- Page 1 24 Port Fast Ethernet Switch with VLAN and Trunking User Manual Model # ANS-24RV...
- Page 2 FCC Warning This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
-
Page 3: Table Of Contents
1.4 Front Panel LED indicators ..6 1.5 Rear panel..6 1.6 Power Connecting..6 1.7 Connecting computers to the switch ..6 1.8 Uplink ..6 1.9 To prolong the operational life to your units ..7 2 Installing the Fast Ethernet Switch ... 8 2.1 Configure system network... - Page 4 2.10 Configuration... 22 2.10.1 Configuration Backup/Recovery ... 22 3 Console User Interface ... 24 3.1 Connecting to the Switch Console Port... 24 3.2 Setup HyperTerminal... 24 3.3 Configure Switching Hub via COM1 Port ... 27 3.3.1 Switch Main Menu ... 27...
-
Page 5: Introduction
1. Introduction 1.1 General Description The device is a powerful, high-performance Fast Ethernet switch, with all 24 ports capable of 10 or 100Mbps auto-negotiation operation (Nway) which means the switch could automatically negotiate with the connected partners on the network speed and duplex mode. It is ideal for micro-segmenting large networks into smaller, connected subnets for improved performance, enabling the bandwidth demanding multimedia and imaging applications. -
Page 6: Front Panel Led Indicators
Rear Panel of the switching hub has a RS232 Connector, a power cord socket. 1.6 Power Connecting Plug the circle end of the power cord firmly into the power port on the switch rear panel, and the other end into an electric service outlet, then the system is ready. -
Page 7: To Prolong The Operational Life To Your Units
When using the uplink port, you can extend the distance to 100m for linking another switch or hub. 1.9 To prolong the operational life of your units *Never stack units more than eight high if freestanding *Do not place objects on top of any unit or stack... -
Page 8: Installing The Fast Ethernet Switch
2. Installing the Fast Ethernet Switch 2.1 Configure system network The switching hub offers a Web based management software to manage and monitor the switching hub. Before running the management software, you have to configure your system network setup. For Windows 98/98SE and ME, click “Network”... -
Page 9: Login The Smartswitch Web-Base Controller
Step 3: Select “Use the following IP address”, and enter “IP address”, “Subnet mask”, and “Default gateway” fields, and then click “OK”. 2.2 Login the Web Step 1: Enter IP address http://192.168.2.1 in the web browser URL field. Step 2: When Login window pops out, enter “Username”... -
Page 10: The Smartswitch Home Overview
2.3 The SmartSwitch Home overview The window below shows the Home page of SmartSwitch: Administrator 1) Authentication Configuration 2) System IP configuration... -
Page 11: Administrator
3) System status 4) Load Default Setting 5) Firmware update Port Management 1) Port Configuration 2) Port Mirroring 3) Bandwidth Control 4) Broadcast Storm Control VLAN Setting 1) Group VLAN Setting 2) Multi to 1 Setting Trunk Setting Trunk Configuration QoS Setting 1) Priority Mode 2) Class of Service Configuration... -
Page 12: System Ip Configuration
2.4.2 System IP Configuration In this page, you can set and update the IP Address, Subnet Mask, and setting. After filling up the data that you want to change, click “Update” to process the data changed immediately. 2.4.3 System Status Click on “System Status”... -
Page 13: Load Default Setting
2.4.4 Load Default Setting This option helps you to reset the device back to the default setting from the factory. Be aware that the entire configuration will be reset, the IP address of the device will be set to default setting 192.168.2.1. Just simply click “Load”... -
Page 14: Firmware Update
2.4.5 Firmware update Before updating the firmware, you should check whether your management station provides TFTP server and DHCP server. If these 2 services exit on your management station, you should disable both services by executing the following procedures: (1) Click “Control Panel” “System Management Tool”... - Page 15 This program can be downloaded from the web site. http://tftpd32.jounin.net/.You don’t need to install this program. To run TFTPD32 just launch the executable file tftpd32.exe. The configuration procedure for DHCP/BootP server is illustrated as the following figures. Step1: Click the “Settings” item and set base Directory. Step2: To update the firmware through this program, you should select TFTP server, DHCP server and Syslog server.
-
Page 16: Port Management
(5) Press the “Update” button which is shown on the Web page. After you press the “update” button, the TFTP procedure starts and the program shows the throughput of the data transfer as shown below. If no throughput can be seen on this program, there may be something wrong with your settings. -
Page 17: Port Mirroring
Port Mirroring is a method of monitoring network traffic that forwards a copy each incoming and/or outgoing packet from one port of a network switch to another port where the packet can be studied. It enables the manager to keep Close track of switch performance and alter it if necessary. -
Page 18: Broadcast Storm Control
2.5.4 Broadcast Storm Control You can enable Broadcast Storm Control to configure the advanced switch function. The value indicates the number of broadcast packet which is allowed to enter each port in one time unit. One time unit is 10 ms for 100Mbps speed and 100ms for 10Mbps speed. -
Page 19: Vlan Setting
2.6 VLAN Setting 2.6.1 Group VLAN Setting This page allows user to define Virtual LAN (VLAN) membership by group of device’s ports. Any individual port can be a member of a VLAN group. A VLAN basically a broadcast domain, but any port is not limited to belong to only one VLAN group. The forwarding rule is that packets from the source port will be only forwarded to destination port within the same VLAN group. -
Page 20: Trunk Setting
2.7 Trunk Setting 2.7.1 Trunk Configuration Port trunk setting. The trunk hash algorithm can select “Port ID”, “Source address”, “Destination address” or “SD &DA”... -
Page 21: Qos Setting
2.8.1 Priority Mode Before users do the priority setting, you have to check the “Enable High box at Class of Service page. 24-port Modular Smart Switch offers Low) queues, which catch the priority information in based in the incoming frames as controller guarantees the service for high priority frames to some extent, depending on the load condition of incoming traffic. -
Page 22: Mac Address
Default: All ports in TOS priority recognition disabled. VLAN tagging base (TCI) priority recognition: indicates this port is TCI priority enabled. Default: All ports in TCI priority recognition disabled. 2.9 MAC Address 2.9.1 MAC Address Configuration This page allows user define which MAC address can be entry to the port. You can assign three MAC address for every port. -
Page 23: Configuration
2.10 Configuration 2.10.1 Configuration Backup/Recovery This function allows you to backup or recovery the latest switch settings. Just simply enter your password and click “Update” button. -
Page 24: Console User Interface
3. Console User Interface 3.1 Connecting to the Switch Console Port User can configure the switch system via terminal emulation program through RS-232 port with baud rate 19200-8-n-1. The RS-232 connector is on the back panel of the switching hub; make sure you connect the other end of serial port to COM1 of PC. - Page 25 Step 2: The Connection windows will appear. Enter terminal “Name”, select correct icon, and then click “Ok” button. Step 3: Select “COM1” in the “Connect using” field and then click “OK”.
- Page 26 Select “19200” in Bits per second field and click “Apply” & “OK” buttons to save the settings. Step 5: Reset or pull out the switch power. Wait for a while for system checking and then press “s” to enter the Note: If you press other key, you won’t into the console, please reset the...
-
Page 27: Configure Switching Hub Via Com1 Port
3.3 Configure Switching Hub via COM1 Port 3.3.1 Switch Main Menu After you enter the Modular Console, the Switch Main Menu will appear. 3.3.2 Load Default Setting This page allows user to restore default port settings. - Page 28 In the 1 option to 3 option (1. Restore switch default setting/2. Restore default Setting/3. Restore Login default Setting), just simply press number to restore the default settings. Press”4’ to enter Modify IP setting screen:...
