DVR User Manual
- DSS 4-30, 16-30, 16-60, 4-120 series
- DSS 16-120, 16-240, 16-480, 5000 series
Digital Video Recorder System
Eyetech Digital International
8491 Lemon Ave.
Alta Loma, CA. 91701
USER GUIDE MANUAL
GOLDENEYE INSTALL GUIDE MANUAL
Phone ; 909-989-1040
Fax
; 909-941-3144
Web site; WWW.eyetechdigital.com
1
Advertisement
Table of Contents
Summary of Contents for EyeTech DSS 4-30 Series
- Page 1 GOLDENEYE INSTALL GUIDE MANUAL DVR User Manual - DSS 4-30, 16-30, 16-60, 4-120 series - DSS 16-120, 16-240, 16-480, 5000 series Digital Video Recorder System Eyetech Digital International Phone ; 909-989-1040 8491 Lemon Ave. ; 909-941-3144 Alta Loma, CA. 91701...
-
Page 2: Table Of Contents
USER GUIDE MANUAL CONTENTS NOTICE Introduction Precaution before Installation Warranty Sheet Warranty Contents Checking List System General ------------------------------ System Features --------------------------- Main Function ----------------------- Monitoring Mode ----------------------------- Monitoring Mode Explanation ------------------ Pan/Tilt Control Method ----------------------- Function Setting Methods ---------------------- Way of Function Converting ------------------- General Setting---------------------------- Camera Setting ----------------------------- Motion &... -
Page 3: Precaution Before Installation
Products Introduction DSS 430, DSS 1630, DSS 1660, DSS 4120, DSS 16120, DSS 16240, DSS 16480, DSS 5000, GED (Golden Eye) are Eyetech series. Thanks for choosing our products. This manual includes DVR system program setting methods, functions, features & pan/tilt control connection. -
Page 4: Warranty Contents
USER GUIDE MANUAL Warranty Introduction We guarantee that we will repair and exchange defective products when there are any Defaults on our products under this paper. Warranty Contents If our products break down within 1Year under the manual condition, we should repair it without any charge. -
Page 5: Checking List
USER GUIDE MANUAL Checking List Please check if you have all the items as follows and if you find some other material missing, contact the purchasing place. (Option: Monitor, Audio Input Cable, Network connecting Cable) SET Base MONITOR (OPTION) - Resolution 1024 * 768, 60Hz True Color, +32bit DVR SYSTEM (Digital Video Recorder System) Key Board, Mouse... -
Page 6: System General
USER GUIDE MANUAL 1 System General This system makes analogue signal into digital signal and save it in HDD, then search those information when you need. This is what we called DVR (Digital Video Recorder) 1.1 System Features 1) System Stability We spent more than 4 Years to make our systems stabilized. -
Page 7: Monitoring Mode
USER GUIDE MANUAL 2 Monitoring Mode Information display part (1) Date and Time (2) Sensor & Alarm, RMS, Backup (3) Saving degree (Oldest Basket saving data) Screen control part (4) 1, 4, 6, 9, 10, 16 division (5) Maximum screen (6) Converting to next camera (7) Automatic group (8) PAN TILT CONTROL... -
Page 8: Pan/Tilt Control Method
USER GUIDE MANUAL /Tilt Control Method When you watch the video and control the view scope of camera or it can be possible to control focus in/out & zoom in/out. This is different according to Receiver (refer to Appendix Receiver) PAN/TILT Setting Method (1) Click setting ->... - Page 9 USER GUIDE MANUAL 2. How to use Pan/Tilt (1) Click ‘Pan/Tilt’ button, and put ‘ID’ & ‘Password’ (2) Color turns into blue when it is being used. (3) Click the icon. You can change following (left/right) icon. (4) You can check out all direction with Zoom In/Zoom Out button also.
-
Page 10: Way Of Function Converting
USER GUIDE MANUAL 3.1 Way of Function Converting (The shape of icon before/ after) (1) Click the Setup button. (2) Put ID & Password. *REF: Please make sure that nobody except operator changes this setting mode. Logging in is made only when operator put ID &... -
Page 11: General Setting
USER GUIDE MANUAL General Setting (1) Initialize: Interval and Initialization - Composite Monitor display interval: Composite (TV) Monitor (Default: 3Sec, Converting ever 3minutes) - Pan/Tilt Control seeing Composite Monitor: From the composite monitor you can check out moving image on camera. - Full Screen: Set for full screen. -
Page 12: Camera Setting
USER GUIDE MANUAL 3.3 Camera Setting (10) (1) Select Camera You can choose if you use PTZ, CODEC type, etc. * Apply same value to all cameras: If you want to make all the function same. (You can choose if you use PTZ, CODEC type, etc) (2) Camera Option - Use: You have to check here after select the camera. - Page 13 USER GUIDE MANUAL - Notify E-Mail on Event It sends e-mail notice when event happens (Motion, Sensor, and Video Loss) Outgoing mail Server: SMTP Server From: Sender’s account Authentication: When you need certification through e-mail server, ask mail server manager. ID/Password: Put User ID &...
- Page 14 USER GUIDE MANUAL (5) Adjust Camera Frame rate You can designate every camera’s frame rate. * Caution Recommendation is that Maximum Averaged Frame Rate. If you want to set each different camera’s frame rate, it should be done within the maximum frame rate it can support. In case of GED2000: Total frame rate 120FPS, so allow within this scope.
- Page 15 USER GUIDE MANUAL (9) Record Scheduling *How to use 1) Click the designated camera. 2) Click recording scheduling methods button (Normal, Motion, Sensor, etc) 3) Click suitable week day (Mon~Sun), Hour (0~24) or drag & drop. ⇒ Normal : Steady recording during fixed time. ⇒...
-
Page 16: Motion & Display Setting
USER GUIDE MANUAL Motion & Display Setting * How to use 1) Select Camera. 2) Control the screen quality. *REF: This is not real image but recording image, so you must be careful with controlling this. * Controlling of motion recording 3) Adjust sensor ratio and degree. -
Page 17: Network Setting
USER GUIDE MANUAL Network Setting - Use: Check in ‘Use’ and it permits RMS Connection. - Video Transfer method: JPEG or MPEG4 mode (In case of Modem, MPEG4 is advisable) - Notification: When sensor or motion happens, this RMS gives notification by E-Mail. * How to use 1) Check in ‘Use’. -
Page 18: Sensor Setting
USER GUIDE MANUAL 3.6 Sensor & Alarm Setting (1) Selecting sensor: Choose the sensor number (2) Option - Location of sensor: Input the sensor location - Sensor type: NC (Normal Close) or NO (Normal Open) - Connected camera : Setting of camera and free set to record when sensor turns on (3) Sensor Values - Check Interval: Setting of sensor checking time &... - Page 19 USER GUIDE MANUAL (6) Emergency button This makes it easier for user to back up data set already from emergency button. When emergency happens, it sends recording image through RMS and converting and saving. Button automatically, you can choose only one among sensors. <...
-
Page 20: User Setting
USER GUIDE MANUAL User Setting (1) New user add - Put the user account/ Password, then give the authority (management mode/user mode/ Search mode, back up mode, etc) (2) User list update - Select user and change the authority and click ‘update ‘button. (3) Delete of user - Click the user and delete it. -
Page 21: Searching Mode
USER GUIDE MANUAL 4 Searching Mode 4.1 Search Mode Changing & Methods (1) Click ‘Search’ button. - Magnified image ◄ Search mode (2) Click ‘OK’ after putting Account and Password name. - Mark the exact ‘Account and Password’ (Default ID: test, Password: test) - Manage account and password for your own. - Page 22 USER GUIDE MANUAL (3) Select searching date (red mark) (Previous month) (Next month) . These red marks mean currently recording part. (4) Click time zone for searching.
- Page 23 USER GUIDE MANUAL (5) First Image will be shown on screen. (Refer to date) (6) Searching is going on when you put this button REF: Hour basis searching among REF: Minute basis searching is available among 24hours 60minutes Different color will shown Red mark means the location where you are...
-
Page 24: Multi Searching Way
USER GUIDE MANUAL Multi Searching Way When you search the other camera, you can use this function. (1) Select the minute and hour part to search, then select right part of the searching part (1, 4, 9, 16 division) <Screen Division > 1 division 4 divisions 9 divisions... -
Page 25: Searching Screen Button Explanation
USER GUIDE MANUAL Search Screen Button Explanation Date (Year, Month, Day) Time (Hour, Minute, Second) Compression CODEC mark (JPEG, MPEG4) Camera number and file size Next camera group button choice (4 channel grouping) Previous group button choice (4 channel grouping) . - Page 26 USER GUIDE MANUAL Searching TOOL (1) Conversion button Searching TOOL (2) Searching TOOL (1) – Recording Image quality control button - Sharp: Make the vague image clear - Blur: Make the wild image softer - B/W: Convert color into Black & WHITE - Cancel: Reverse into previous step, returning button - Zoom: With the mouse clicking, magnifying the image - Original: Returning to the first image...
- Page 27 USER GUIDE MANUAL Print When you need to print the image In case of printer setting done Left image may show up asking where to print, select ‘OK’ then you can print out. In case of printer setting not done Printer setting advises message comes out...
-
Page 28: Motion Searching Way
USER GUIDE MANUAL Motion Searching Way Method Under the normal recording mode, designating specific area and analyzing It. (ex. This is very useful for stolen or lost goods) (1) Motion rate and sensibility can be adjustable. This is not related with [3.4 Motion &... -
Page 29: How To Use Book Mark
USER GUIDE MANUAL 4.5 How to use Book Mark Saving location function of current searched recording material (Time, Hour, Minute) (1) Select Stop button (2) Click ‘Motion’ button. (3) Click ‘Add Book mark’ for book marking (4) Put the Comments name. -
Page 30: Data Saving Way
USER GUIDE MANUAL Data Saving Way Saving function of searched data into disk with the form of JPEG file or AVI (Audio Video Interface) file. Normal PC can view it. (1) Still Image (JPEG) Select Still Image (JPEG) Click ‘OK’ button Saving ‘OK’... - Page 31 USER GUIDE MANUAL (4) Click playing button on Search (7) Click playing button on Search Stop General: The percentage is increasing when searching is going on. Click the stop button when you need it. (5) Click the Stop’ button (8) Click the stop button (6) ‘OK’...
-
Page 32: Log Viewer
USER GUIDE MANUAL 5 Log Viewers (1) Click the ‘Log Viewer’ button on the monitoring mode. (As follows) * REF: If log files exceed 1MB, old one remains backup version and new one will be created. All these are left on GED log folder. - Page 33 USER GUIDE MANUAL (7) Graph: Graph of the event log - Analyzed View of graphic according to each event log view. View of graphic according to date of specific date... Go to previous date/next date of the camera. Go to next page...
- Page 34 USER GUIDE MANUAL [3.3] Refer to camera Setting - Manual: Sending the email just one time. - Schedule: Send the email frequently. * As a ‘Schedule Setting’, it sends email frequently when you set this mode...
-
Page 35: Event Backup
USER GUIDE MANUAL 6 Event Backup You can use this function for back up the recorded event screen on designated directory. (Refer to 3.6 sensor& alarm (6) Event button) (1) Click ‘Event Backup’ button (1) If the message turns up like this, click ‘OK’ button Lookup Package copying image (2) confirm again whether you do Event... -
Page 36: Image Tool
USER GUIDE MANUAL 7 Image Tool This program for checking out authentication of FDD, HDD’s JPEG file. * Water marking function is already equipped Way of playing: C:₩Program files₩DVR, double click imagetool.exe file ◄ Initial screen of playing (1) Click ‘Open’ (2) Find &... -
Page 37: Backup
USER GUIDE MANUAL 8 Backup This is a part for back up into other saving equipment. There is Manual back/auto back up for user’s convenience. You can always check out at anywhere. * REF: You can not do both auto/manual back up. <... - Page 38 USER GUIDE MANUAL (5) Click ‘Select Media’ (6) Select back up device. (7) Click ‘OK’. (8) Users are designating Date->Camera->Hour ->Minute * REF Checking point is to be backed up With back up window open, The most recent information Refreshes. (9) Click ‘Back up start’...
-
Page 39: Auto Backup Method
USER GUIDE MANUAL Auto Backup Method Automatic backing up with operating specific time scheduler. < Variety of Backup > 1) DAILY BACKUP Mark Monday to Sunday and back up the previous data. 2) Minute basis BACKUP Back up after designating minute and begin backing up. Ex) if you set up 2minutes basis it is doing continuously. - Page 40 USER GUIDE MANUAL Select All: select all cameras at one time (3) Select the camera to back up (4) Select Backup device (5) Designate the location of related saving device (6) Click ‘ next’ (7) Select the kind of back up (8) Click ‘Finish’...
- Page 41 USER GUIDE MANUAL 2. Auto Backup Update This Job is done under “update” column as below. List can be shown as below when you click right button of mouse. ADD: NEW SCHEDULE ADS UPDATE: SCHEDULE AMENDS DELETE: SCHEDULE DELETES CLEAR ALL: ALL SETTING SCHEDULE ARE BEING DELETED 3.
-
Page 42: Backup Viewer
USER GUIDE MANUAL 9 Backup Viewers This is a program for viewing back up material on a general PC or DVR. < Program running methods > 1) Running at DVR (Run lookup.exe file in C:₩Program Files₩DVR folder.) 2) General PC running methods: Copy LookupPackage.exe (Backup viewer) on backup search program and open (automatically), C:₩Program Files₩Lookup is made, then you can run backup.exe (1) Click the icon... -
Page 43: Dvr Installation
USER GUIDE MANUAL 10 Installations 10.1 Front or Back part of the System 【 Front 】 Power Hard Rack HDD LED Switch (Option) Reset Button Overlay Board (RCA jack Camera (1~16) use) Sensor/Relay Outer monitor Connection connecting part: BNC jack use Capture Card Power VGA Card... -
Page 44: Capture Card Connection And Receiver
USER GUIDE MANUAL 10.2 Capture Card Connector and Receiver Capture Card Jumper J11 is for RS232, J12 is for RS422/485 Camera Receiver Camera J12 (J32) ① On: 485 Modes Off: 422 Modes ② J11 (J31) COM1 COM2 Line 1 connecting way: J12 (J32) port should be connected to PTZ Camera or Receiver Please refer to following. -
Page 45: Sensors & Relays Connector Pin Spec (Kit)
USER GUIDE MANUAL 10.3 Sensors & Relays Connector Pin Spec SENSOR 3~12V DC Lamp or Siren (Max 30W) DC 30V 1A AC 125V 0.3A 10.4 Back I/O Board with Sensors & Relays (SET) Video 1~ 16 Common 1, 2 Composite Output (TV monitor) Relay 1~4 Sensor 1~ 16... -
Page 46: Pan/Tilt Camera Protocol
USER GUIDE MANUAL 10.5 /Tilt Camera Protocol setting Values by Receiver Stop Auto Pan Preset 2007.10 Jan index Receiver Baud rate Parity Data Bit Dvna 9600 9600 Fine 2400 Linlin 9600 Panasonic 19200 Pelco D 2400 Philips 9600 Serim 9600 Sungjin 4800 Vicon_1200R... -
Page 47: Sound Setting For Audio
USER GUIDE MANUAL 10.6 Sound Setting Method Audio volume should be controlled in PC which has RMS installed S/W for sound recording < How to use > (1) Start->Program->Sub program (2) If you click ‘Option->Properties’, ->Entertainment->Volume control you can see ‘properties info’ window Sound card mixer equipment Check mike... - Page 48 USER GUIDE MANUAL (5) Check the mike output volume At other control part. Check Microphone Boost List. It can show +20db Gain in some cases. You can use recorder function to check Mike output before & after checking) You must check if sound input is working well.
