Rhino Winch 8004698 Quick Start Manual

8004698, 8004700, 8004702, 8004703, 8004705, 8004706, 8004714, 8004714, 8004715
V 1.34 V 1.3

SPECIFICATIONS

8004698
Max. Capacity: 800 lb
Rope dia.: 3/16"
Drum capacity: 40 ft
Gear Ratio: 3:2:1
Reversible N/A
Ratchet:
Free spool in off Yes
position
# of speeds 1

IMPORTANT SAFETY PRECAUTIONS

WARNING! Read and understand all instructions before using this winch. Keep this manual for the
safety warnings and precautions, operating, inspection and maintenance instructions. When using
this winch, basic precautions should always be followed to reduce the risk of personal injury and/or
damage to the equipment.

PERSONAL SAFETY

1. Do not over reach; keep proper footing and balance at all times. Proper footing and balance enables better control of
the winch in unexpected situations.
2. Dress properly, wear protective equipment. Do not wear loose clothing or jewelry as they can be caught in moving
parts. Tie back long hair. Protective clothes and non-skid footwear are recommended when working.
3. Stay alert, watch what you are doing and use your common sense. Do not operate a winch when you are tired, under
the influence of drugs, alcohol or medications.

TOOL USE AND CARE

1. Use the right winch for the job. Do not attempt to force a lower capacity winch to do the work required of a larger
capacity winch. The proper capacity winch will perform better and more safely at the task for which it was intended. Do
not modify this winch or use for a purpose for which it was not designed.
2. Maintain your winch with care. Keep your winch clean and in good condition for a better and safer performance. The
handle must be kept clean, dry and free from oil and grease at all times. A properly maintained winch reduces the risk of
injury and is easier to control. Applying excessive force can lead to slips, damage to the winch or personal injury.

SERVICE

1. Check for damaged parts. Before using any winch, any part that appears to be damaged should be carefully checked
to determine that it will operate properly and perform its intended functions. Check for alignment and binding of moving
parts; broken parts or mounting fixtures, or any other condition that may affect proper operation. Any part that is
damaged should be properly repaired or replaced by a qualified technician.
For any technical questions, please call 1-800-665-8685
Hand
Winch
8004700 8004702 8004703
1,200 lb 1,400 lb 1,800 lb
5/16" 5/16" 5/16"
30 ft 20 ft 58 ft
4.1 : 1 4:1 4 : 1/8 : 1
Yes Yes Yes
Yes Yes Yes
1 1 2
8004705 8004706 8004709
2,500 lb 600 lb 1,200 lb
7/16" 5/32" 3/16"
30 ft 33 ft 33 ft
4 : 1/8 : 1 3.2 : 1 4.1 : 1
Yes N/A Yes
Yes Yes Yes
2 1 1
1
8004714 8004715
1,000 lb 2,000
2" 2"
23 ft 23 ft
4.1 : 1 4 : 1/8 : 1
Yes Yes
Yes Yes
1 2
