transmission Upshifting Briefly press the selector lever to the right towards D+. Pull the right-hand steering wheel gearshift paddle. The automatic transmission shifts up to the next gear. Downshifting Briefly press the selector lever to the left towards D–. Pull the left-hand steering wheel gearshift paddle.

  • Page 176: Releasing The Parking Lock Manually

    Refuelling Problems with the transmission Problem Possible causes/consequences and M Solutions The transmission has The transmission is losing oil. problems shifting gear. Have the transmission checked at a qualified specialist work- shop immediately. The acceleration ability The transmission is in emergency mode. is deteriorating.
  • Page 177 Refuelling Refuelling WARNING Avoid contact with fuels. Opening/closing the fuel filler flap It is hazardous to your health if your skin comes into direct contact with fuels or you breathe in fuel vapours. WARNING Do not use petrol to refuel a diesel tank. Never mix diesel with petrol.
  • Page 178 Refuelling Completely insert the filler neck of the fuel pump nozzle into the tank and refuel. Only fill the tank until the pump nozzle switches off. Do not add any more fuel after the pump stops filling for the first time. Otherwise, fuel may leak out.
  • Page 179 Refuelling Problems with the fuel and fuel tank Problem Possible causes/consequences and M Solutions Fuel is leaking from the Risk of explosion or fire vehicle. The fuel line or the fuel tank is faulty. Turn the key to position 0 in the ignition lock immediately and remove it ( page 159).

  • Page 180: Starting The Engine

    Parking Problem Possible causes/consequences and M Solutions The fuel filler flap can- The fuel filler flap is not unlocked. not be opened. The key battery is discharged. Unlock the vehicle ( page 77). Unlock the vehicle using the emergency key element page 78).
  • Page 181 Parking Switching off the engine apply the parking brake too firmly. If the wheels lock, release the parking brake until Vehicles with manual transmission the wheels begin turning again. Shift to either first gear or reverse gear R. WARNING Turn the key to position 0 in the ignition If you leave children unattended in the vehi- lock and remove it.

  • Page 182: Driving Tips

    Driving tips The ECO display consists of three bars: Parking up the vehicle Acceleration If you leave the vehicle parked up for longer Constant than four weeks, the battery may be damaged by exhaustive discharging. Coasting If you leave the vehicle parked up for longer The percent value is the average value of the than six weeks, the vehicle may suffer dam- three bars.
  • Page 183 Driving tips Coasting (evaluation of total decelera- minute trip on a motorway or rural road at tion) least every 500km. The bar fills up: The bar depletes: Braking Drive with care, Frequent braking keep your distance Important safety notes from the vehicle ahead and remove WARNING your foot from the...
  • Page 184 This improves the grip of the which correspond to an equivalent quality brakes. standard. Brake pads/linings which have not been approved for Mercedes-Benz vehicles or Wet road surfaces which are not of an equivalent quality could affect your vehicle's operating safety.
  • Page 185 Driving systems If the vehicle threatens to skid or cannot be Winter driving stopped when moving at low speed: Important safety notes Vehicles with manual transmission: shift to neutral. WARNING Vehicles with automatic transmission: If you shift down on a slippery road surface in shift the transmission to position N.

  • Page 186: Driving Systems

    Driving systems To switch between cruise control and var- or winding roads). You may otherwise iable SPEEDTRONIC cause an accident. To deactivate cruise control on slippery roads. The drive wheels may lose their grip when braking or accelerating You can operate cruise control and variable and the vehicle may skid.
  • Page 187 Driving systems Storing the current speed and calling up If it is not, press the cruise control lever in the last stored speed the direction of arrow ;. LIM indicator lamp : in the cruise control WARNING lever goes out. Cruise control is selected. Only call up a stored speed if you know what that speed is and if it is suitable for the current Storing and maintaining the current...
  • Page 188 Driving systems Press the cruise control lever up : for a higher speed or down ; for a lower speed. Briefly press the cruise control lever in the direction of arrow ;. Keep the cruise control lever pressed until Variable SPEEDTRONIC is selected. LIM the desired speed is reached.
  • Page 189 Driving systems To store the current speed and call up the WARNING last stored speed SPEEDTRONIC is only an aid designed to To store the current speed or a lower assist driving. You are responsible for the speed vehicle's speed and for braking in good time. To switch between cruise control or DIS- SPEEDTRONIC brakes automatically so that TRONIC PLUS and variable SPEEDTRONIC...
  • Page 190 Driving systems Check whether LIM indicator lamp : is on. If it is on, variable SPEEDTRONIC is already selected. If it is not, press the cruise control lever in the direction of arrow ;. LIM indicator lamp : in the cruise control lever lights up.
  • Page 191 Driving systems Permanent SPEEDTRONIC a higher speed or down ; for a lower speed. You can use the on-board computer to limit the speed permanently to a value between Deactivating variable SPEEDTRONIC 160 km/h(e.g. for driving on winter tyres) and WARNING the maximum speed ( page 245).
  • Page 192 Driving systems General notes WARNING DISTRONIC PLUS cannot take account of road DISTRONIC PLUS regulates the speed and and traffic conditions. If DISTRONIC does not automatically helps you maintain the dis- recognise or no longer recognises the vehicle tance to the vehicle detected in front. DIS- in front, do not activate DISTRONIC or, if it is TRONIC PLUS brakes automatically so that already active, deactivate it.
  • Page 193 Driving systems Cruise control lever Activation conditions To activate DISTRONIC PLUS, the following conditions must be fulfilled: the engine must be running. It may take up to two minutes of driving before DIS- TRONIC PLUS is ready for use. the parking brake must be released. ®...
  • Page 194 Driving systems DISTRONIC PLUS switches off and you will If the vehicle in front pulls away: remove hear a tone. your foot from the brake pedal. Briefly pull the cruise control lever towards If you do not fully release the accelerator you ;, or press it up : or down =.
  • Page 195 Driving systems tance between your vehicle and the vehicle in Vehicles with COMAND Online front becomes too small. The following function is not operational in all countries. When changing lanes, DISTRONIC PLUS monitors the left lane for left-hand-drive DISTRONIC PLUS uses additional information vehicles and the right lane for right-hand- from your navigation system so that it can drive vehicles.
  • Page 196 Driving systems Shift the transmission to position P to pre- DISTRONIC PLUS must also never be oper- vent the vehicle from rolling away. ated, activated or deactivated by a passenger DISTRONIC PLUS is deactivated. The warn- or from outside the vehicle. ing message in the multifunction display DISTRONIC PLUS does not replace the park- disappears.
  • Page 197 Driving systems Release the cruise control lever. Briefly pull the cruise control lever towards The new speed is stored. DISTRONIC PLUS you :. is activated and adjusts the vehicle's speed Remove your foot from the accelerator to the new speed stored. pedal.
  • Page 198 Driving systems Displaying DISTRONIC PLUS in the Display when DISTRONIC PLUS is deacti- speedometer vated Vehicle in front, if detected When DISTRONIC PLUS is activated, one or Distance indicator: current distance to two segments ; in the set speed range light the vehicle in front Specified minimum distance to the vehi- If DISTRONIC PLUS detects a vehicle in front,...
  • Page 199 Driving systems Select the Distance display function ® ® intervenes or you deactivate ESP using the on-board computer the transmission is in the P, R or N position. page 240). the vehicle is near a radio telescope facility page 382). You will see the stored speed for about you switch off the radar sensor system five seconds when you activate DISTRONIC...
  • Page 200 Driving systems The ability of DISTRONIC PLUS to detect vehi- DISTRONIC PLUS has not yet detected the cles when cornering is limited. Your vehicle vehicle in front on the edge of the carriage- may brake unexpectedly or late. way, because of its narrow width. The dis- tance to the vehicle in front will be too short.
  • Page 201 Driving systems Make sure that the activation conditions HOLD function are met. General notes Depress the brake pedal. The HOLD function can assist the driver in the Quickly depress the brake pedal further following situations: until ë appears in the multifunction dis- play.
  • Page 202 Driving systems you depress the brake pedal again with a the multifunction display. Immediately certain amount of pressure until ë dis- depress the brake firmly until the warning message in the multifunction display goes appears from the multifunction display. out. you activate DISTRONIC PLUS.
  • Page 203 Driving systems with the road. Select this mode when employ- WARNING ing a sporty driving style, e.g. on winding Make sure that no persons or animals are in country roads. the manoeuvring range. Otherwise, they Start the engine. could be injured. Press button ;.
  • Page 204 Driving systems Rear sensors Centre Approx. 120 cm Corners Approx. 80 cm Minimum distance Centre Approx. 20 cm Corners Approx. 15 cm If there is an obstacle within this range, the Example: sensors in the front bumper, relevant warning displays light up and a warn- left-hand side ing tone sounds.
  • Page 205 Driving systems Deactivating/activating PARKTRONIC segments showing operational readiness = light up. The gear lever position or the transmission position of the automatic transmission deter- mines which warning display is active when the engine is running. Manual transmission: Gear lever posi- Warning display tion Forwards gear...
  • Page 206 Driving systems Problems with PARKTRONIC Problem Possible causes/consequences and M Solutions Only the red segments PARKTRONIC has malfunctioned and has switched off. in the PARKTRONIC If problems persist, have PARKTRONIC checked at a qualified warning displays are lit. specialist workshop. You also hear a warning tone for approximately two seconds.
  • Page 207 Driving systems make sure that the tyre pressures are WARNING always correct. This has a direct effect on Make sure that no persons or animals are in the steering instructions. the manoeuvring range. Otherwise, they the way your vehicle is positioned in the could be injured.
  • Page 208 Driving systems Parking Guidance will only detect parking Vehicles with automatic transmission: shift spaces: into position R. The multifunction display shows the that are parallel to the direction of travel Check vehicle surroundings Con‐ that are at least 1.5 m wide firm with OK message.
  • Page 209 Driving systems Countersteering: while the vehicle is sta- Reversing camera tionary, turn the steering wheel in the Important safety notes specified direction until the arrow is white and a warning tone sounds. WARNING To reverse into the parking space: main- Make sure that no persons or animals are in tain the steering wheel angle and reverse the manoeuvring range.
  • Page 210 Mercedes-Benz recommends that you use The lines are only guides, not accurate meas- a Mercedes-Benz Service Centre for this urements of the distance to an obstacle. purpose. Therefore, you should never pass the red line Do not use the reversing camera in these when approaching an obstacle.
  • Page 211 Driving systems If ATTENTION ASSIST detects typical indica- tors of fatigue or increasing lapses in con- centration on the part of the driver, it sug- gests taking a break. ATTENTION ASSIST assesses your level of fatigue or lapses in concentration by taking the following criteria into account: your personal driving style, e.g.
  • Page 212 Driving systems Activate ATTENTION ASSIST using the on- the traffic signs are poorly illuminated. board computer ( page 241). there are ambiguous traffic signs, for Symbol : appears in the multifunction instance near roadworks or on multi-lane display. roads. If necessary, take a break. Traffic signs always have priority over the Press the a button to confirm the mes- Speed Limit Assist display.
  • Page 213 Driving systems Information in the multifunction display the road type changes (e.g. motorway, country road). you have travelled a certain minimum distance without the traffic sign being repeated or detected again. Lane Tracking package General notes The Lane Tracking package consists of Blind Spot Assist ( page 210) and Lane Keeping Example: vehicles with automatic transmission...
  • Page 214 Driving systems For Blind Spot Assist to assist you when driv- If the lanes are narrow, vehicles driving in the ing, the radar sensor system must be activa- lane beyond the lane next to your vehicle may ted ( page 245) and operational. be indicated, especially if the vehicles are not driving in the middle of their lane.
  • Page 215 Driving systems page 241) are activated in the on-board computer. Turn the key to position 2 in the ignition lock. Warning lamps : in the exterior mirrors light up red for approximately 1.5 seconds and then turn yellow. Towing a trailer If you attach a trailer, make sure that you have correctly established the electrical connec- Yellow indicator lamp/red warning lamp...
  • Page 216 Driving systems If you have selected as the display unit in the windscreen is dirty, misted up or cov- Display unit Speed-/odome‐ ered, for instance by a sticker, in the vicinity ter( page 242) function in the on-board of the camera computer, Lane Keeping Assist assists you at several or no lane markings for a single lane speeds above 60 km/h.
  • Page 217 Driving systems you have switched on the turn signals. In The system may be impaired or may not func- this case, the warnings are suppressed for tion if: a certain period of time. there is poor visibility, e.g. due to snow, a driving safety system intervenes, such as rain, fog or spray.
  • Page 218 Driving systems Monitoring range be the case if there are vehicles at the inner edge of your lane. WARNING Due to the nature of the system: Active Blind Spot Assist monitors certain warnings may be issued in error when driv- areas in the immediate vicinity of your vehicle.
  • Page 219 Driving systems If Active Blind Spot Assist is switched on, Ensure at all times that there is sufficient lat- indicator lamps : in the exterior mirrors light eral distance between you and other road up yellow up to a speed of 30 km/h. At users or obstacles.
  • Page 220 Driving systems Either no braking application, or a course- may detect the lane markings on the road correcting brake application adapted to the incorrectly or not at all. driving situation occurs, if: The system may be impaired or may not func- there are vehicles or obstacles, e.g.
  • Page 221 Driving systems General notes The warning vibration occurs later if: the road has narrow lanes. you cut the corner on a bend. Lane-correcting brake application WARNING Active Lane Keeping Assist does not keep your vehicle in its lane. It is only an aid designed to assist driving.
  • Page 222 Driving systems If a lane-correcting brake application occurs, Active Lane Keeping Assist does not detect the display shown in the illustration appears road and traffic conditions. An inappropriate in the multifunction display. brake application may be interrupted at any time if: If you leave your lane under certain circum- stances, the vehicle will brake briefly on one you steer slightly in the opposite direction.
  • Page 223 Towing a trailer you have switched on the turn signals. In detach from the vehicle and fall on the road. this case, the warnings are suppressed There is a risk of an accident and injury. for a certain period of time. Always maintain the permissible noseweight a driving safety system intervenes, such when carrying loads.
  • Page 224 Observe the legally tion. prescribed maximum speed in the relevant country. For certain Mercedes-Benz vehicles, the max- Notes on towing a trailer imum permissible rear axle load is increased General notes when towing a trailer. Refer to the "Technical data"...
  • Page 225 Towing a trailer On long and steep downhill gradients, espe- WARNING cially if the vehicle is laden or towing a trailer, If you release the ball coupling or it does not you must select shift range 1, 2 or 3. engage correctly when folding in, it will swing out.
  • Page 226 Towing a trailer Uncoupling a trailer WARNING If you uncouple a trailer with an engaged over- run brake, you could trap your hand between the vehicle and the trailer drawbar. This poses a risk of injury. Do not uncouple a trailer with an engaged overrun brake.
  • Page 227 Towing a trailer Place the protective covering on the ball Press the ball coupling in the direction of coupling. the arrow until it engages behind the bumper. Indicator lamp = goes out and the mes- sage in the multifunction display disap- pears.
  • Page 228 Towing a trailer the current has fallen below the minimum of 50 mA. To ensure reliable operation of the bulb failure indicator, each LED chain in the trailer lighting must be guaranteed a minimum current of 50 mA. Trailer with 7-pin connector General notes Trailers with 7-pin connector: you can make a connection to the 13-pin connector...
  • Page 230 Useful information ......228 Important safety notes ....228 Displays and operation ....229 Menus and submenus ...... 233 Display messages ......249 Warning and indicator lamps in the instrument cluster ......275...

  • Page 231: Useful Information

    Important safety notes Useful information WARNING The operating safety of your vehicle could be This Owner's Manual describes all mod- impaired if maintenance work is carried out els, series and optional equipment for your incorrectly. This could cause you to lose con- vehicle that were available at the time of trol of your vehicle and cause an accident.
  • Page 232 Displays and operation Displays and operation Instrument cluster Instrument cluster: kilometres Fuel gauge Time Speedometer with segments ( page 231) Multifunction display ( page 232) Rev counter ( page 231) Coolant temperature ( page 230) Instrument cluster lighting ( page 230)
  • Page 233 Displays and operation Instrument cluster: miles Fuel gauge Time Speedometer with segments ( page 231) Multifunction display ( page 232) Rev counter ( page 231) Coolant temperature ( page 230) Instrument cluster lighting ( page 230) You can set the time using the audio system or COMAND Online; see the separate oper- ating instructions.

  • Page 234: Displays And Operation

    Displays and operation At high outside temperatures and when driv- The segments between the speed of the ing uphill, the coolant temperature may rise vehicle in front and the stored speed light to the end of the scale. Rev counter Operating the on-board computer ! Do not drive in the overrevving range.

  • Page 235: Transmission Position Display

    Displays and operation Left control panel Adjusts the volume Calls up the menu and menu bar Mute Press briefly: Back button Scrolls through lists Press briefly: Selects a submenu or function In the Audio menu: selects a Back stored station, an audio track or Switches off LINGUATRONIC;...
  • Page 236 Menus and submenus Menu bar ; disappears after a few seconds. menu (telephone) ( page 238) Assist. menu (assistance) ( page 239) Text field : shows the selected menu or submenu as well as display messages. Serv. menu ( page 241) The following messages can appear in the Settings menu (...
  • Page 237 Menus and submenus The values in the From start submenu are Press the = or ; button on the steer- calculated from the start of a journey, whilst ing wheel to select the Trip menu. the values in the From reset submenu are Press the 9 or : button to select the calculated from the last time the submenu...

  • Page 238: Menus And Submenus

    Menus and submenus Activated route guidance Press the a button. Press the : button to select No change of direction announced press the a button to confirm. You can reset the values of the following func- tions: trip meter trip computer "From start" trip computer "From reset"...
  • Page 239 Menus and submenus Change of direction announced with a Audio menu lane recommendation Selecting a radio station Road to which the change of direction leads Waveband Distance to change of direction and visual Station frequency with memory position distance display Station ;...
  • Page 240 Menus and submenus Audio player or audio media operation TV operation Channel frequency with memory position Example: CD/DVD changer display Current track The memory position is only displayed along with station : if this has been Audio data from various audio devices or media can be played, depending on the equip- stored.
  • Page 241 Observe the legal requirements of the country on the Internet at: http:// in which you are currently driving regarding www.mercedes-benz.com/connect the use of mobile phones in the vehicle. If it is permitted to use mobile phones while Accepting a call...
  • Page 242 Menus and submenus Press the 9 or : button to select the Assistance menu desired name. Introduction To begin rapid scrolling: press and hold the 9 or : button for longer than one second. Rapid scrolling stops when you release the button or reach the end of the list.
  • Page 243 Menus and submenus Press the a button. ® For further information about ESP , see The multifunction display shows Speed page 67). Limit Assist. Start the engine. Press the : button. Press the = or ; button on the steer- The current selection is displayed.
  • Page 244 Menus and submenus long as the HOLD function is not activated If the Blind Spot Assist Sensors deac‐ page 198). tivated Active blind spot assist. sensor system deactivated message Vehicles with Parking Guidance: if PARK- appears, the radar sensor system is deacti- TRONIC is activated and you are driving at a vated.
  • Page 245 Menus and submenus call up display messages in the message Press a to confirm. memory ( page 249) Press the : or 9 button to select the restart the tyre pressure loss warning sys- Display unit Speed-/odometer: func- tem ( page 345) tion.
  • Page 246 Menus and submenus Switching the Intelligent Light System Vehicles for the United Kingdom: this on/off function is not available. Press the = or ; button on the steer- Selecting the permanent display function ing wheel to select the Settings menu. You can determine whether the multifunction Press the : or 9 button to select the display permanently shows your speed or the...
  • Page 247 Menus and submenus Press the : or 9 button to select the Press a to confirm. Dipped beams Setting for: function. Press the : or 9 button to select the You will see the selected setting: Right- Surround lighting function. side traffic Left-side traffic.
  • Page 248 Menus and submenus Activating/deactivating the interior light- Switching the automatic locking feature ing delayed switch-off on/off Press the = or ; button on the steer- If you activate the Lighting delayed sw.- function, the interior lighting remains on ing wheel to select the Settings menu.

  • Page 249: Auxiliary Heating

    Menus and submenus ! Operating the auxiliary heating/ventila- Press the 9 or : button to select tion draws on the vehicle battery. After you Radar sensor (See Owner's Man.):. have heated or ventilated the vehicle a You will see the selected setting: maximum of two times, drive for a longer off.
  • Page 250 Menus and submenus Changing the departure time Press the : or 9 button to select the Easy Entry/Exit: function. Press the = or ; button on the steer- If the Easy Entry/Exit function is activa- ing wheel to select the Settings menu.
  • Page 251 Menus and submenus To fold the exterior mirrors in or out If you have switched the Auto. fold in function on and you fold the exterior mirrors in using button :, they will not fold out auto- matically ( page 118). You can then only fold out the exterior mirrors using button :.

  • Page 252: Display Message

    Display messages Display messages Introduction General notes Display messages appear in the multifunction display. Display messages with graphic symbols are simplified in the Owner's Manual and may differ from the symbols in the multifunction display. Please respond in accordance with the display messages and follow the additional notes in this Owner's Manual.
  • Page 253 Display messages Safety systems Display messages Possible causes/consequences and M Solutions !÷ ® ABS (Anti-lock Braking System), ESP (Electronic Stability Pro- ® gram), BAS (Brake Assist), PRE-SAFE , the HOLD function, hill currently unavail‐ ® start assist and ESP trailer stabilisation are temporarily unavail- able See Owner's able.
  • Page 254 Display messages Display messages Possible causes/consequences and M Solutions The steerability and braking characteristics may be severely affec- ted. The braking distance in an emergency braking situation can increase. ® ® If ESP is not operational, ESP is unable to stabilise the vehicle. The danger of skidding and having an accident increases.
  • Page 255 Display messages Display messages Possible causes/consequences and M Solutions ® EBD (electronic brake force distribution), ABS, ESP , BAS, PRE- ® ® SAFE , the HOLD function, hill start assist and ESP trailer stabi- ÷ lisation are unavailable due to a malfunction. ®...
  • Page 256 Display messages Display messages Possible causes/consequences and M Solutions There is insufficient brake fluid in the brake fluid reservoir. In addition, the red J warning lamp lights up in the instrument Check brake fluid cluster and a warning tone sounds. level WARNING The braking efficiency may be impaired.
  • Page 257 Display messages Display messages Possible causes/consequences and M Solutions PRE-SAFE ® PRE-SAFE Brake is inoperative due to a fault. BAS PLUS or the distance warning signal may also have failed. Functions cur‐ rently limited See Visit a qualified specialist workshop. Owner's Manual Risk of injury Cabriolet: the roll bars are defective.
  • Page 258 Display messages Display messages Possible causes/consequences and M Solutions SRS has malfunctioned at the front on the left or right. The 6 warning lamp also lights up in the instrument cluster. Front left malfunc‐ WARNING tion Consult work‐ shoporFront right The airbags or belt tensioners may either be triggered uninten- malfunction Con‐...
  • Page 259 Display messages Display messages Possible causes/consequences and M Solutions The left or right-hand cornering light is faulty. Check whether you are permitted to replace the bulb yourself Left cornering page 133). light Right cor‐ nering light Visit a qualified specialist workshop. The left or right-hand dipped-beam headlamp is faulty.
  • Page 260 Display messages Display messages Possible causes/consequences and M Solutions The turn signal in the left-hand or right-hand exterior mirror is faulty. Left mirror indica‐ Check whether you are permitted to replace the bulb yourself Right mir‐ page 133). ror indicator Visit a qualified specialist workshop.
  • Page 261 Display messages Display messages Possible causes/consequences and M Solutions The rear foglamp is faulty. Check whether you are permitted to change the bulb yourself Rear fog lamp page 133). Visit a qualified specialist workshop. The front left or front right parking lamp is faulty. Check whether you are permitted to change the bulb yourself Front left parking page 133).
  • Page 262 Display messages Display messages Possible causes/consequences and M Solutions The lights are still switched on when you leave the vehicle. A warning tone also sounds. Switch off lights Turn the light switch to Ã. Adaptive Highbeam Assist is faulty. Adaptive Main-beam Assist inoperative Visit a qualified specialist workshop.
  • Page 263 Display messages Display messages Possible causes/consequences and M Solutions The coolant is too hot. A warning tone also sounds. Coolant Stop vehi‐ WARNING cle Switch engine Never drive with an overheated engine. Driving when your engine is overheated can cause some fluids which may have leaked into the engine compartment to catch fire.
  • Page 264 Display messages Display messages Possible causes/consequences and M Solutions The battery is not being charged. A warning tone also sounds. Possible causes: faulty alternator torn poly-V-belt a malfunction in the electronics Stop the vehicle immediately, paying attention to road and traf- fic conditions, and switch off the engine.
  • Page 265 Display messages Display messages Possible causes/consequences and M Solutions ¸ Vehicles with a diesel engine: the engine air filter is dirty and must be replaced. Please replace air Visit a qualified specialist workshop. cleaner Vehicles with a diesel engine: there is water in the fuel filter. The water must be drained off.
  • Page 266 Display messages Display messages Possible causes/consequences and M Solutions ë The HOLD function is deactivated. The vehicle is skidding. A warning tone also sounds. Reactivate the HOLD function later ( page 198). The HOLD function is deactivated. When the brake pedal is firmly depressed, an activation condition is not fulfilled.
  • Page 267 Display messages Display messages Possible causes/consequences and M Solutions Lane Keeping Lane Keeping Assist or Active Lane Keeping Assist is deactivated and temporarily inoperative. Possible causes: Assist currently unavailable See the windscreen is dirty in the camera's field of vision. Owner's Manual visibility is impaired due to heavy rain, snow or fog.
  • Page 268 Display messages Display messages Possible causes/consequences and M Solutions Blind Spot Assist or Active Blind Spot Assist is temporarily inop- erative. Possible causes: the sensors are dirty. the function is impaired due to heavy rain or snow. the radar sensor system is outside the operating temperature range.
  • Page 269 Display messages Display messages Possible causes/consequences and M Solutions Parking Guidance Parking Guidance is deactivated. Possible causes: cancelled The vehicle is skidding. the sensors are dirty. a malfunction has occurred. A warning tone also sounds. Reactivate Parking Guidance later ( page 203).
  • Page 270 Display messages Display messages Possible causes/consequences and M Solutions DISTRONIC PLUS cur‐ DISTRONIC PLUS is temporarily inoperative. Possible causes: rently unavailable the function is impaired due to heavy rain or snow. See Owner's Manual the sensors in the radiator trim and in the bumpers are dirty. the radar sensor system is temporarily inoperative, e.g.
  • Page 271 Display messages Display messages Possible causes/consequences and M Solutions Limit While depressing the accelerator pedal beyond the pressure point (kickdown), SPEEDTRONIC cannot be activated. --- km/h Cruise control A condition for activating cruise control has not been met. --- km/h You have tried to store a speed below 30 km/h, for example.
  • Page 272 Display messages Tyres Display messages Possible causes/consequences and M Solutions The tyre pressure loss warning system has detected a significant Tyre pressure loss in pressure. Check tyres A warning tone also sounds. WARNING With tyre pressures which are too low, there is a risk of the fol- lowing hazards: the tyres may burst, especially as the load and vehicle speed increase.
  • Page 273 Display messages Vehicle Display messages Possible causes/consequences and M Solutions You have attempted to start the engine with the transmission in To start engine, position R or D. shift to either P or N Shift the transmission to position P or N. You have switched off the engine with the Start/Stop button and opened the driver's door.
  • Page 274 Display messages Display messages Possible causes/consequences and M Solutions The bonnet is open. A warning tone also sounds. CLS Shooting Brake: the bonnet is open. A warning tone also sounds. WARNING The open bonnet may then block your view when the vehicle is in motion.
  • Page 275 Display messages Display messages Possible causes/consequences and M Solutions The trailer tow hitch is not correctly engaged. A warning tone also sounds. Check trailer Stop the vehicle immediately, paying attention to road and traf- hitch lock fic conditions, and switch off the engine. Apply the parking brake.
  • Page 276 Display messages Display messages Possible causes/consequences and M Solutions Telephone No Your vehicle is outside the network provider's transmitter/ receiver range. service Wait until the mobile phone operational readiness symbol appears in the multifunction display. If you drive at speeds of more than 40 km/h, you cannot open or close the soft top.
  • Page 277 Display messages Display messages Possible causes/consequences and M Solutions  You have put the wrong key in the ignition lock. Use the correct key. Key does not belong to vehicle  The key needs to be replaced. Visit a qualified specialist workshop. Replace key Â...

  • Page 278: Warning And Indicator Lamps In The Instrument Cluster

    Warning and indicator lamps in the instrument cluster Display messages Possible causes/consequences and M Solutions  The KEYLESS-GO key is not continually detected. KEYLESS-GO is temporarily malfunctioning or is defective. A warn- Remove starting ing tone also sounds. button, then Insert the key into the ignition lock and turn it to the desired insert key position.

  • Page 279: Problem (Display Message)

    Warning and indicator lamps in the instrument cluster Safety Seat belts Problem Possible causes/consequences and M Solutions ü The seat belt warning lamp reminds the driver and front passenger to fasten their seat belts. Only for certain coun- tries: the red seat belt Fasten your seat belt ( page 50).
  • Page 280 Warning and indicator lamps in the instrument cluster Safety systems Problem Possible causes/consequences and M Solutions There is insufficient brake fluid in the brake fluid reservoir. The red brake system WARNING warning lamp comes on The braking efficiency may be impaired. while the engine is run- There is a risk of an accident.

  • Page 281: Bas Plus (Brake Assist System Plus)

    Warning and indicator lamps in the instrument cluster Problem Possible causes/consequences and M Solutions EBD is not available due to a malfunction. Therefore, ABS, BAS, ® ® ® BAS PLUS, ESP , PRE-SAFE , PRE-SAFE Brake, the HOLD func- The yellow ABS warning ®...
  • Page 282 Warning and indicator lamps in the instrument cluster Problem Possible causes/consequences and M Solutions ä ® or traction control has intervened because there is a risk of skidding or at least one wheel has started to spin. ® The yellow ESP warn- ing lamp flashes while Cruise control or DISTRONIC PLUS is deactivated.
  • Page 283 Warning and indicator lamps in the instrument cluster Problem Possible causes/consequences and M Solutions You are driving with the parking brake applied. The red brake system Release the parking brake. warning lamp comes on The warning lamp goes out and the warning tone ceases. while the vehicle is moving.
  • Page 284 Warning and indicator lamps in the instrument cluster Problem Possible causes/consequences and M Solutions The fuel level has dropped into the reserve range. The yellow reserve fuel Operation of the auxiliary heating is deactivated if the fuel level warning lamp lights up drops into the reserve range.
  • Page 285 Warning and indicator lamps in the instrument cluster Problem Possible causes/consequences and M Solutions The coolant level is too low. The red coolant warn- If the coolant level is correct, the airflow to the engine radiator ing lamp comes on may be blocked or the electric engine radiator fan may be mal- while the engine is run- functioning.
  • Page 286 Warning and indicator lamps in the instrument cluster Problem Possible causes/consequences and M Solutions Leave the vehicle and keep a safe distance from the vehicle until the engine has cooled down. Check the coolant level and top up the coolant, observing the warning notes ( page 310).
  • Page 288 Useful information ......286 Stowage areas ........286 Features ..........291...
  • Page 289 Stowage areas or the permissible axle loads for the vehicle Useful information (including occupants). position heavy loads as far forwards as pos- This Owner's Manual describes all mod- sible and as low down in the boot as pos- els, series and optional equipment for your sible.
  • Page 290 Stowage areas Glove compartment Stowage compartment in the centre console To open: pull handle : and open glove Illustration example: Coupé compartment flap ;. To open: slide roller : back. To close: fold glove compartment flap ; upwards until it engages. Stowage compartment/telephone The glove compartment can be ventilated compartment under the armrest...
  • Page 291 Stowage areas up the preinstalled mobile phone holder Otherwise, you and other vehicle occupants (see the separate Audio or COMAND Online could be injured by objects being thrown Operating Instructions). around the vehicle in the event of sharp brak- ing, a sudden change in direction or an acci- dent.
  • Page 292 Stowage areas Move the driver's or front-passenger seat forward if necessary. Fold rear seat backrest : back until it engages. Move the driver's or front-passenger seat back if necessary. You should always engage the rear seat backrests if you do not need the through- loading feature.
  • Page 293 Stowage areas Boot Stowage well under the boot floor ! Remove the handle again before closing the boot lid and snap it in tightly to prevent the handle flap from protruding. Otherwise, you could damage the handle. Example: Coupé There are four lashing eyelets in the boot on the Coupé...
  • Page 294 Vehicles with a steel roof ! Mercedes-Benz recommends that you only use roof carriers that have been tested and approved for Mercedes-Benz vehicles. This helps to prevent damage to the vehi- cle.
  • Page 295 Features Pry groove ; away carefully on the front- brake sharply passenger side using a suitable tool until change direction suddenly lug = becomes visible. are involved in an accident Pull the cup holder upwards slightly, to the Only use the cup holders for containers of a stop.
  • Page 296 Features Cup holder in the rear stowage box Example: Coupé Mirror light Coupé (double cup holder, side by side) Bracket To open (Coupé): slide cover : forwards. Retaining clip, e.g. for a car park ticket Vanity mirror Mirror cover Vanity mirror in the sun visor Mirror light : only functions if the sun visor is clipped into retainer ;...
  • Page 297 Features To refit the insert: press insert = into the holder until it engages. To close: briefly press cover : at the front. The cover moves back. You can remove the ashtray insert and use the resulting compartment for stow- age.
  • Page 298 Features Socket in the front centre console Turn the key to position 2 in the ignition lock ( page 159). To open: slide cover : forwards until it To open: slide cover : forwards until it engages. engages. Lift up the cover of socket ;. Press in cigarette lighter ;.
  • Page 299 Place the mobile phone bracket into the electromagnetic fields. pre-installed fitting (see the separate Mercedes-Benz recommends the use of an installation instructions for the mobile approved exterior aerial. This ensures: phone fitting).
  • Page 300 Features tions. However, the charging function and You can fold the pre-installed bracket up to aerial function are not available. improve access to the stowage space beneath it. Depending on the vehicle's equip- ment, a USB connection and an AUX-IN con- Operating the mobile phone nection/Media Interface are fitted in the You can operate the telephone using the...
  • Page 301 Features Press and hold button B on remote control A until indicator lamp : lights up green. If indicator lamp : lights up green or flashes, then programming has been suc- cessful. Release button B of garage door drive remote control A. If indicator lamp : lights up red: repeat the programming procedure for the corre- sponding button on the rear-view mirror.
  • Page 302 Features Problems when programming Turn the key to position 2 in the ignition lock. If you have problems when programming the integrated garage door opener, please note Press button ;, = or ? which you have the following: programmed to operate the garage door. Garage door system with a fixed code: indi- Check the transmitter frequency of garage cator lamp : lights up green.
  • Page 303 Features Country Radio type approval num- Country Radio type approval num- Frequency range (MHz) Frequency range (MHz) BG (Bulga- Article 6 of Directive FI (Finland) Article 6 of Directive ria) 1999/5/EC R&TTE 12 April 1999/5/EC R&TTE10668 13 May 05 MHz: 27, 40, 433, 868 MHz: 27, 40, 433, 868 CH (Switzer- Article 6 of Directive...
  • Page 304 Features Country Radio type approval num- Country Radio type approval num- Frequency range (MHz) Frequency range (MHz) IS (Iceland) Article 6 of Directive MC (Mon- Article 6 of Directive 1999/5/EC R&TTE 18 May aco) 1999/5/EC R&TTE10668 13 May 05 MHz: 27, 40, 433, 868 MHz: 27, 40, 433, 868 IT (Italy) DGPGSR/II/347487/...
  • Page 305 Features Country Radio type approval num- Country Radio type approval num- Frequency range (MHz) Frequency range (MHz) SI (Slovenia) Article 6 of Directive GF (French Article 6 of Directive 1999/5/EC R&TTE Guyana) 1999/5/EC R&TTE10668 500-1/2005-437 9 May 05 13 May 05 MHz: 27, 40, 433, 868 MHz: 27, 30, 40, 433, 868 SK (Slova-...
  • Page 306 Features Australia Retrofitted anti-glare film Country Radio type approval num- Retrofitted anti-glare film on the inside of the windows can interfere with radio/mobile telephone reception. This is particularly the Frequency range (MHz) case for conductive or metallic-coated films. AU (Aus- 28 June You can obtain information about anti-glare tralia)
  • Page 308 Useful information ......306 Engine compartment ......306 Service ..........311 Care ............ 312...

  • Page 309: Useful Information

    Engine compartment Useful information This Owner's Manual describes all mod- els, series and optional equipment for your vehicle that were available at the time of going to press. National variations are pos- sible. Note that your vehicle may not be equipped with all of the functions descri- bed.

  • Page 310: Engine Compartment

    Engine compartment WARNING There is a risk of injury if the bonnet is open, even if the engine is not running. Some engine components can become very hot. To avoid the risk of burns, only touch those components described in the Owner's Manual and observe the relevant safety notes.
  • Page 311 Engine compartment Lower the bonnet and let it fall from a that no ignition position has been selected height of approximately 20 cm. with KEYLESS-GO. All indicator lamps must be Check that the bonnet has engaged prop- off in the instrument panel. erly.
  • Page 312 375). service system. You can obtain a list of the engine oils and oil filters tested and approved in accordance with the Mercedes-Benz Specifications for Service Products at any Mercedes-Benz Service Centre.
  • Page 313 Engine compartment neck when warm, there is enough coolant Other service products in coolant expansion tank ;. Checking the coolant level If necessary, top up with coolant that has been tested and approved by Mercedes- WARNING Benz. The cooling system is pressurised. Therefore, Replace cap : and turn it clockwise as far only unscrew the cap once the engine has as it will go.

  • Page 314: Service

    If you notify a qualified specialist workshop of A qualified specialist workshop, e.g. a this display, you will receive a statement on Mercedes-Benz Service Centre, will reset the the associated costs. ASSYST PLUS service interval display after The ASSYST PLUS service interval display the service work has been carried out.
  • Page 315 Care tion can be obtained at a qualified specialist Use care products and cleaning agents rec- workshop, e.g. a Mercedes-Benz Service ommended and approved by Mercedes-Benz. Centre. Driving abroad Washing the vehicle and cleaning the An extensive Mercedes-Benz Service network paintwork is also available in other countries.

  • Page 316: Care

    Use a soft sponge to clean. ventilation slots Use a mild cleaning agent, such as a car Damaged seals or electrical components shampoo approved by Mercedes-Benz. can lead to leaks or failures. Thoroughly hose down the vehicle with a gentle jet of water.
  • Page 317 Have treatment. the soft-top seams sealed at a qualified spe- These notes also apply to light-alloy wheels cialist workshop, e.g. at a Mercedes-Benz with a clear matt finish. Service Centre. The vehicle should preferably be washed...
  • Page 318 Care Cleaning AIRCAP Mercedes-Benz and rinse it with clean water. Cleaning the wind deflector Cleaning the AIRCAP draught stop ! Do not use high-pressure cleaning equip- ment to clean the net. Clean the AIRCAP draught stop with the soft top open.
  • Page 319 Deposits such as leaves, petals lighting using a wet sponge and a mild and pollen may under certain circumstan- cleaning agent, e.g. Mercedes-Benz car ces prevent water from draining away. This shampoo or cleaning cloths. can lead to corrosion damage and damage to electronic components.
  • Page 320 Care Mercedes-Benz car shampoo or cleaning Use clear water and a soft cloth to clean cloths. camera lens :. Cleaning the sensors Cleaning the exhaust tail pipes ! If you clean the sensors with a high-pres- ! Do not clean the exhaust pipe with alka-...
  • Page 321 This could lead to irrepara- leather care agents that have been recom- ble damage to the display. mended and approved by Mercedes-Benz. Before cleaning the display, make sure that it is switched off and has cooled down. Cleaning wooden trim and trim ele-...
  • Page 322 Only use leather care agents that have been tested and approved by Mercedes-Benz. You can obtain these from a qualified specialist workshop. clean artificial leather covers with a cloth moistened with a solution containing 1 % detergent (e.g.
  • Page 324 Useful information ......322 Where will I find...? ......322 Flat tyre ..........324 Battery (vehicle) ........ 328 Jump-starting ........331 Towing and tow-starting ....333 Electrical fuses ......... 336...

  • Page 325: Useful Information

    Where will I find...? Setting up the warning triangle Useful information This Owner's Manual describes all mod- els, series and optional equipment for your vehicle that were available at the time of going to press. National variations are pos- sible. Note that your vehicle may not be equipped with all of the functions descri- bed.

  • Page 326: Where Will I Find

    Where will I find...? Vehicles with a TIREFIT kit Fire extinguisher The fire extinguisher is located underneath the front of the driver's seat. Centring pin Jack One pair of gloves Pull tab : upwards. Cabriolet: straps for emergency release Remove fire extinguisher ;. of the soft top Have fire extinguisher ;...
  • Page 327 Flat tyre The vehicle tool kit contains: Vehicles with KEYLESS-GO: remove the Start/Stop button from the ignition lock Cabriolet: straps for emergency release of page 159). the soft top All occupants must get out of the vehicle. Foldable wheel chock Make sure that they are not endangered as Fuse allocation chart they do so.

  • Page 328: Flat Tyre

    Flat tyre your vehicle even if there is a total loss of WARNING pressure in one or more tyres. In the following situations, the tyre sealant is MOExtended tyres may only be used in con- unable to provide sufficient breakdown assis- junction with an active tyre pressure loss tance, as it is unable to seal the tyre properly: warning system or with an active tyre pres-...
  • Page 329 Flat tyre TIREFIT sticker, 2-part Remove the cap from valve C on the faulty Do not remove any foreign objects which tyre. have penetrated the tyre, e.g. screws or Screw filler hose D onto valve C. nails. Insert connector ? into a 12 V socket Remove the tyre sealant bottle, the accom- page 295) in your vehicle.
  • Page 330 Flat tyre Tyre pressure not reached If a tyre pressure of 180 kPa (1.8 bar/26 psi) has been attained after five minutes: If a pressure of 180 kPa (1.8 bar/26 psi) has Switch off the tyre inflation compressor. not been achieved after five minutes: Unscrew the filler hose from the valve of Switch off the tyre inflation compressor.

  • Page 331: Battery (Key)

    Avoid creating sparks. shop. Battery acid is caustic. In your vehicle, you will find a sticker with Avoid contact with the skin, the Mercedes-Benz Service24h telephone eyes or clothing. number, e.g. on the B-pillar on the driver's Wear suitable protective side.

  • Page 332: Battery (Vehicle)

    Battery (vehicle) Observe the service intervals in the Service WARNING Booklet or contact a qualified specialist For safety reasons, Mercedes-Benz recom- workshop for more information. mends that you only use batteries which have been tested and approved for your vehicle by ! You should have all work involving the Mercedes-Benz.

  • Page 333: Charging

    Do not lean over the battery during the charging process. WARNING Battery acid is caustic. Avoid contact with the skin, eyes or clothing. ! Only charge the installed battery with a battery charger which has been tested and approved by Mercedes-Benz. These battery...

  • Page 334: Jump Starting

    Jump-starting Jump-starting WARNING There is a risk of acid burns when jump-starting a vehicle due to the gases which escape from the battery. Do not lean over the battery while the engine is being jump-started. WARNING Gases escaping from the battery during jump-starting may cause minor explosions. Avoid cre- ating sparks.
  • Page 335 Jump-starting Position number B identifies the charged battery of the other vehicle or an equivalent jump- starting device. Slide cover : of positive terminal ; in the direction of the arrow. Connect positive terminal ; on your vehicle to positive terminal = of donor battery B using the jump lead.

  • Page 336: Function

    Towing and tow-starting distance so that the tow rope does not Towing and tow-starting sag. Important safety notes do not use steel cables or chains to tow your vehicle. The vehicle could be dam- WARNING aged. If you tow the vehicle, you must use a rigid ! Do not use the towing eye for recovery, towing bar if: this could damage the vehicle.
  • Page 337 Towing and tow-starting The battery must be connected and charged. Vehicles with a trailer tow hitch: if you intend Otherwise, you: to use the vehicle for towing, fold out the ball coupling and connect the towbar to it cannot turn the key in the ignition lock to page 222).
  • Page 338 Towing and tow-starting Vehicles with manual transmission: Towing the vehicle with both axles on shift to neutral. the ground Vehicles with automatic transmission: WARNING turn the key to position 2 in the ignition The power assistance for the steering and the lock.
  • Page 339 Only use fuses that have been approved for left-hand side of the vehicle, when viewed Mercedes-Benz vehicles and which have the in the direction of travel correct fuse rating for the systems con- fuse box in the boot on the right-hand side cerned.

  • Page 340: Electrical Fuses

    Electrical fuses ! When closing the cover, make sure that it is lying correctly on the fuse box. Moisture seeping in or dirt could otherwise impair the operation of the fuses. Remove any existing moisture from the fuse box using a dry cloth. To open: take lines ;...
  • Page 341 Electrical fuses Coupé To open: turn rotary catch : of cover ; clockwise. Open cover ; downwards. Cabriolet To open: raise boot floor :( page 290). Using tabs = push back floor covering with slits ; and lift it up.
  • Page 342 Useful information ......340 Important safety notes ....340 Operation ........... 340 Winter operation ....... 342 Tyre pressure ........343 Changing a wheel ......346 Wheel and tyre combinations ..350 Emergency spare wheel ....363...

  • Page 343: Useful Information

    Accessories that are not approved for your damage. Hidden tyre damage could also be vehicle by Mercedes-Benz or are not being causing the unusual handling characteristics. used correctly can impair the operating If you find no signs of damage, have the tyres safety.
  • Page 344 Only fit tyres of the correct size onto the ard valve cap or other valve caps approved by wheels. Mercedes-Benz for your vehicle. Do not fit any Run in new tyres at moderate speeds for other valve caps or systems, e.g. tyre pres- the first 100 km.

  • Page 345: Winter Operation

    ( page 345). cold temperatures could cause tears to form, For more information on driving with an emer- thereby damaging the tyres permanently. gency spare wheel, see ( page 363). Mercedes-Benz cannot accept responsibility for this type of damage.

  • Page 346: Tyre Pressure

    Mercedes-Benz, or that are of a corre- if the load changes sponding standard of quality. before beginning a long journey If you intend to fit snow chains, please bear for changed operating conditions, e.g.
  • Page 347 Tyre pressure does not permit any reliable conclusion about Check the tyre for foreign objects. the tyre pressure. Check whether the wheel is losing air or the If possible, only correct tyre pressures when valve is leaking. the tyres are cold. If you are unable to rectify the damage, con- The tyres are cold: tact a qualified specialist workshop.
  • Page 348 Tyre pressure message will appear in the multifunction dis- give reliable warnings if you have set the play. correct tyre pressure. If an incorrect tyre pressure is set, these incorrect values will The tyre pressure warning system does not be monitored. warn you of an incorrectly set tyre pressure.
  • Page 349 Changing a wheel if necessary, restart the tyre pressure loss Changing a wheel warning system. Flat tyre You can find information on what to do in the Direction of rotation event of a flat tyre in the "Breakdown assis- tance" section ( page 324).

  • Page 350: Changing A Wheel

    Changing a wheel Vehicles without KEYLESS-GO: remove The folding wheel chock is an additional the key from the ignition lock. securing measure to prevent the vehicle from rolling away, for example when changing a Vehicles with KEYLESS-GO: open the wheel. driver's door.
  • Page 351 Mercedes-Benz. If the jack is used incorrectly, it could tip over while the vehicle is raised. Using wheel wrench :, loosen the bolts on...
  • Page 352 Changing a wheel Removing a wheel ! Do not place wheel bolts in sand or dirt. The threads of the wheel bolts and wheel hubs could otherwise be damaged when the bolts are tightened. Vehicles with AMG equipment: fold cover ; upwards. Unscrew the uppermost wheel bolt com- pletely.
  • Page 353 Only use wheel bolts that have been designed for the wheel and the vehicle. For safety rea- sons, Mercedes-Benz recommends that you only use wheel bolts which have been approved for Mercedes-Benz vehicles and the respective wheel. Tightening wheel bolts (example: vehicle with emergency spare wheel)

  • Page 354: Wheel And Tyre Combinations

    MOE = Mercedes-Benz Original Extended RA: rear axle (tyres featuring run-flat characteristics) You will find a table with recommended tyre MO1 = Mercedes-Benz Original (only cer- pressures for various operating conditions on tain AMG tyres) the inside of your vehicle's fuel filler flap. For...
  • Page 355 Wheel and tyre combinations Tyres E 200 BlueEFFICIENCY Summer tyres R 16 Tyres Light-alloy wheels BA: 7.0 J x 16 H2 ET 38 3, 4 BA:205/55 R16 91 V R 17 Tyres Light-alloy wheels BA: 7.5 J x 17 H2 ET 45 BA:235/45 R17 94 W 5, 6 BA: 7.5 J x 17 H2 ET 45...
  • Page 356 Wheel and tyre combinations R 19 Tyres Light-alloy wheels FA: 8.5 J x 19 H2 ET 44 8, 9, 10 FA: 235/35 ZR19 XL RA: 8.5 J x 19 H2 ET 44 7, 8, 9, 10 RA: 255/30 ZR19 XL FA: 8.0 J x 19 H2 ET 44 8, 9, 10 FA: 235/35 ZR19 91Y XL...
  • Page 357 Wheel and tyre combinations R 17 Tyres Light-alloy wheels BA: 7.5 J x 17 H2 ET 45 BA: 235/45 R17 94 W 5, 6 BA: 7.5 J x 17 H2 ET 45 BA: 235/45 R17 94 W MOExtended FA: 235/45 R17 94 W FA: 7.5 J x 17 H2 ET 45 RA: 8.5 J x 17 H2 ET 49 RA: 255/40 R17 94 W...
  • Page 358 Wheel and tyre combinations R 17 Tyres Light-alloy wheels BA: 235/45 R17 94 H M+Si BA: 7.5 J x 17 H2 ET 45 BA: 7.5 J x 17 H2 ET 45 BA: 235/45 R17 94 H M+SiMOExtended R 18 Tyres Light-alloy wheels BA: 235/40 R18 95 H X M+Si BA: 8.0 J x 18 H2 ET 45...
  • Page 359 Wheel and tyre combinations R 19 Tyres Light-alloy wheels FA: 8.5 J x 19 H2 ET 44 8, 9, 10 FA: 235/35 ZR19 XL RA: 8.5 J x 19 H2 ET 44 7, 8, 9, 10 RA: 255/30 ZR19 XL FA: 8.0 J x 19 H2 ET 44 8, 9, 10 FA: 235/35 ZR19 91Y XL...
  • Page 360 Wheel and tyre combinations R 18 Tyres Light-alloy wheels FA: 8.0 J x 18 H2 ET 45 FA: 235/40 R18 91 Y RA: 8.5 J x 18 H2 ET 49 7, 8 RA: 255/35 R18 94 Y XL R 19 Tyres Light-alloy wheels FA: 8.5 J x 19 H2 ET 44...
  • Page 361 Wheel and tyre combinations R 19 Tyres Light-alloy wheels FA: 8.5 J x 19 H2 ET 44 8, 9, 10 FA: 235/35 ZR19 XL RA: 8.5 J x 19 H2 ET 44 7, 8, 9, 10 RA: 255/30 ZR19 XL FA: 8.0 J x 19 H2 ET 44 8, 9, 10 FA: 235/35 ZR19 91Y XL...
  • Page 362 Wheel and tyre combinations R 18 Tyres Light-alloy wheels FA: 8.0 J x 18 H2 ET 45 FA: 235/40 R18 91 Y RA: 8.5 J x 18 H2 ET 49 7, 8 RA: 255/35 R18 94 Y XL R 19 Tyres Light-alloy wheels FA: 8.5 J x 19 H2 ET 44...
  • Page 363 Wheel and tyre combinations E 250 CDI BlueEFFICIENCY Summer tyres R 16 Tyres Light-alloy wheels BA: 7.0 J x 16 H2 ET 38 3, 4 BA: 205/55 R16 91 W R 17 Tyres Light-alloy wheels BA: 7.5 J x 17 H2 ET 45 BA: 235/45 R17 94 W BA: 7.5 J x 17 H2 ET 45 5, 6...
  • Page 364 Wheel and tyre combinations R 19 Tyres Light-alloy wheels FA: 8.5 J x 19 H2 ET 44 8, 9, 10 FA: 235/35 ZR19 XL RA: 8.5 J x 19 H2 ET 44 7, 8, 9, 10 RA: 255/30 ZR19 XL FA: 8.0 J x 19 H2 ET 44 8, 9, 10 FA: 235/35 ZR19 91Y XL...
  • Page 365 Wheel and tyre combinations Tyres Light-alloy wheels FA: 235/45 R17 94 W FA: 7.5 J x 17 H2 ET 45 RA: 8.5 J x 17 H2 ET 49 RA: 255/40 R17 94 W FA: 7.5 J x 17 H2 ET 45 FA: 235/45 R17 94 W MOExtended RA: 8.5 J x 17 H2 ET 49 6, 7...

  • Page 366: Emergency Spare Wheel

    Emergency spare wheel Replace the tyres after six years at the latest, Emergency spare wheel regardless of wear. This also applies to the Important safety notes emergency spare wheel. WARNING When you are driving with the emergency spare wheel fitted, the tyre pressure loss The wheel/tyre dimensions and the tyre type warning system cannot function reliably.
  • Page 367 Emergency spare wheel Technical data E 200 BlueEFFICIENCY "Minispare" emergency spare wheel Tyres Light-alloy wheels T 135/90 R16 102 M 3.5 B x 16 H2 ET 20 Tyre pressure: 420 kPa (4.2 bar/61 psi) T 135/80 R17 103 M 3.5 B x 17 H2 ET 19.5 Tyre pressure: 420 kPa (4.2 bar/61 psi) T 125/70 R18 99 M 3.5 B x 18 H2 ET 20...
  • Page 368 Emergency spare wheel E 350 BlueEFFICIENCY "Minispare" emergency spare wheel Tyres Light-alloy wheels T 135/80 R17 103 M 3.5 B x 17 H2 ET 19.5 Tyre pressure: 420 kPa (4.2 bar/61 psi) T 125/70 R18 99 M 3.5 B x 18 H2 ET 20 Tyre pressure: 420 kPa (4.2 bar/61 psi) E 500 BlueEFFICIENCY "Minispare"...
  • Page 369 Emergency spare wheel E 350 CDI BlueEFFICIENCY "Minispare" emergency spare wheel Tyres Light-alloy wheels T 135/80 R17 103 M 3.5 B x 17 H2 ET 19.5 Tyre pressure: 420 kPa (4.2 bar/61 psi) T 125/70 R18 99 M 3.5 B x 18 H2 ET 20 Tyre pressure: 420 kPa (4.2 bar/61 psi)
  • Page 370 Useful information ......368 Information on technical data ..368 Genuine Mercedes-Benz parts ..368 Vehicle electronics ......369 Identification plates ......371 Service products and capacities ..371 Vehicle data ........378 Trailer tow hitch ........ 380 24 GHz radar sensor system (coun-...

  • Page 371: Useful Information

    Mercedes-Benz parts meet the approval For this reason, Mercedes-Benz recommends requirements. The use of non-approved parts that you use genuine Mercedes-Benz parts or may invalidate the vehicle's general operating parts of equal quality. Only use tyres, wheels permit.

  • Page 372: Vehicle Electronics

    (VIN) ( page 371) and the engine num- cialist workshop. ber ( page 371) when ordering genuine Mercedes-Benz parts. ! The operating permit may be invalidated if the instructions for installation and use of RF transmitters are not observed. Vehicle electronics...
  • Page 373 Deviations with respect to wavebands, maxi- out restrictions: mum transmission outputs or aerial positions RF transmitters with a maximum transmis- must be approved by Mercedes-Benz. sion output of up to 100 mW The maximum transmission output (PEAK) at mobile phones (GSM/DCS/PCS/UMTS/...

  • Page 374: Identification Plates

    Service products and capacities data applicable to your vehicle on the vehi- Identification plates cle's identification plate. Vehicle identification plate with vehi- cle identification number (VIN) Open the right-hand door. You will see vehicle identification plate :. Slide the right-hand front seat to its rear- most position.
  • Page 375 Mercedes-Benz recommends that All models Approx- you use products tested and approved by imately 8.0 l Mercedes-Benz. They are listed in this Mercedes-Benz Owner's Manual in the appro- Petrol (EN 228, E DIN 51626-1) priate section. You can identify service products approved...
  • Page 376 In areas where petrol with the required addi- reduce engine performance and increase tives is not available, carbon deposits can fuel consumption. Avoid driving at full build up. In this case, Mercedes-Benz recom- throttle. mends the use of additives that have been approved for Mercedes-Benz vehicles; see Information on refuelling ( page 174).
  • Page 377 This can Only use flow improvers tested and approved otherwise lead to engine damage. This by Mercedes-Benz. During use, please does not include flow improver additives. observe the information on operation. For further information, see "Flow improv- Correct dosage and sufficient mixing are deci- ers".
  • Page 378 229.3, 229.5 or ACEA C3 technical standard. This may only be topped up once, and the Therefore, only Mercedes-Benz approved quantity must not be greater than 1.0 l. engine oils may be used in Mercedes-Benz engines.
  • Page 379 This could damage the engine. Information about approved brake fluid can Engine oil viscosity be obtained at any qualified specialist work- shop or on the Internet at http://bevo.mercedes-benz.com. Have the brake fluid renewed regularly at a qualified specialist workshop. Coolant Important safety notes WARNING Antifreeze is highly flammable.
  • Page 380 Further information on coolants can be adequate antifreeze and corrosion protec- found in the Mercedes-Benz Specifications tion. for Service Products, MB Specifications for Service Products 310.1, e.g. on the Inter- net at http://bevo.mercedes-benz.com.

  • Page 381: Vehicle Data

    Vehicle data At temperatures below freezing: Dimensions and weights Fill the washer fluid reservoir with a mixture of water and washer fluid, e.g. MB Winter- Fit. Adapt the mixing ratio to the outside temper- ature. Down to Ò10 †: mix 1 part MB WinterFit with 2 parts water.
  • Page 382 Vehicle data E 200 BlueEFFICIENCY E 300 BlueEFFICIENCY E 350 BlueEFFICIENCY Vehicle length 4698 mm Unladen weight, Coupé 1660 kg Vehicle width excluding 1786 mm exterior mirrors Unladen weight, Cabriolet 1785 kg Vehicle height, Coupé 1397 mm E 500 BlueEFFICIENCY Vehicle height, Cabriolet 1398 mm Vehicle length...

  • Page 383: Trailer Tow Hitch

    Trailer tow hitch E 250 CDI BlueEFFI- CIENCY Vehicle length 4698 mm Vehicle width excluding 1786 mm exterior mirrors Vehicle height, Coupé 1397 mm Vehicle height, Cabriolet 1398 mm Unladen weight, manual 1700 kg transmission Unladen weight, auto- 1825 kg matic transmission E 350 CDI BlueEFFI- CIENCY...
  • Page 384 Trailer tow hitch Trailer loads Missing values for the E 500 BlueEFFICIENCY were not available at the time of going to print. All models (except the E 500 BlueEFFICIENCY model) Permissible trailer load, unbraked 750 kg Permissible trailer load, braked (at minimum gra- 1800 kg dient-climbing capability of 12 % from a standstill.

  • Page 385: Blind Spot Assist

    ( page 245). The current country overview can be obtained from a Mercedes-Benz Service Centre or on the Internet at: http://www.mercedes-benz.de/betriebsanleitung. Vehicles with a navigation system: the radar sensor system is deactivated automatically near radio telescope facilities.

Table of Contents
