2000 lb.12V DC Electric Trailer Jack
#8970220
WARNING:
Read, Understand, Follow and Save These Instructions.
Failure to follow all warnings and instructions may result in product failure, property
damage, serious personal injury.
The warnings, cautions, and instructions discussed in this instruction manual
cannot cover all possible conditions or situations that could occur. It must be
understood by the operator that common sense and caution are factors which
cannot be built into this product, but must be supplied by the operator
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Princess auto TowingMaster 8970220
- Page 1 2000 lb.12V DC Electric Trailer Jack #8970220 WARNING: Read, Understand, Follow and Save These Instructions. Failure to follow all warnings and instructions may result in product failure, property damage, serious personal injury. The warnings, cautions, and instructions discussed in this instruction manual cannot cover all possible conditions or situations that could occur.
-
Page 2: Intended Use
INTENDED USE This electric trailer tongue jack is a 12V motor-driven jack that makes coupling and uncoupling from the hitch on travel trailers and boat trailers an easier operation. New industrial design that holds up to rugged conditions and is waterproof. TECHNICAL SPECIFICATIONS Amperage Lift current-No load... -
Page 3: Installation Instructions
Do not modify the jack in any way. Unauthorized modification may impair the function and/or safety and could affect the life of the equipment. There are specific applications for which the jack was designed. Always check for damaged or worn out parts before using the jack. Broken parts will affect the jack operation. -
Page 4: Maintenance
place with the 3/8” safety lock pin (#13) provided. Do not stack blocks under the jack’s foot to increase the height. Stacked WARNING: blocks may become unstable and fall. 3. Extend the jack by pushing the operating switch (#4) UP. Note: Under heavy use, the internal circuit breaker may open, causing the motor to switch off. -
Page 5: Exploded View
Ensure all connections are tight and free of corrosion and that the jack is properly grounded Open Internal Circuit Breaker Wait 15 seconds for breaker to close Loose Wires on ON/OFF Switch Secure wire connections ON/OFF Switch Faulty Replace switch Motor Faulty Replace motor Motor Clutch... -
Page 6: Parts List
PARTS LIST Parts No. Description Override Protection Cover Plastic Cover Motor Up/Down Switch Black Up/Down Switch Cover Gear Assembly ACME Screw Outer Tube Inner Tube Lock Pin Crank Footpad Hardware Kit Positive Wire Negative Wire Limited 1 year Warranty We makes every effort to assure that this product meets high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of one years from the date of manufacture, provided that installation and use of the product is in accordance with product instructions. - Page 7 Cric de remorque électrique 12V DC 2000LBS #8970220 AVERTISSEMENT: Lisez, comprenez, suivez et enregistrez ces instructions. Le non-respect de tous les avertissements et instructions peut entraî ner une dé faillance du produit, des dommages matériels, des blessures graves. Les avertissements, mises en garde et instructions décrits dans ce manuel d'instructions ne peuvent pas couvrir toutes les conditions ou situations pouvant survenir.
-
Page 8: Utilisation Prévue
UTILISATION PRÉVUE Ce vérin d'attelage électrique pour remorque est un vérin motorisé de 12 V qui facilite et accélère le couplage et le désaccouplement de l'attelage sur les roulottes de voyage et les remorques de bateau. SPÉCIFICATIONS TECHNIQUES Intensité de courant Courant de levage - Pas de charge 1.8-2.3A Courant de rétraction –... -
Page 9: Instructions D'installation
Vérifiez toujours les piè ces endommagé es ou usées avant d'utiliser le cric. Les pièces cassé es affecteront le fonctionnement du cric. Remplacez ou réparez immé diatement les piè ces endommagé es ou usées. Ne forcez pas le cric de remorque. N'essayez pas de soulever plus que la capacité de levage maximale de 2000 lb. -
Page 10: Entretien
1. Garez la remorque sur une surface plane et bloquez les roues. 2. Avant d'utiliser le cric, étendez le cale-pied (# 15) à la longueur appropriée et fixez-le en place avec la goupille de sécurité 3/8 ”(# 13) fournie. AVERTISSEMENT: n'empilez pas de blocs sous le pied du cric pour augmenter la hauteur. -
Page 11: Dépannage
DÉPANNAGE Reportez-vous au guide de dé pannage ci-dessous si l'appareil ne fonctionne pas correctement ou s'il manque des pièces. En cas d'impossibilité, faites réparer l'appareil par un technicien qualifié. Échec Cause possible Action corrective Pas ou basse tension Vé rifiez la batterie et les connexions é lectriques. Doit avoir un minimum de 10 VDC. -
Page 12: Vue Éclatée
VUE ÉCLATÉE Page of 13... -
Page 13: Liste Des Pièces
LISTE DES PIÈCES No. de pièces Description Qté Couverture outrepassé de protection Couverture plastique Moteur Up/Down interrupteur Couverture Up/Down interrupteur Ensemble d'engrenage Vis ACME Tube extérieur Tube interne Goupille de verrouillage Manivelle Coussin de pied Kit matériel Fil court positif Fil court né...
