Page 2
FIRE PIT Customer Service Before Return: If part missing or damaged, or you need help with assembly, please do not hesitate to contact us. Website: www.casainc.com Contact us: (303)747-4321 Email us : service@casainc.com...
Page 3
FIRE PIT ITM./ART.#: WFEHFP-06-C MODEL#: F200061-B2 ANS Z21.97 CSA 2.41-2017 Outdoor Decorative Gas Appliances INSTALLER: Leave this manual with the appliance. WARNING: For Outdoor Use Only. CONSUMER: Retain this manual for future reference Installation and service must be performed by a qualified installer, DANGER service agency, or the gas supplier.
IMPORTANT SAFETY INFORMATION The installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1 NFPA 54; National Fuel Gas Code; Natural Gas and Propane Installation Code, CSA B149.1; or Propane Storage and Handling Code, CSA B149.2, as applicable. The appliance must be isolated from the gas supply piping system by closing its individual manual shutoff valve during any pressure testing of the gas supply piping system at test pressures equal to or less than 1/2 psi (3.5 kPa).
IMPORTANT SAFETY INFORMATION ABOUT PROPANE (LP) GAS The LP-gas supply cylinder to be used must be constructed and marked in accordance with the U.S. Deparment of Transportation (D.O.T.) Specifications for LP-Gas Cylinders, or the Standard for Cylinders, Spheres and Tubes for Transportation of Dangerous Goods and Commission, CAN/CSA-B339, as applicable.
PACKAGE CONTENTS PART DESCRIPTION QUANTITY Fire table 1 pc 1 pc Tank seat 1 pc Weather cover Lava rock (4.18 Ibs) 1 box ASSEMBLY INSTRUCTIONS Carefully unpack all parts from the box, compare parts with package content listed above, make sure all parts are present before beginning assembly of product.
Page 7
3. Put the gas tank in the tank seat (B), connect the regulator, screw the black handle clockwise to tighten, turn the black handle counterclockwise to remove. The hose must point down. The knob on the control panel is turned all the way to the “OFF” position when the fireplace is NOT in use (see Figure 3). black handle Figure 3 4.
Page 8
BATTERY Make sure the control knob is in the “OFF” position. Unscrew the push button cap on the ignitor module located on the control panel to access the battery compartment. The ignitor module requires one AAA size battery (See Figure 6), BATTERY IS NOT INCLUDED. WARNING: 1.
gas valve-hose connection (Figure 9) inlet tube-bellows connection (Figure 10) To perform a leak test: Make 2~3 oz. of leak solution by mixing one part liquid dishwashing detergent and three parts water. Noted: make sure control knob is “OFF”. Apply several drops of solution where the cylinder attaches to regulator (See Figure 7), inspect the solution at the connection looking for bubbles.
Observe Flame Height When Lit: The burner will display blue and yellow flames. These flames should be a blue / yellow color between 1~2 in. height (See Figure 12). These flames should not be yellow or produce thick smoke. This would indicate an obstruction of airflow through the burners. The flames should be blue with straight yellow tops.
WARRANTY Firepits Burner, steel fire pit bowl, all mechanical parts and fittings to control panel and burner assembly, and all fire pit tops that are not cast aluminum are warranted for a period of one (1) year from original date of purchase, against defects in material and or workmanship.
