Summary of Contents for Healy 0007
- Page 1 Healy Watch INSTRUCTIONS FOR USE Model No.: 0007...
-
Page 2: Table Of Contents
3.1 Installation 3.1.1 Smartphone Requirements 3.1.2 Android Operating System 3.1.3 iOS Operating System 3.1.4 Hardware 3.1.5 Pairing via Bluetooth 3.1.6 Wearing the Healy Watch 4. Operation Instructions 4.1 Software Functions 5. Cleaning, Disinfection and Maintenance 5.1 General 5.2 Cleaning 5.3 Storage Between Applications... - Page 3 7.5 Environmental Conditions 7.5.1 Operation and Storage 8. Disposal 9. Used Symbols and Icons 10. Revision Status Disclaimer: The Healy Watch is not intended to cure, treat, mitigate, diagnose or prevent disease, but rather to support vitality and wellbeing. EN | 4...
-
Page 4: Introduction
1. Introduction Thank you for choosing the Healy Watch. Please read this manual carefully and pay special attention to the warnings and cautions. This manual is intended for the user. Intended users include adults at home. It aims to ensure safe handling and to enable users to become familiar with the device. -
Page 5: Hardware Description
2.2.1 Hardware Description Removable straps Wrist pads Sensor Full-screen touch display Sensor Sensor Built-In USB charger 2.2.2 Software Description The "Healy Watch App" is required for configuring and con- trolling the Healy Watch hardware. EN | 6... -
Page 6: Attention
2.3 Attention · Intentional misuse may impair the function of the device. · Carefully read the instructions before using the device. · This product is intended only for the purpose described in these ins tructions for use. ... -
Page 7: Preparations For Use
3. Preparations for Use 3.1 Installation Before putting the Healy Watch into operation, you need to prepare the hardware and install the "Healy Watch App". 3.1.1 Smartphone Requirements Bluetooth Bluetooth 4.2 or higher Operating system iOS version 9.0 or higher Android version 4.4 or higher... -
Page 8: Hardware
3.1.4 Hardware · Unpack the Healy Watch and check for damage · Charge the batteries for 1.0 hours before first use Note: The battery cannot be removed by the user. Gently pull the straps off. OPEN Do NOT pull the straps horizontally... - Page 9 Insert the built-in USB charger into a USB port for charging. Remove device from the power supply once fully charged. Push the straps back on. EN | 10...
-
Page 10: Pairing Via Bluetooth
Make sure the smartphone Bluetooth (BLE 4.2) and location service are turned on. Go to「Settings → Pair Device」and select the Healy Watch for pairing. You can check the Healy Watch Bluetooth ID in「Function → Info」. Pair the Healy Watch with your smartphone. - Page 11 EN | 12...
-
Page 12: Wearing The Healy Watch
3.1.6 Wearing the Healy Watch For accurate heart rate* measurement, please wear the watch: Tightly but comfortably. It should not move while running or exercising. Keep it at least one finger width away from the carpal bones. * Not intended for diagnosis or therapy 4. -
Page 13: Software Functions
Wrist Gesture - Rotate or lift your wrist toward your body to turn the screen on. 4.1 Software Functions Watch Face – The Healy Watch updates the time and date automatically when you sync with a smartphone. Status – The total number of steps, cal-... -
Page 14: Cleaning, Disinfection And Maintenance
Healy Watch. Please read this section carefully. 5.2 Cleaning Switch off the Healy Watch before cleaning. For cleaning, com- mercial cleaning products may be used. The surfaces can be wiped with a damp sponge or cloth. Make sure that no liquid penetrates beneath the covers or enclosures. -
Page 15: Maintenance
5.4 Maintenance There are no user serviceable parts inside. In the event of damage, please contact the manufacturer. The following maintenance activity is recommended and should be followed for safe operation. Frequency By whom Maintenance activity Prior to User Check the casing for damage. each use In case of damage contact the manufacturer or an authorized... -
Page 16: System Components
6. System Components Reference Description Quantity number 0007 Healy Watch hardware device 108-1301 Screen protector 108-1302 Screen wipe 108-1303 Conductive gel 7. Technical Data 7.1 General Protection against IP 67, dustproof, complete protec-... -
Page 17: Electrical Parameters
7.2 Electrical Parameters 7.2.1 Power Source Requirements The Healy Watch can be connected to any power source with the following specifications: Supply voltage range 4.4 V – 5.5 V DC Output current Max. 2500 mA Frequency Socket type USB-Type A... -
Page 18: Fcc Statement
7.2.3 FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, includ-ing interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. -
Page 19: Ec-Declaration Of Conformity
7.3 EC-Declaration of Conformity This is an electrical device for application on humans. Type: Healy Watch Year of manufacture: 09-2019 – 12-2019 The product is designed and manufactured in accordance with the following directives: Low Voltage Directive 2014/35/EU ROHS - Directive 2011/65/EU; REACH 1907/2006/EC under the sole responsibility of: Company: Healy GmbH |Schloss Kränzlin|... -
Page 20: Mechanical Parameters
7.4 Mechanical Parameters Dimensions 11.6 x 2.2 x 12.4 cm Weight 30 g Strap TPU black Input socket 7.5 Environmental Conditions 7.5.1 Operation and Storage Temperature Range 5°C to 40°C / 41°F to 104°F Relative humidity 15 % to 93 % Atmospheric pressure 700 hPa to 1060 hPa 8. - Page 21 Watch Face Status Sleep Work Out Function Breath Message Recycling Bluetooth symbol In conformity with European legis lation REF 0006 Hardware reference number Symbol for Bluetooth wireless connection Electronic waste – do not dispose. Recycle acc. to local regulations or contact your authorized dealer or the manufacturer EN | 22...
-
Page 22: Revision Status
10. Revision Status Revision: 1 Date: 23th November 2019 Remark: Second edition Healy GmbH Schloss Kränzlin, Darritzer Str. 6 16818 Kränzlin - Germany 23 | EN... - Page 23 EN | 24...
- Page 24 Healy GmbH | Schloss Kränzlin | Darritzer Str. 6 16818 Kränzlin – Germany T. +49 30 54905949-1 www.healyworld.net | info@healy.de...
