Summary of Contents for ECI Hi-FOCuS 960E
- Page 1 960E Installation Manual Hi-FOCuS™ 960E Installation Manual ECI Telecom Ltd. Proprietary...
- Page 2 ECI. In addition, any use of this document or disk or the information contained herein for any purposes other than those for which it was disclosed is strictly forbidden.
-
Page 3: Electrical Safety Hazards
The fiber optics ports must never be exposed during operation. • Each of the ports must be connected to a fiber optic cable, terminated at the far end, or covered with a proper protection cap supplied with the system. ECI Telecom Ltd. Proprietary... -
Page 4: Warning Instructions
Caution: Indicates information on how to avoid damage to the equipment or to avoid possible service disruption. ESD: Indicates information on how to avoid discharge of static electricity and subsequent damage to the unit. ECI Telecom Ltd. Proprietary... -
Page 5: Table Of Contents
Line cards....................16 4.4............. 16 ENTRAL ILTERING NSTALLATION 4.5................16 RONT OVER NSTALLATION 5. C ...................... 17 ABLE ONNECTING 5.1..................17 ROTECTIVE ROUND 5.2..............18 OWER ONNECTOR ONNECTION 5.3................... 18 LOCK EFERENCE ECI Telecom Ltd. Proprietary... - Page 6 Traffic Cables — Network and Subscribers..........44 B.4.2. Fiber Optic Cables ................... 44 B.4.3. Ethernet 10/100/1000BaseT ..............45 B.4.4. RS-485 Connector ................... 45 B.4.5. Ethernet Clock..................46 B.4.6. E1 A and B ....................47 B.4.7. Ethernet 8 and 9 ..................48 ECI Telecom Ltd. Proprietary...
- Page 7 Ethernet Clock connector ................46 Figure 37. Ethernet Clocks Pinout.................. 46 Figure 38. E1 A and B connector ................... 47 Figure 39. E1 A and B Pinout ..................47 Table 5: Ethernet 8 and 9 RJ-45 Pin out................48 ECI Telecom Ltd. Proprietary...
- Page 8 960E Installation Manual Table 6: SFP Types ......................48 Table 7: Hi-FOCuS Specifications table ................51 Table 8: HF5 Cards Power Consumption ................51 ECI Telecom Ltd. Proprietary viii...
- Page 9 Power range, displayed by LED and reported alarm bit........44 Table 6: Ethernet RJ-45 Pin out ..................45 Table 7: RS-485 Connector Pin Assignments ..............45 Table 8: CFU Card LEDs — States and Definitions ............49 Table 9: Acronym Table....................50 ECI Telecom Ltd. Proprietary...
-
Page 10: System Overview
1.1. Platform Description ECI’s 960E is a fully customizable and very flexible high-bandwidth access gateway and DSLAM. The 960E can be deployed in the central office where it can aggregate traffic from other Hi-FOCuS shelves toward the network. It can also be deployed in the local loop to provide services directly to subscribers. -
Page 11: External Interfaces And Indications
960E Installation Manual 1.2. External Interfaces and Indications Figure 2. 960E Shelf Unit Figure 3. 960E Chassis ECI Telecom Ltd. Proprietary... -
Page 12: Front View
• Main card compartment with tributary/line cards in slots 1-15 • NI cards in slots 16 and 17 • FAN Unit • CFU A and CFU B cards • Hold up Capacitors Card • Front cover ECI Telecom Ltd. Proprietary... -
Page 13: Central Connection Panel
RJ-45 Female 2 Mbps clock in and out for uplink RJ-45 Male copper synchronization RS 485 RJ-45 Female Enable remote control for external RJ-45 Male devices ETH-8 RJ-45 Female For Ethernet 10/100BaseT service. RJ-45 Male ETH-9 ECI Telecom Ltd. Proprietary... -
Page 14: Line Connectors
The Central Connecting Panel contains an RS485 (RJ-45 female) connector for local craft connection. 1.2.7.4. Ethernet A, B Connectors The Central Connecting Panel contains Ethernet (RJ-45 female) connectors for Ethernet 10/100/1000BaseT service connection labeled as ETH A and ETH B (out-of-band). ECI Telecom Ltd. Proprietary... -
Page 15: Direct Terminal Access
In the event of a failure of any one of the fans, the remaining fans also switch to Turbo mode to maintain cooling power. The fan card is controlled by the NI cards. Controls include speed, start and stop. Reports include shelf temperature and fan status. ECI Telecom Ltd. Proprietary... -
Page 16: Installation Overview
SFP (optional) (see Chapter 6) (see Chapter 6) (see Chapter 6) Power up the 960E (see Chapter 7) Perform the commissioning procedure 960E_Installation_chart.vsd (see Chapter 8) Figure 6. 960E Installation Overview ECI Telecom Ltd. Proprietary... -
Page 17: Site Preparation And Pre-Installation
Warning: You must install an external grounding wire if the metal installation structure is not properly grounded. • Types of interfaces used at the site (optical, electrical, management, alarm monitoring, etc.) • Work and equipment safety requirements ECI Telecom Ltd. Proprietary... -
Page 18: Required Tools & Accessories
Included in Package Power Cable 1 or 2 Protection Ground Ethernet 10/100BaseT Alarms & Clocks RS232 POTS LINE Dual Fiber Optic SM, LC/xx* 8 sets *xx is the connector at the user end of the cable. ECI Telecom Ltd. Proprietary... -
Page 19: Site Requirements
Before unpacking, make a preliminary inspection of the shipping boxes. Evidence of damage should be noted and reported immediately to the carrier, the project manager, and/or your local ECI Telecom representative. Caution - Static sensitive devices require proper handling and grounding. 960E equipment contains components sensitive to electrostatic discharge (ESD). -
Page 20: To Unpack The Equipment
Search the shipping boxes for any additional small items that may be present. Check the contents of the shipping boxes against the packing list attached to each box. If you detect any damaged or missing parts, notify the project manager and/or your local ECI Telecom representative. ECI Telecom Ltd. Proprietary... -
Page 21: System Mounting
2. Use M6 screws in the top and bottom holes on each side of the shelf to secure the shelf in the rack. ECI Telecom Ltd. Proprietary... -
Page 22: Figure 7. Mounting Bracket And Position (Etsi Shown)
960E Installation Manual Screw holes for mounting in middle positioning rack mounts ETSI Mounting Bracket Figure 7. Mounting bracket and position (ETSI shown) ECI Telecom Ltd. Proprietary... -
Page 23: Installing Units Adjacent To The 960E
The space between the 960E and other units below or on top of it can be as little as 100mm. Power Distribution Frame Splitter 960 Direct connection between Shelves Hi-FOCuS 960E Optical Distribution Frame 960E_Rack_Mount1.vsd Figure 8. 960E in an ETSI Rack ECI Telecom Ltd. Proprietary... -
Page 24: Card Installation
3. Align the CFU card with the guide rails in the 960E frame and push the card along the slide rail into the slot with even force until it meets the connection socket on the backplane. ECI Telecom Ltd. Proprietary... -
Page 25: Ni Cards
The front cover is required to provide EMC and to maintain airflow over the cards. To close the front cover, lift the cover and lower it on to the front of the 960 and tighten the two front retaining bolts. ECI Telecom Ltd. Proprietary... -
Page 26: Cable Connecting
To ground the 960E. 1. Remove the GND lug from the shelf, below the CCP, by releasing the two ESD screws. 2. Crimp the GND cable into the lug. 3. Re-install the cable with lug, secured with the screws. ECI Telecom Ltd. Proprietary... -
Page 27: Power Connector Connection
1. Insert the 37-pin alarm connector cable into the Alarm port on the 960E CCP. 2. Use slot-head 5x150 mm screwdriver to secure the connector. 3. Connect the other end of the cable to the Alarm panel in the rack mount. ECI Telecom Ltd. Proprietary... -
Page 28: Traffic Cables
960E to allow proper clearance during re-installation of the front cover. straight_plug Figure 11. Cable w/Straight Connector right_angle_plug Figure 12. Cable w/Right Angle Connector The 960E contains a fiber/cable guide with 17 slots for the 17 line/NI cards. Cable Guides Figure 13. Fiber/Cable Guide ECI Telecom Ltd. Proprietary... -
Page 29: Sfp Connection
Subscriber Copper Connectors and Cables To connect the copper cables to the CCP: 1. Insert the 78-pin telco connector into the POTS/Subscriber Lines port on the 960E CCP. 2. Use slot-head 5x150 mm screwdriver to secure the connector. ECI Telecom Ltd. Proprietary... -
Page 30: Subscriber Copper Connectors And Cables On Card
1. Connect RJ-45 plug connector of the cable to the Ethernet 1 port on the 960E CCP. 2. Connect the other cable side to the Ethernet equipment. Make sure the RJ-45 connectors are locked in the ports. ECI Telecom Ltd. Proprietary... -
Page 31: System Verification
1. Unplug the cards from the backplane (the cards may remain in their slots, but they must not contact the backplane). 2. Use a multimeter to check whether the input -48/60V DC power supply is within range. ECI Telecom Ltd. Proprietary... -
Page 32: Board Status
960E starts running. If the fans in the chassis are not running normally, cut off the power and check the fans. 2. Turn off the power of the rack, and then re-insert the cards into the backplane. ECI Telecom Ltd. Proprietary... -
Page 33: Powering-Up
EMC (Electro Magnetic Compatibility) standards. See section Front Cover Installation for cover installation procedure. 7.1.1. Powering Down There are no special procedures for powering down the 960E. To power down the system, turn off the A and B power sources. ECI Telecom Ltd. Proprietary... -
Page 34: Commissioning
9. Verify that the Fault LED is off on the IPNI and a Login prompt appears on the Hyper terminal screen. The common login and password are: Login: ecidslam password: Hi-FOCuS (Case sensitive) The following Command prompt appears: IPNI > ECI Telecom Ltd. Proprietary... -
Page 35: Basic Syntax Commands
5. Reboot the 960E by typing restart at the command prompt and then press Enter. The system reboots. To set in-band configuration parameters 1. Set the IP Address and IP Gateway, by typing: Inbandip <ipaddress> <gateway> <subnetmask> <NI NUM (Optional) a/b> and then press Enter. ECI Telecom Ltd. Proprietary... -
Page 36: Sample Screens
5. Reboot the 960E by typing restart at the command prompt and then press Enter. 8.4. Sample Screens Figure 14. Screen shot after typing eer and pressing Enter. Figure 15. Screen shot after pressing Space bar. ECI Telecom Ltd. Proprietary... -
Page 37: Shelf Card Population
To view the IPNI card version: 1. Type: ver. Figure 17. 960E IPNI Card Version To view the ATUC/VTUC SW/HW version: 1. Type XTUCTERM 0 7. 2. Type in any Login and Password. Press Enter. 3. Type ver. ECI Telecom Ltd. Proprietary... -
Page 38: Figure 18. 960E Atuc Card Version
960E Installation Manual Figure 18. 960E ATUC Card Version Figure 19. 960E VTUC Card Version ECI Telecom Ltd. Proprietary... -
Page 39: Maintenance
2. Grasp the screws and gently remove the FAN by pulling it towards you. Note: As you withdraw the FAN, note metal guide that controls its path. 3. Place the FAN in antistatic packaging. ECI Telecom Ltd. Proprietary... -
Page 40: Installing And Removing The Air Filters
Save the package for future use. While holding the SFP Transceiver, carefully slide the SFP Transceiver into the socket, labeled as 1…8 Tx Rx and verify that it is mechanically locked in place. Caution: Do not use force. ECI Telecom Ltd. Proprietary... -
Page 41: List Of Orderable Items
List of Orderable Items USA Part No. Accessory Quantity Provided Y22853 SFP TRANSCEIVER 15KM DTAG Y33038 V2U-C24EC Y43520 ATU-C64IP ISDN Y33096 IPNI-80E R3 DTAG Y33097 SHELF SAM-960E DTAG Y33098 CFU FOR SAM-960E Y12417 CABLE POWER 5W5 TO OPEN 3 Meters ECI Telecom Ltd. Proprietary... -
Page 42: Cables And Connectors
Eight external input alarms and three external output alarms (Major, Minor and Alarm Cutoff) are available in the CCP 37 D-Type connector. The external alarms are sent status on external events, such as cabinet door opening, to the OPS. ECI Telecom Ltd. Proprietary... -
Page 43: Figure 22. Alarm Connector 37 Pin D Type Male Pin-Out
960E Installation Manual Figure 22. Alarm Connector 37 Pin D Type Male Pin-out Table 2: Alarm Connector Pin Assignment DC_AC_NO IN_ALR1 DC_MI_NO IN_ALR2 DC_MA_NC IN_ALR3 IN_ALR4 CGND IN_ALR5 IN_ALR6 IN_ALR7 IN_ALR8 ECI Telecom Ltd. Proprietary... - Page 44 960E Installation Manual NAMIA_NC EUMIA_CO EUMIA_NO N48V_LIM EUMAR_CO EUMAR_NC P48V EUMAV_CO EUMAV_NC ALM_COMM NAMAV_NO DRY_COMM NAMAR_NO ECI Telecom Ltd. Proprietary...
-
Page 45: In-Alarm
-48/60V for common. ALM_COMM IN_ALR1 IN_ALR2 IN_ALR3 IN_ALR4 IN_ALR5 IN_ALR6 IN_ALR7 IN_ALR8 P48VDC P48VDC -48/60VDC P48VDC P48VDC P48VDC P48VDC P48VDC P48VDC IPNI Alarm_Connection_circuitry.vsd Figure 23. In-Alarm Connection Circuitry ECI Telecom Ltd. Proprietary... -
Page 46: Out-Alarm
Major alarm is NC and the alarm is active when power is down or when the system software indicates a Major alarm. Minor and ACO alarms are NO and active when the system software indicates a Minor or ACO alarm respectively. Figure 24. Out-Alarm Connection Circuitry ECI Telecom Ltd. Proprietary... -
Page 47: Data
Subscriber copper connections are 78 pin male D-Type connectors at the shelf. This 78 pin connector is used for all technologies (ADSL2+, VDSL2 and POTS). It is used for either 24 pairs or 32 pairs. Each connector serves either 24 or 32 pairs. Figure 27. Line Connector ECI Telecom Ltd. Proprietary... -
Page 48: Line-Pots Connectors Pin Assignment
Connections to the ADSL cards are through the CCP. VDSL cards are equipped with connectors on their front panels. Route the subscriber cable through the cable guide and plug the 78 pin D-type connector into the appropriate line/splitter card. B.2.2. LINE-POTS Connectors Pin Assignment Figure 29. Line/POTS Connector ECI Telecom Ltd. Proprietary... -
Page 49: Figure 30. Subscribers Line Cable Connector Pin Assignments
Ring Brown Ring Orange Yellow Yellow Ring White/Blue Ring Gray Yellow Yellow Ring Green/Blue Ring Orange/Blue Yellow Yellow Ring Gray/Blue Ring Brown/Blue Yellow Yellow Ring Orange/Green Ring White/Orange Figure 30. Subscribers Line Cable Connector Pin Assignments ECI Telecom Ltd. Proprietary... -
Page 50: Din 160 Pin Male Connector
DSL 8-Ring DSL 14-Ring DSL 18-Ring DSL 4-Tip DSL 13-Tip DSL 17-Tip DSL 4-Ring DSL 13-Ring DSL 17-Ring DSL 7-Tip DSL 12-Tip DSL 16-Tip DSL 7-Ring DSL 12-Ring DSL 16-Ring DSL 2-Tip DSL 11-Tip DSL 15-Tip ECI Telecom Ltd. Proprietary... -
Page 51: Adsl2+ Front Connector
960E Installation Manual DSL 2-Ring DSL 11-Ring DSL 15-Ring DSL 1-Tip DSL 6-Tip DSL 10-Tip DSL 1-Ring DSL 6-Ring DSL 10-Ring B.2.4. ADSL2+ Front Connector Figure 32. ADSL2+ Front Connector pinout ECI Telecom Ltd. Proprietary... -
Page 52: Rs-232 Db-9 Connector
Power Connection The required Power range is –40.5VDC to –75 VDC. As in other ECI platforms, the 960E receives power from two sources in redundant mode. The standard power feed module for the 960E is the High-current Input Filter dual-source power feed module supported with two Central Filtering Unit (CFU) card modules. -
Page 53: Power Range
Normal. Fiber optic cables are available in 3mm diameter and in 2mm diameter. Use fiber optic cables of 2mm diameter only and LC boot length of 30mm maximum. Figure 34. Fiber Optic Cable The recommended bending radius of the fiber optic cable is approximately 30mm. ECI Telecom Ltd. Proprietary... -
Page 54: Ethernet 10/100/1000Baset
B.4.4. RS-485 Connector The RS-485 connector is for external control, such as automatic MDF. The RS-485 connector pin-outs are shown in the following table. Table 7: RS-485 Connector Pin Assignments Signal Connector 485TXH 485TXH 485TXH 9_pin_D 485TXH ECI Telecom Ltd. Proprietary... -
Page 55: Ethernet Clock
960E Installation Manual B.4.5. Ethernet Clock Figure 36. Ethernet Clock connector Figure 37. Ethernet Clocks Pinout ECI Telecom Ltd. Proprietary... -
Page 56: E1 A And B
960E Installation Manual B.4.6. E1 A and B Figure 38. E1 A and B connector Figure 39. E1 A and B Pinout ECI Telecom Ltd. Proprietary... -
Page 57: Ethernet 8 And 9
100m / Copper Cat. 5 Note: The operating distance varies for each system design. Therefore, the results are not official and should be considered as a reference only. Note: The 960E is not supplied with an SFP Transceiver. ECI Telecom Ltd. Proprietary... -
Page 58: Led Display Definition
–75 V Power Green only –38V >Input Voltage> Input voltage out of range. –75 V –40.5V >Input Voltage> Voltage warning. –75V Alarm Red only –40.5V >Input Voltage> Input power okay –75V (if power LED is on). ECI Telecom Ltd. Proprietary... -
Page 59: Glossary Of Terms And Acronyms
Remote Access Multiplexer Service Access Multiplexer SANI Switched Aggregate Network Interface Shortcuts card (Bypass card) STU-C Symmetric DSL Termination Unit Central Office TANI Tributary ATM Network Interface V2U-C VDSL2 Termination Unit Central Office VLAN Virtual Local Area Network ECI Telecom Ltd. Proprietary... -
Page 60: Specifications
ETSI rack per IEC 60917-2-1 Installation (Including Japanese requirements) E.1. Power Consumption The Hi-FOCuS 960E power consumption is a function of the cards installed. The following table shows the power consumption of selected cards: Table 8: HF5 Cards Power Consumption Card Power Consumption... -
Page 61: Disposal
Installation Manual E.2. Disposal Consumer Notice: The ECI product you have purchased is subject to Directive 2002/96/EC of the European Parliament and the Council of the European Union on waste electrical and electronic equipment (WEEE) and, in jurisdictions adopting that Directive, is marked as being put on the market after August 13, 2005, and should not be disposed of as unsorted municipal waste.
