Summary of Contents for Hisense HB20MOBX5UK

  • Page 1 HB20MOBX5UK...

  • Page 2: Microwave Oven

    Microwave oven We sincerely thank you for your purchase. We believe you will Dear Customer soon fi nd ample evidence that you can really rely on our products. To make the use of the appliance easier, we attach these comprehensive instruction manual. The instructions should aid you in getting familiar with your new appliance.

  • Page 3: Important Safety Instructions

    Important safety instructions Never touch the surfaces of heating or cooking appliances. They will become hot during operation. Keep children at a safe distance. There is a risk of burning! Microwave energy & High voltage! Do not remove the cover. WARNING! The appliance and its accessible parts become hot during use.
  • Page 4 • Never replace the light bulb inside the oven. It must always be replaced by Hisense service. • Do not clean the appliance with steam cleaners, high-pressure cleaners, sharp objects, abrasive cleaning agents, and abrasive...
  • Page 5 Safety instructions for general use Listed below are, as with all appliances, certain rules to follow and safeguards to assure top performance from this oven: 1. Always have the glass tray, roller arms, coupling and roller track in place when operating the oven. 2.

  • Page 6: Control Panel

    CONTROL PANEL DISPLAY Power Level (microwave power level) Defrost (Weight or Time defrost) Clock / Timer (setting the clock or countdown timer) START / +30 Sec (Quick start, start the programm, extend the programm) STOP / Cancel (to stop or cancel the program/setting) Knob decrease time/weight, access to the timer increase time/weight, access to the automenu...
  • Page 7 Operation instructions This microwave oven uses modern electronic control to adjust cooking parameters to meet your needs better for cooking. 1. Clock Setting When the microwave oven is electrified,the oven will display "0:00", buzzer will ring once. 1) Press "Clock/Timer" twice, the hour figure flash; 2) Turn "knob"...
  • Page 8 Operation instructions 4. Defrost By Weight 1) Press "Defrost" once, the screen will display "dEF1". 2) Turn "knob" to select the food weight. The range of weight is 100-2000g. 3) Press "Start/+30 Sec" key to start defrosting. 5. Defrost By Time 1) Press "Defrost"...
  • Page 9 Operation instructions Menu Weight Display 200g 400g Auto Reheat 600g 200g 300g Vegetable 400g 250g 350g Fish 450g 250g 350g Meat 450g 50 g (with water 450 ml) Pasta 100 g (with water 800 ml) 200g 400g Potato 600g 200g Pizza 400g 200 ml...

  • Page 10: Care Of Your Microwave Oven

    Care of your microwave oven 1. Turn the oven off and remove the power plug from the wall socket before cleaning. 2. Keep the inside of the oven clean. When food splatters of spilled liquids adhere to oven walls,wipe with a damp cloth. The use of harsh detergent or abrasives is not recommended.

  • Page 11: Installation Instructions

    Installation instructions Installation 1. Make sure all the packing materials are removed from the inside of the door. 2. Inspect the oven after unpacking for any visual damage such - Misaligned Door - Damaged Door - Dents or Holes in Door Window and Screen - Dents in Cavity If any of the above are visible, DO NOT use the oven.
  • Page 12 Built-in cabinet Prepare the cabinet 1. Put the template on the bottom of the cabinet.
  • Page 13 2. Make the marks on the bottom of the cabinet according to marks "a" on the template. A center line B bracket C screws A 3. Remove the bottom cabinet template and fix the bracket with screw A. Install the oven 4.
  • Page 14 Specifications Power consumption 230V~50Hz,1250W Output power 800W Grill heater Operating frequency 2450MHz Outside Dimensions 595mm(W)x388mm(H)x345mm(D) Oven Capacity 20 litres Uncrated Weight Approx. 15 kg Noise level Lc < 58 dB (A) Turntable diameter 245 mm This appliance is marked according to the European directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE).

  • Page 15: Before You Call For Service

    Guarantee & service If you need information or if you have a problem, please contact the Hisense Customer Care Centre in your country you find its phone number in the worldwide guarantee leaflet). If there is no Customer Care Centre in your country, go to your local Hisense dealer or contact the Service department of Hisense domestic appliances.
  • Page 16 HB20MOBX5UK (11-20)
