Signal Flow Diagram - TC Electronic DBMAX V2 User Manual

DBMAX
In Level
Trim Input
Left
ANALOG
A/D
INPUTS
[balanced]
Right
Ext. Sync
Internal 44.1kHz
Internal 48kHz
Clock
Ext. DI
Digital Input
AES/EBU
[AES]
SRC
S/PDIF
Digital Input
[S/PDIF]
All manuals and user guides at all-guides.com
INPUT PPM
Left
Right
Input
Selector
Ins 1 Ins 2 Ins 3 EXP
Digital In Gain
OUTPUT PPM
Defined Overload
Fader
Out Fine L/R
COMP LIM Ins 4
Bypass
Dither
Left
Right
Trim Output
ANALOG
D/A
OUTPUTS
[balanced]
Digital Out Gain
Digital Output
[AES]
Digital Output
[S/PDIF]
9
